PDS02-05S12H Overview

Analog Circuit, PDSO7,

PDS02-05S12H Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Power Mate Tech
Reach Compliance Code	compli
Maximum input voltage	9 V
Minimum input voltage	4.5 V
JESD-30 code	R-PDSO-G7
Number of terminals	7
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	0.167 A
Nominal output voltage	12 V
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	GWDIP7/14,.7
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	Not Qualified
surface mount	YES
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	2.54 mm
Terminal location	DUAL

Preview

Download Datasheet

View All

APPLICATIONS

Wireless Network

Telecom/Datacom

Industry Control System

Measurement Equipment

Semiconductor Equipment

FEATURES

•

2 WATTS MAXIMUM OUTPUT POWER

•

SMD AND DIP PACKAGE, 0.74 x 0.50 x 0.33 INCH

•

SMD PACKAGE QUALIFIED FOR LEADFREE REFLOW SOLDER PROCESS

ACCORDING IPC J-STD-020D

•

2:1 WIDE INPUT VOLTAGE RANGE

•

HIGH EFFICIENCY UP TO 84%

•

INPUT TO OUTPUT ISOLATION: 1600VDC

•

LOW RIPPLE & NOISE

•

EXTERNAL ON/OFF CONTROL

•

SWITCHING FREQUENCY (100KHz, MIN)

•

CONTINUOUS SHORT CIRCUIT PROTECTION

•

UL94-V0 PACKAGE MATERIALS

•

CE MARK MEETS 2006/95/EC, 93/68/EEC AND 2004/108/EC

•

UL60950-1, EN60950-1 AND IEC60950-1 LICENSED

•

COMPLIANT TO RoHS EU DIRECTIVE 2002/95/EC

OPTIONS

3000VDC ISOLATION

DESCRIPTION

The PDS02(SMD type), PDH02(DIP type) offer 2 watts of output power from a 0.74 x 0.50 x

0.33 inch package without derating to 85ºC. The PDS(H)02 series have 2:1 wide input

voltage of 4.5~9, 9~18, 18~36 and 36~75VDC and features 3000VDC of isolation,

short-circuit protection.

T E C H N I C A L S P E C I F I C AT I O N

OUTPUT SPECIFICATIONS

Output power

Voltage accuracy

Minimum load

Line regulation

LL to HL at Full Load

All specifications are typical at nominal input, full load and 25ºC otherwise noted

INPUT SPECIFICATIONS

2 Watts, max.

± 1% Input voltage range

± 0.2%

Input filter

5V nominal input

12V nominal input

24V nominal input

48V nominal input

4.5 ~ 9VDC

9 ~ 18VDC

18 ~ 36VDC

36 ~ 75VDC

Capacitor type

15VDC 1sec, max.

25VDC 1sec, max.

50VDC 1sec, max.

100VDC 1sec, max.

80mAp-p

40mAp-p

30mAp-p

20mAp-p

Power up

5mS

Remote ON/OFF

5mS

Open or high impedance

Control pin applied current

2 ~ 4mA max(via 1KΩ)

2.5mA, max.

5V input

±1.0%

12V input

No load to Full load

±1.0% Input surge voltage

24V input

Load regulation

±0.5%

48V input

10% load to 90% load

±0.8%

5V input

12V input

Input reflected ripple

Cross regulation (Dual)

Asymmetrical load 25%/100% FL

±5%

24V input

current(Note 6)

Ripple and noise

20MHz bandwidth

See table

48V input

Nominal input and

±0.02%

/ ºC, max. Start up time

Temperature coefficient

constant resistive load

Transient response recovery time

25% load step change 250µS, typ. Remote ON/OFF

DC-DC ON

DC-DC OFF

Short circuit protection

Continuous, automatics recovery

Single

Dual

Single

Dual

GENERAL SPECIFICATIONS

Efficiency

Isolation voltage

Isolation resistance

Isolation capacitance

Switching frequency

Approvals and standard

Dimensions

Weight

MTBF(Note 1)

Standard

Suffix ”H”

Remote off state input current

See table Application circuit:

1600VDC, min.1 minute

3000VDC, min.1 minute

10 ohms, min.

