www.hamlin.com
59090 Heavy Duty Vane Sensor Features and Benefits
Features
•
Sensor and magnet contained in
single housing
•
Sensor operates when ferrous vane
passes through slot
•
Normally closed standard, normally
closed high voltage or change over
options
•
Choice of cable length and connector
Benefits
•
Quick and reliable single screw
mounting with location feature
•
No standby power requirement
•
Hermetically sealed, magnetically
operated contacts continue to
operate long after optical and other
technologies fail due to
contamination
Applications
•
•
•
•
•
Position and limit sensing
Security system switch
Linear actuators
Industrial process control
Shaft rotation sensing
DIMENSIONS (in) mm
CUSTOMER OPTIONS - Switching Specifications
TABLE 1
Contact Type
Switch Type
Power
Voltage
Current
Resistance
Capacitance
Temperature
Time
Shock
Vibration
Switching
Breakdown
Switching
Carry
Contact, Initial
Insulation
Contact
Operating
Storage
Operate
Release
11ms 1⁄2 sine
50-2000 Hz
Watt - max.
Vdc - max.
Vdc - min.
A - max.
A - max.
Ω
- max.
Ω
- min.
pF - typ.
°C
°C
ms - max.
ms - max.
G - max.
G - max.
Form A
Normally
Closed
4
10
200
250
0.5
1.2
0.2
10
10
0.3
-40 to +85
-65 to +85
1.0
1.0
100
30
Normally Closed
High Voltage
5
10
300
450
0.5
1.5
0.2
10
10
0.2
-20 to +85
-65 to +85
1.0
1.0
100
30
Change
Over
3
5
175
200
0.25
1.5
0.2
10
9
0.3
-40 to +85
-65 to +85
3.0
3.0
50
30
CUSTOMER OPTIONS - Cable Length and Termination Specification
TABLE 2
Cable Type:-
BS 6500 3A 16/0.2 PVC
DOUBLE INSULATED
TABLE 3
Termination Options:-
SELECT
OPTION
DESCRIPTION
(2
WIRE VERSIONS ILLUSTRATED
)
ACTIVATION
Standard Lengths
SELECT
OPTION
CABLE
LENGTH
(in)
01
02
03
04
05
mm
A or F
Tinned or untinned leads
(3,94) 100
(11,81) 300
(19,69) 500
(29,53) 750
(39,37) 1000
C
6.35mm fastons
B
Crimped terminals
ORDERING INFORMATION
59090
59036
Series 59090
Switch Type
Sensitivity
Cable Length
Termination
Hamlin USA
Hamlin UK
Hamlin Germany
Hamectrol France
ISSUE No:
5
DATE:
16/10/08
X
T
XX
X
Table 1
Table 2
Table 3
DETAILS PROVIDED ON THIS DATA SHEET ARE PROVIDED FOR
INFORMATION PURPOSES ONLY AND SHOULD NOT BE RELIED
UPON AS BEING ACCURATE FOR ANY PARTICULAR PURPOSE.
Product performance may be affected by the application to which the
product is put. Upon request, HAMLIN will assist purchasers by
providing information specific to any particular application. HAMLIN
disclaims any and all liability whatsoever for any purchaser’s reliance
upon the information contained on this data sheet without further
consultation with authorised representatives of HAMLIN.
