Silicon NPN Power Transistor
BDY61
DESCRIPTION
·Collector-Emitter
Breakdown Voltage-
: V
(BR)CEO
= 60V (Min)
·Low
Collector-Emitter Saturation Voltage
·Excellent
Safe Operating Area
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for power amplifier applications.
ABSOLUTE MAXIMUM RATINGS(T
a
=25℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Base Current-Continuous
Collector Power Dissipation @T
C
=25℃
Junction Temperature
Storage Temperature
VALUE
100
60
7
5
8
3
50
150
-65~150
UNIT
V
V
V
A
A
A
W
℃
℃
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
V
(BR)EBO
V
CE
(sat)
V
BE(
on
)
I
CBO
I
EBO
h
FE-1
h
FE-2
f
T
PARAMETER
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector-Emitter Saturation Voltage
Base-Emitter On Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
Current-Gain—Bandwidth Product
CONDITIONS
I
C
= 10mA ; I
B
= 0
I
E
= 1mA ; I
C
= 0
I
C
= 4A; I
B
= 0.4A
I
C
= 1A ; V
CE
= 5V
V
CB
= 100V ; I
E
= 0
V
EB
= 5V ; I
C
= 0
I
C
= 1A ; V
CE
= 2V
I
C
= 4A ; V
CE
= 2V
I
C
= 1A; V
CE
= 5V
40
20
30
MIN
60
5
TYP.
BDY61
MAX
UNIT
V
V
2.0
1.5
100
100
300
V
V
μA
μA
MHz
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
