223496: DescriptionBoard Connector, 66 Contact(s), 6 Row(s), Male, Straight, 0.079 inch Pitch, Press Fit Terminal, Guide Slot, Gray Insulator, Receptacle,; CategoryThe connector The connector; File Size57KB，1 Pages; ManufacturerERNI; Websitehttp://www.erni.com

Download Datasheet Parametric View All

223496 Overview

Board Connector, 66 Contact(s), 6 Row(s), Male, Straight, 0.079 inch Pitch, Press Fit Terminal, Guide Slot, Gray Insulator, Receptacle,

223496 Parametric

Parameter Name	Attribute value
Maker	ERNI
Reach Compliance Code	compli
ECCN code	EAR99
Other features	11 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE
Board mount options	PEG
body width	0.606 inch
subject depth	0.53 inch
body length	0.984 inch
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	AU
Contact completed and terminated	TIN
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	750VAC V
Durability	250 Cycles
Filter function	NO
IEC compliance	NO
maximum insertion force	.7506 N
Insulation resistance	10000000000 Ω
Insulator color	GRAY
insulator material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
JESD-609 code	e3
MIL compliance	NO
Plug contact pitch	0.079 inch
Match contact row spacing	0.079 inch
Mixed contacts	NO
Installation option 1	GUIDE SLOT
Installation option 2	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	6
Number of rows loaded	6
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.0066 mm
polarization key	POLARIZED HOUSING
Rated current (signal)	1.5 A
Guideline	UL, CSA
reliability	COMMERCIAL
Terminal length	0.146 inch
Terminal pitch	2 mm
Termination type	PRESS FIT
Total number of contacts	66
UL Flammability Code	94V-0
Evacuation force-minimum value	.139 N

Preview

Download Datasheet

View All

Ident-Nr.

Date Code

15,4

2

10 x 2 =

20

EE Zone für durchkontaktierte

Löcher ø 0.6±0.05

compliant zone for thru hole

ø 0.6±0.05

2

5x2=

10

Ebene -

11

1

z

a

b

c

d

e

f

Level 3

Level 2

11.2

9.7

8.2

+0.2

Ebene -

+0.2

Ebene - Level 1

+0.2

4.5

±0.3

3.7

±0.3

A

3,7

25 max.

1 max.

P2

P1

U1

13

±0.3

Bezugsebene Tiefe

Datum plane depth

K

Bestückungsplan

11 10 9

8

7

- contact layout

6

5

4

3

2

1

z

R3

a

b

c

d

e

f

B

C

B

C

B

C

B

C

B

C

B

C

B

C

B

C

B

C

B

C

R2

R1

13

±0.2

14.5

±0.2

16

±0.2

5.3

±0.1

6.8

8.3

±0.1

Lochbild für Leiterplatte

(Bestückungsseite)

Board hole pattern

(Component mounting side)

0.1

alle Löcher

all holes

10 x 2 = 20

+0,05

1)

2

ø 0,6

±0,05

Durchmesser

±0,05

Diameter

des metallisierten Loches

of finished plated-through hole

2

nicht

ø 0,7

±0,02

Bohrungsdurchmesser des Loches

ø 0,7

±0,02

Diameter of drilled hole

durchkontaktiert

not plated thru

3

1)

Schichtaufbau im metallisierten Loch siehe Zeichnung 114406

Metal plating of plated-through hole see drawing 114406

z

a

b

c

d

e

f

Fehlende Maße und Angaben nach IEC 61076-4-101

Missing information and dimensions per IEC 61076-4-101

Isolierwerkstoff: GV PBT, UL94 V-0, grau

Housing material: GLASS FILLED PBT, UL 94 V-0, grey

5 x 2 = ( 10 )

2

11

1

Information: P2 Level 2, 3

siehe Bestückungsplan/

see contact layout

Anforderungsstufe 2 /

Consider protection memo from DIN 34

Tolerances

All Dimensions

in mm

Scale

2:1

class 2

Only for information.

To insure that this is the latest

version of this drawing, please

contact one of the ERNI companies

before using.

Subject to modification without

prior notice.

Drawing will not be updated.

Designation

ERmet Messerleiste C

ERmet Male Wide Type C

www.ERNI.com

Index

Date

H:00052062.SZA

223496

ERMC

13,45

-0,1

B

C

D

E

F

G

H

J

L

M

N

P

Q

R

S

T

3

-0,1

ERNI

XXXXXXX

223496

I