50pF, max.

100KHz, min.

Nominal input

Standard

Suffix ”H”

IEC60950-1, UL60950-1, EN60950-1

0.74 x 0.50 x 0.33 Inch

Operating ambient temperature

(18.9 X 12.8 X 8.4 mm)

4.5g(0.16oz) Storage temperature range

BELLCORE TR-NWT-000332

MIL-HDBK-217F

EN55022

EN61000-4-2

EN61000-4-3

EN61000-4-5

EN61000-4-6

Air

Contact

8KV

6KV

10 V/m

2KV

1KV

10 Vr.m.s

5.107 x 10

hrs Thermal shock

2.886 x 10

hrs Vibration

ENVIRONMENTAL SPECIFICATIONS

-40ºC ~ +85ºC (non-derating)

-55ºC ~ +125ºC

MIL-STD-810F

5% to 90% RH

IPC J-STD-020D

IPC J-STD-033B

Level 2a

EMC CHARACTERISTICS

EMI (Note 6)

ESD

Radiated immunity

Surge (Note 7)

Conducted immunity

Relative humidity(non-condensing)

Class A Lead-free reflow solder process

Perf. Criteria A Moisture sensitivity level(MSL)

Perf. Criteria A

Fast transient (Note 7) EN61000-4-4

PDS02-05S12H Related Products

	PDS02-05S12H	PDH02-05S12	PDH02-05S12H	PDH02-12S12	PDH02-12S12H	PDS02-05S12	PDS02-12S12	PDS02-12S12H
Description	Analog Circuit, PDSO7,	Analog Circuit, PDIP7,	Analog Circuit, PDIP7,	Analog Circuit, PDIP7,	Analog Circuit, PDIP7,	Analog Circuit, PDSO7,	Analog Circuit, PDSO7,	Analog Circuit, PDSO7,
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Maker	Power Mate Tech	Power Mate Tech	Power Mate Tech	Power Mate Tech	Power Mate Tech	Power Mate Tech	Power Mate Tech	Power Mate Tech
Reach Compliance Code	compli	compli	compli	compli	compli	compli	compli	compli
Maximum input voltage	9 V	9 V	9 V	18 V	18 V	9 V	18 V	18 V
Minimum input voltage	4.5 V	4.5 V	4.5 V	9 V	9 V	4.5 V	9 V	9 V
JESD-30 code	R-PDSO-G7	R-PDIP-T7	R-PDIP-T7	R-PDIP-T7	R-PDIP-T7	R-PDSO-G7	R-PDSO-G7	R-PDSO-G7
Number of terminals	7	7	7	7	7	7	7	7
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Maximum output current	0.167 A	0.167 A	0.167 A	0.167 A	0.167 A	0.167 A	0.167 A	0.167 A
Nominal output voltage	12 V	12 V	12 V	12 V	12 V	12 V	12 V	12 V
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	SOP	DIP	DIP	DIP	DIP	SOP	SOP	SOP
Encapsulate equivalent code	GWDIP7/14,.7	DIP7/14,.55	DIP7/14,.55	DIP7/14,.55	DIP7/14,.55	GWDIP7/14,.7	GWDIP7/14,.7	GWDIP7/14,.7
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	SMALL OUTLINE	SMALL OUTLINE	SMALL OUTLINE
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	NO	NO	NO	NO	YES	YES	YES
Temperature level	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL	INDUSTRIAL
Terminal form	GULL WING	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	GULL WING	GULL WING	GULL WING
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
package instruction	-	DIP, DIP7/14,.55	DIP, DIP7/14,.55	DIP, DIP7/14,.55	DIP, DIP7/14,.55	-	-	SOP, GWDIP7/14,.7
