AMER72N-24300Z datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> AMER72N-24300Z

AMER72N-24300Z: DescriptionAC/DC LED Driver; Input voltage min (V): 90; Input voltage max (V): 305; Input frequency (Hz): 47-63; Output voltage min: 12; Output voltage max: 24; Output voltage dual assymetric (y/n): Single; Output Power (W): 72; Max Output current (A): 3; Efficiency (%): 87; Package type: Encapsulated; Rating (IP): IP67; Mounting: Wire terminal; W (in): 1.91; L (in): 1.31; H (in): 7.36; W (mm): 48.6; L (mm): 187; H (mm): 33.3; Min Operating temperature: -40; Max operating temperature (°C): 60; Derating: 60; Isolation (VAC): 3750; EMC compliance 1: EN 55015; EMC compliance 2: FCC part 15, Class B; Case material: Aluminum; Application 6 (Lighting): 1; MTBF (h): 400000; Line Regulation (% of Vin): ±3; Load Regulation %: ±3; Ripple & Noise (mV p-p): 200; SwitchingFrequencytyp(KHz): 150; Short circuit protection: Continuous; Leakage current (mA): 0.75; Active power factor correction: 1; Mode of operation: CC; Product Weight (grams): 490; CategoryPower/power management The power supply circuit; File Size379KB，6 Pages; ManufacturerAimtec; Websitehttp://www.aimtec.ca/; Environmental Compliance

Download Datasheet Parametric View All

AMER72N-24300Z Overview

AC/DC LED Driver; Input voltage min (V): 90; Input voltage max (V): 305; Input frequency (Hz): 47-63; Output voltage min: 12; Output voltage max: 24; Output voltage dual assymetric (y/n): Single; Output Power (W): 72; Max Output current (A): 3; Efficiency (%): 87; Package type: Encapsulated; Rating (IP): IP67; Mounting: Wire terminal; W (in): 1.91; L (in): 1.31; H (in): 7.36; W (mm): 48.6; L (mm): 187; H (mm): 33.3; Min Operating temperature: -40; Max operating temperature (°C): 60; Derating: 60; Isolation (VAC): 3750; EMC compliance 1: EN 55015; EMC compliance 2: FCC part 15, Class B; Case material: Aluminum; Application 6 (Lighting): 1; MTBF (h): 400000; Line Regulation (% of Vin): ±3; Load Regulation %: ±3; Ripple & Noise (mV p-p): 200; SwitchingFrequencytyp(KHz): 150; Short circuit protection: Continuous; Leakage current (mA): 0.75; Active power factor correction: 1; Mode of operation: CC; Product Weight (grams): 490

AMER72N-24300Z Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Aimtec
package instruction	,
Reach Compliance Code	compli
Factory Lead Time	12 weeks
Analog Integrated Circuits - Other Types	AC-DC POWER FACTOR CORRECTION MODULE
Certification	EN, IEC, UL
control mode	VOLTAGE-MODE
Efficiency (main output)	89%
Maximum input voltage	305 V
Minimum input voltage	90 V
Nominal input voltage	115 V
JESD-30 code	R-XDFM-W5
Maximum grid adjustment rate	3%
Maximum load regulation	3%
Number of functions	1
Output times	1
Number of terminals	5
Maximum operating temperature	70 °C
Minimum operating temperature	-40 °C
Maximum output current	3.15 A
Maximum output voltage	24 V
Minimum output voltage	12 V
Package body material	UNSPECIFIED
Package shape	RECTANGLE
Package form	MICROELECTRONIC ASSEMBLY
Protect	OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE
Ripple voltage (main output)	0.0707 Vrms
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	WIRE
Terminal location	UNSPECIFIED
Maximum total power output	72 W
Fine-tuning/adjustable output	NO

Preview

Download Datasheet

View All

Series AMER60N-Z

up to 1600mA | AC-DC LED driver

FEATURES:

•

Universal Input: 90~305 VAC

High Efficiency: Up to 88%

Active Power Factor Correction

Short Circuit / Open Circuit Protection

•

IP65/67 Design for outdoor application

Long Life, High reliability

Ultra-low ripple without flickering

5-year limited warranty

Models

Single output

Model

AMER60N-42130Z

AMER60N-42140Z

AMER60N-42150Z

AMER60N-42160Z

Max Output

Power

(W)

54.6

58.8

63.0

67.2

Output Voltage

Range

(V)

24-42

Output Current

(mA)

1300

1400

1500

1600

Input Voltage

(VAC/Hz)

90-305/47-63

Efficiency

(%)

NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity <75%, nominal input voltage and at

rated output load unless otherwise specified.

Input Specifications

Parameters

Input Current

Inrush current <2ms

Leakage current

Input dissipation

Power Factor

Input Fuse

Start-up Time

115 VAC, full load

230 VAC, full load

No Load

Output Short

115 VAC, full load

230 VAC, full load

3.15A / 300V

1.5

1.0

Sec.

Conditions

90 VAC, full load

115 VAC, cold start

230 VAC, cold start

Typical

Maximum

1.0

0.75

1.5

4.5

0.98

0.95

Units

Arms

Output Specifications

Parameters

Current accuracy

Line regulation

Load regulation

Ripple & Noise

Output Current Ripple

Current Overshoot

Hold-up time (min)

Minimum Load Voltage

Conditions

LL to HL

Full Output Voltage Range

Full load

LL to HL, full load at cold start,

% of rated output current

Typical

±5

±3

±5

Maximum

Units

mV p-p

200

120

See Models Table Above

Isolation Specifications

Parameters

Tested I/O voltage

Isolation Resistance

Isolation Capacitance

Conditions

I/P – O/P

I/P – FG

O/P – FG

500VDC

Typical

Rated

3750

2000

500

Units

VAC

MΩ

>100

5000

www.aimtec.com

F 052.1e R4

Tel: +1 514 620 2722

1 of 6

Toll free: + 1 888 9 AIMTEC (924 6832)

North America only
