59036 Clamp Sensor Features and Benefits
Features
Sensor with integral clamping
•S
feature
•
Suitable for mounting on 15mm ø
pipework
•
Choice of contacts
•
Choice of connector
•
Customer defined cable length
Benefits
No
•
N standby power required
•
Hermetically sealed, magnetically
operated contacts continue to
operate long after optical and other
technologies fail due to
contamination
•
Quick and simple clip fit feature
Applications
•
•
•
•
Position and limit sensing
P
Linear actuators
Industrial Process Control
Liquid level control
DIMENSIONS (in) mm
CUSTOMER OPTIONS - Switching Specifications
TABLE 1
Contact Type
Switch Type
Power
Voltage
Current
Resistance
Capacitance
Temperature
Time
Shock
Vibration
Switching
Breakdown
Switching
Carry
Contact, Initial
Insulation
Contact
Operating
Storage
Operate
Release
11ms 1⁄2 sine
50-2000 Hz
Watt - max.
Vdc - max.
Vdc - min.
A - max.
A - max.
Ω
- max.
Ω
- min.
pF - typ.
°C
°C
ms - max.
ms - max.
G - max.
G - max.
Form A
Normally
Open
1
10
200
250
0.5
1.2
0.2
10
10
0.3
-40 to +105
-65 to +105
1.0
1.0
100
30
Normally Open
High Voltage
2
10
300
450
0.5
1.5
0.2
10
10
0.2
-20 to +105
-65 to +105
1.0
1.0
100
30
Change
Over
3
5
175
200
0.25
1.5
0.2
10
9
0.3
-40 to +105
-65 to +105
3.0
3.0
50
30
Normally
Closed
4
5
175
200
0.25
1.5
0.2
10
9
0.3
-40 to +105
-65 to +105
3.0
3.0
50
30
CUSTOMER OPTIONS - Cable Length and Termination Specification
TABLE 2
Cable Type:-
24 AWG 7/32 PVC 105
o
C
UL1430/UL1569
TABLE 3
Termination Options:-
SELECT
OPTION
DESCRIPTION
(2
WIRE VERSIONS ILLUSTRATED
)
ACTIVATION
Using Hamlin 57025 actuator as illustrated below
Standard Lengths
SELECT
OPTION
CABLE
LENGTH
A or F
B
C
D
E
Tinned or untinned leads
Crimped terminals
6.35mm fastons
AMP MTE 2.54mm pitch
JST XHP 2.5mm pitch
(in)
01
02
03
04
05
mm
(3,94) 100
(11,81) 300
(19,69) 500
(29,53) 750
(39,37) 1000
ORDERING INFORMATION
N.B. 57025 actuator sold separately
59036
Table 1
Table 2
Table 3
X
T
XX
X
Series 59036
Switch Type
Sensitivity
Cable Length
Termination
Hamlin USA
Hamlin UK
Hamlin Germany
Hamectrol France
ISSUE No: 4 DATE: 1/5/3
Tel:
Tel:
Tel:
Tel:
+1 920 648 3000
•
Fax: +1 920 648 3001
•
Email: sales.us@hamlin.com
+44 (0)1379 649700
•
Fax: +44 (0)1379 649702
•
Email: sales.uk@hamlin.com
+49 (0) 6181 953660
•
Fax: +49 (0) 6181 9536666
•
Email: sales.de@hamlin.com
+33 (0) 1 4687 0202
•
Fax: +33 (0) 1 4686 6786
•
Email: sales.fr@hamlin.com
23
DETAILS PROVIDED ON THIS DATA SHEET ARE PROVIDED FOR
INFORMATION PURPOSES ONLY AND SHOULD NOT BE RELIED
UPON AS BEING ACCURATE FOR ANY PARTICULAR PURPOSE.
Product performance may be affected by the application to which the
product is put. Upon request, HAMLIN will assist purchasers by
providing information specific to any particular application. HAMLIN
disclaims any and all liability whatsoever for any purchaser’s reliance
upon the information contained on this data sheet without further
consultation with authorised representatives of HAMLIN.
