www.hamlin.com
File E61760(N)
57145, 57150 Actuator
59145 and 59150 Flange Mount Features and Benefits
Features
•
2 part magnetically operated
proximity sensor
•
Flying leads can exit either left or
right hand side of the housing
•
Case design allows screw down or
adhesive mounting
•
Customer defined sensitivity
•
Choice of cable length and
connector
Benefits
•
No standby power requirement
•
Operates through non-ferrous
materials such as wood, plastic or
aluminium
•
Hermetically sealed, magnetically
operated contacts continue to
operate long after optical and other
technologies fail due to
contamination
Applications
•
Position and limit sensing
•
Security system switch
•
Linear actuators
•
Door switch
59145, 59150 Sensor
DIMENSIONS (in) mm
Note: 59145 shown.
59150 leads exit opposite.
CUSTOMER OPTIONS - Switching Specifications
TABLE 1
Contact Type
Switch Type
Power
Voltage
Current
Resistance
Capacitance
Temperature
Time
Shock
Vibration
Switching
Breakdown
Switching
Carry
Contact, Initial
Insulation
Contact
Operating
Storage
Operate
Release
11ms 1⁄2 sine
50-2000 Hz
Watt - max.
Vdc - max.
Vdc - min.
A - max.
A - max.
Ω
- max.
Ω
- min.
pF - typ.
°C
°C
ms - max.
ms - max.
G - max.
G - max.
Form A
Normally
Open
1
10
200
250
0.5
1.2
0.2
10
10
0.3
-40 to +105
-65 to +105
1.0
1.0
100
30
Normally Open
High Voltage
2
10
300
450
0.5
1.5
0.2
10
10
0.2
-20 to +105
-65 to +105
1.0
1.0
100
30
Change
Over
3
5
175
200
0.25
1.5
0.2
10
9
0.3
-40 to +105
-65 to +105
3.0
3.0
50
30
Normally
Closed
4
5
175
200
0.25
1.5
0.2
10
9
0.3
-40 to +105
-65 to +105
3.0
3.0
50
30
CUSTOMER OPTIONS - Sensitivity, Cable Length and Termination Specification
TABLE 2
D
TABLE 3
Cable Type:-
24 AWG 7/32 PVC 105
o
C
UL1430/UL1569
Sensitivity Options:-
Activate Distances are approximate
using Hamlin 57145/57150 actuator
as illustrated
Switch AT before modification
TABLE 4
Termination Options:-
SELECT
OPTION
DESCRIPTION
(2
WIRE VERSIONS ILLUSTRATED
)
Standard Lengths
SELECT
OPTION
CABLE
LENGTH
A or F Tinned or untinned leads
B
C
D
E
Crimped terminals
6.35mm fastons
AMP MTE 2.54mm pitch
JST XHP 2.5mm pitch
Select Option
Switch
Type
1
2
3
4
S
Pull In
AT
Range
Activate
Distance
d
(in) mm
(.531)
13,5
(.433)
11,0
Pull In
AT
Range
17-23
20-25
T
Activate
Distance
d
(in) mm
(.453)
11,5
(.354)
9,0
Pull In
AT
Range
22-28
25-30
U
Activate
Distance
d
(in) mm
(.394)
10,0
(.335)
8,5
Pull In
AT
Range
27-33
V
Activate
Distance
d
(in) mm
(.354)
9,0
01
02
03
04
05
(in)
mm
(3,94) 100
(11,81) 300
(19,69) 500
(29,53) 750
(39,37) 1000
Normally Open 12-18
High Voltage
Change Over
15-20
Normally Closed
ORDERING INFORMATION
N.B. 57145/57150 actuator sold separately
59145/59150
59036
X
X
XX
X
Series 59145/59150
Table 1
Switch Type
Table 2
Sensitivity
Table 3
Cable Length
Termination
Hamlin USA
Hamlin UK
Hamlin Germany
Hamectrol France
ISSUE No: 4 DATE: 1/5/3
Table 4
DETAILS PROVIDED ON THIS DATA SHEET ARE PROVIDED FOR
INFORMATION PURPOSES ONLY AND SHOULD NOT BE RELIED
UPON AS BEING ACCURATE FOR ANY PARTICULAR PURPOSE.
Product performance may be affected by the application to which the
product is put. Upon request, HAMLIN will assist purchasers by
providing information specific to any particular application. HAMLIN
disclaims any and all liability whatsoever for any purchaser’s reliance
upon the information contained on this data sheet without further
consultation with authorised representatives of HAMLIN.
