isc
Silicon PNP Power Transistor
2SB828
DESCRIPTION
·High
Collector Current:: I
C
= -12A
·Low
Collector Saturation Voltage
: V
CE(sat)
= -0.5V(Max)@I
C
= -6A
·Wide
Area of Safe Operation
·Complement
to Type 2SD1064
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for relay drivers,high-speed inverters,converters,
and other gereral high-current switching applications.
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Total Power Dissipation
@ T
C
=25℃
Junction Temperature
Storage Temperature Range
VALUE
-60
-50
-6
-12
-17
80
150
-55~150
UNIT
V
V
V
A
A
W
℃
℃
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon PNP Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
V
CE
(sat)
I
CBO
I
EBO
h
FE-1
h
FE-2
PARAMETER
Collector-Emitter Breakdown Voltage
Collector-Base Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector-Emitter Saturation Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
CONDITIONS
I
C
= -1mA ; R
BE
=
∞
I
C
= -1mA ; I
E
= 0
I
E
= -1mA ; I
C
= 0
I
C
= -6A; I
B
= -0.3A
V
CB
= -40V; I
E
= 0
V
EB
= -4V; I
C
= 0
I
C
= -1A; V
CE
= -2V
I
C
= -5A; V
CE
= -2V
70
30
MIN
-50
-60
-6
TYP.
2SB828
MAX
UNIT
V
V
V
-0.5
-0.1
-0.1
280
V
mA
mA
h
FE-1
Classifications
Q
70-140
R
100-200
S
140-280
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not
designed for use in equipment which require specialized quality and/or reliability, or in equipment
which could have applications in hazardous environments, aerospace industry, or medical
field. Please contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
