isc
Silicon NPN Power Transistors
2SD1064
DESCRIPTION
·Low
Collector Saturation Voltage
: V
CE(sat)
= 0.4V(Max)@ I
C
= 6A
·Wide
Area of Safe Operation
·Complement
to Type 2SB828
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for relay drivers , high-speed inverters,
converters,and other general high-current switching
applications.
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
V
CBO
PARAMETER
Collector-Base Voltage
VALUE
60
UNIT
V
V
CEO
Collector-Emitter Voltage
50
V
V
EBO
Emitter-Base Voltage
6
V
I
C
Collector Current-Continuous
12
A
I
CP
Collector Current-Pulse
Collector Power Dissipation
@ T
C
=25℃
Junction Temperature
17
A
P
C
80
W
T
J
150
℃
T
stg
Storage Temperature Range
-55~150
℃
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistors
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
V
(BR)CBO
V
(BR)EBO
V
CE(
sat
)
I
CBO
I
EBO
h
FE-1
h
FE-2
f
T
PARAMETER
Collector-Emitter Breakdown Voltage
Collector-Base Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector-Emitter Saturation Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
Current-Gain—Bandwidth Product
CONDITIONS
I
C
= 1mA; R
BE
=
∞
I
C
= 1mA; I
E
= 0
I
E
= 1mA; I
C
= 0
I
C
= 6A; I
B
= 0.3A
V
CB
= 40V; I
E
= 0
V
EB
= 4V; I
C
=0
I
C
= 1A; V
CE
= 2V
I
C
= 5A; V
CE
= 2V
I
C
= 1A; V
CE
= 5V
70
30
10
MIN
50
60
6
2SD1064
TYP.
MAX
UNIT
V
V
V
0.4
100
100
280
V
μA
μA
MHz
Switching times
t
on
t
stg
t
f
Turn-on Time
Storage Time
Fall Time
I
C
= 5A; I
B1
= I
B2
= 0.5A
R
L
= 4Ω;P
W
=20μs; V
CC
= 20V
0.1
1.2
0.05
μs
μs
μs
h
FE-1
Classifications
Q
R
100-200
S
140-280
70-140
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
isc website
：
www.iscsemi.com
2
isc & iscsemi
is registered trademark
