RF, Microwave and Datalink Contacts
for MIL-DTL-38999, SuperNine
®
, Mighty Mouse and
Micro-Crimp
®
Connectors
Low-Loss Matched-Impedance Coaxial Contacts
Size #8 50 Ohm Matched-Impedance Coaxial Contacts
Coax contacts fit Glenair Series 80 Mighty Mouse connectors and MIL-DTL-38999 Series I,
III and IV connectors with size 8 contact cavities. 50 ohm nominal impedance. DC – 6 GHz
frequency range. Inner contact is solder type, shield termination is crimp type. Supplied as
unassembled kit with contact body, center contact, front and rear dielectric, retainer, clamp
nut, crimp sleeve, sealing boot and instruction sheet. Contacts are snap-in, rear-release.
Q
Q
Q
Pin Contact
DC – 6 GHz frequency range
50 ohm nominal impedance
50 microinches gold over nickel
plating
Q
Q
Q
Crimp termination
VSWR 1.25:1 max. @ 6 GHz
AS39029 design, construction and
performance
Socket Contact
Size #8 50 Ohm Matched-Impedance Coaxial Contacts
RG Cable
RG316
(M17/113-RG316)
RG316DS
(M17/152-00001)
LLSB-200
(M17/220-0001)
Size
8
8
8
Max.
Freq.
3 GHz
6 GHZ
2.5 GHz
Pin
Contact
852-031-02F
852-031-01F
852-043F
Socket
Contact
852-030-02F
852-030-01F
852-042F
"A" Hex
In.
mm.
.128
.128
.213
3.25
3.25
5.41
Technical Data
Specifications
Q
Q
Q
Q
Q
Q
Q
Q
Construction
Q
Connector Compatibility
Q
Q
Q
Operating temperature: -65°C. to +200°C.
VSWR: 1.25:1 max. @ 6 GHz
50 ohm nominal impedance
Dielectric withstanding voltage: 1300 Vac
rms at sea level, 250 Vac at 50,000 feet
Current rating: 1 ampere
Durability: 500 mating cycles
Shock: EIA-364-27 condition D
Vibration: EIA-364-28 condition VI, letter J
Q
Q
Center contact, body, retainer, clamp nut:
copper alloy, 50 microinches gold over
nickel plating
Front and rear dielectric:
fluoroplastic
Sealing Boot:
fluorosilicone rubber, glass-
filled PEI
MIL-DTL-38999 Series I, III and IV
Glenair Series 23 SuperNine®
Glenair Series 80 Mighty Mouse
Pin Contact 852-031, 852-043
CRIMP
SLEEVE
CABLE
(REF)
CLAMP
NUT
FRONT
DIELECTRIC
BODY
.562 (14.27)
MAX
.517 (13.13)
± .003 (0.08)
Ø.219 (5.56)
.217 (5.51)
Ø.316 (8.03)
.313 (7.95)
RETAINER
REAR
DIELECTRIC
CENTER
CONTACT
“A” HEX
CRIMP
.033 (0.84)
.029 (0.74)
10
© 2016 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • High-Speed Contacts
Dimensions in Inches (millimeters) are subject to change without notice.
RF, Microwave and Datalink Contacts
for MIL-DTL-38999, SuperNine
®
, Mighty Mouse and
Micro-Crimp
®
Connectors
Low-Loss Matched-Impedance Coaxial Contacts
Size #8 50 Ohm Matched-Impedance Coaxial Contacts
Socket Contact 852-030, 852-042
CRIMP
SLEEVE
CABLE
(REF)
CLAMP
NUT
FRONT
DIELECTRIC
BODY
.562 (14.27)
MAX
.625 (15.88)
± .006 (0.15)
Ø .0355 ± .001
(0.90 ± 0.03)
Ø .316 (8.03)
.313 (7.95)
RETAINER
REAR
DIELECTRIC
CENTER
CONTACT
“A” HEX
CRIMP
.033 (0.84)
.029 (0.74)
Crimp Tools, Removal Tool, Assembly Instruction Sheet
Contact
Part
Number
852-030
852-031
852-042
852-043
Crimp Tools
Assembly
Instruction
Sheet
AI85011
AI85012
AI85040
AI85040
Tool terminates cable shield to contact ferrule.
Use with M22520/5 die sets.
Crimp Tools
Inner Contact
Shield Crimp Sleeve
Crimper
Positioner
Crimper
Hex Die
(Solder
(Solder
809-129
809-130
termination)
termination)
(M22520/5-01)
(M22520/5-01)
(M22520/5-01)
(M22520/5-01)
(Solder
termination)
(Solder
termination)
(Solder
termination)
(Solder
termination)
(Solder
termination)
(Solder
termination)
Removal
Tool
(M81969/14-12)
(M81969/14-12)
(M81969/14-12)
(M81969/14-12)
(M22520/5-03)
(M22520/5-03)
(M22520/5-05)
(M22520/5-05)
859-049
859-049
859-049
859-049
809-129
809-129
809-129
809-130
859-051
859-051
(
M22520/5-01
)
809-129
Hex Dies
Hex die for crimping ferrule to cable braid.
Hardened steel, black oxide finish.
Reference Coax Cable Data
LLSB-200
Manufacturer
Times Microwave
Military Part Number
M17/220-0001
Impedance
50 ± 2
Operating Frequency (Max) 2.5 GHz
Temperature Range
-30° to +85°C
Continuous Working Voltage 750 V rms, max.
Jacket Material
LSZH*
Jacket Diameter
.195 (4.95)
*Low Smoke Zero Halogen cross-linked polyolefin
RG316
(mil spec)
M17-113-RG316
50 ± 2
3 GHz
-55° to +200°C
900 V rms, max.
FEP
.098 (2.49)
RG316DS
(mil spec)
M17/152-00001
50 ± 2
12.4 GHz
-55° to +200°C
900 V rms, max.
FEP
.114 (2.90)
(
M22520/5-03
)
809-130
(
M22520/5-05
)
859-051
Removal Tool
(
M81969/14-12
)
859-049
Sealing Boot
Sealing boots are supplied with contacts. To order contacts less the sealing boot, remove the "F" suffix
from the part number.
.985 (25.02)
MAX
.326
(8.28)
Wire Dia.
(in.)
.090 – .130
.130 – .170
.170 – .205
Wire Dia.
(mm.)
2.3 – 3.3
3.3 – 4.3
4.3 – 5.2
Part Number
859-042-01
859-042-02
859-042-03
.350
(8.89)
© 2016 Glenair, Inc • 1211 Air Way, Glendale, CA 91201 • 818-247-6000 • www.glenair.com • U.S. CAGE code 06324 • High-Speed Contacts
Dimensions in Inches (millimeters) are subject to change without notice.
11
