isc
Silicon NPN Power Transistors
DESCRIPTION
·Collector-Emitter
Breakdown Voltage-
: V
(BR)CEO
= 350V(Min)
·High
Switching Speed
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for use as high-speed power switch at high
voltage.
ABSOLUTE MAXIMUM RATINGS(T
a
=25℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
I
BM
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Base Current-Continuous
Base Current-Peak
Collector Power Dissipation @T
C
=75℃
Junction Temperature
Storage Temperature
VALUE
750
350
6
4
6
2
3
30
150
-65~150
UNIT
V
V
V
A
A
A
A
W
℃
℃
BDY93
THERMAL CHARACTERISTICS
SYMBOL
R
th j-c
PARAMETER
Thermal Resistance,Junction to Case
MAX
1.65
UNIT
℃/W
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistors
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
(BR)CEO
V
CE
(sat)
-1
V
CE
(sat)
-2
V
BE
(sat)-1
V
BE
(sat)-2
I
CBO
I
EBO
h
FE
C
OB
f
T
PARAMETER
Collector-EmitterBreakdownVoltage
Collector-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Output Capacitance
Current-Gain--Bandwidth Product
CONDITIONS
I
C
= 50mA ; I
B
= 0
I
C
= 2.5A; I
B
= 0.5A
I
C
= 4A; I
B
= 1.25A
I
C
= 2.5A; I
B
= 0.5A
I
C
= 4A; I
B
= 1.25A
V
CB
=750V; I
E
= 0,
V
CB
=750V; I
E
= 0,T
C
=125℃
V
EB
= 6V; I
C
=0
I
C
= 1A ; V
CE
= 5V
I
E
= 0;V
CB
= 10V;f
test
= 1MHz
I
C
= 0.2A ; V
CE
= 10V ;f
test
= 1MHz
4
15
MIN
350
TYP.
BDY93
MAX
UNIT
V
1.5
3.0
1.4
1.6
1.0
2.0
0.1
60
500
V
V
V
V
mA
mA
pF
MHz
Switching Times
t
on
t
stg
t
f
Turn-On Time
Storage Time
Fall Time
I
C
= 2.5A; I
B1
= 0.5A;I
B2
= -1A;
V
CC
= 250V
0.3
2.0
0.3
0.5
3.5
μs
μs
μs
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
