PROFESSIONAL LED INDICATORS Ø12.7mm Mounting
FEATURES
Natural Anodised Aluminium
Low profile styling, sunlight readable LEDs
Sealed to IP67
Flying lead terminations available
Suitable for high vibration applications
Internal reverse protection diode fitted as standard in all
voltage models.
695 SERIES
PACK QUANTITY = 10 PIECES
Ordering Information & Typical Technical Characteristics (Ta = 25°C)
PART NUMBER
COLOUR
LENS
VOLTAGE
DC (Vdc)
Vopr
CURRENT
DC (mA)
lopr
SPECIFICATION
LUMINOUS
WAVE
INTENSITY
LENGTH
lv@20mA (mcd)
λp
(nm)
OPERATING
TEMP
Topr
STORAGE
TEMP
Tstg
Mean Time Between Failure = 100,000 Hours. Luminous intensity figures refer to the unmodified discrete LED.
HIGH INTENSITY
695-521-21
695-501-21
Yellow
Red
Smoked
Smoked
Smoked
12
12
12
20
20
20
11000
16000
591
643
-40 ~ +95^
-40 ~ +95^
-40 ~ +100
-40 ~ +100
Yes
Yes
695-930-21
695-501-23
695-532-21
695-997-21
Blue
Red
Green
Cool White
Smoked
Smoked
Smoked
12
UNITS
695-997-23
695-930-23
695-532-23
695-521-23
Cool White
Blue
Green
Yellow
Smoked
Smoked
Smoked
Smoked
24-28
Vdc
24-28
24-28
24-28
24-28
12
20
20
7000
23000
20
20
20
20
20
mA
14000
mcd
7000
23000
16000
11000
14000
470
643
527
*see below -40 ~ +95^
-40 ~ +95^
-40 ~ +95^
-40 ~ +95^
-40 ~ +95^
-40 ~ +100
-40 ~ +100
-40 ~ +100
-40 ~ +100
Yes
Yes
Yes
Yes
*see below -40 ~ +95^
nm
°C
470
527
591
-40 ~ +95^
-40 ~ +95^
°C
-40 ~ +100
-40 ~ +100
-40 ~ +100
-40 ~ +100
Yes
Yes
Yes
Yes
Other voltages AC/DC available. Please contact our Technical Sales.
^ = Products must be derated according to the derating information. Each derating graph refers to specific LEDs.
997F-C *Typical
emission colour cool white
x
0.245 0.361 0.356
0.264
y
0.229 0.385 0.351
0.220
Intensities (lv) and colour shades of white (x,y co-ordinates) may vary between LEDs
within a batch.
How to Order:
website: www.marl.co.uk • email: sales@marl.co.uk •
•
Telephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
relating to either products or service. Marl International reserve the right to alter without notice the specification or any conditions of supply
for products or service.
© MARL INTERNATIONAL LTD 2008 : DS 002/08 Issue 2
SAMPLES AVAILABLE
Page 1 of 3
695 Series
+ On rear of
header denotes
anode
Mounting Hole
Mounting hole to be clean and burr free
Dimensions in mm (Typical)
Not to scale
Body
Nut
Panel Seal
MATERIALS
PUSH-ON CONNECTORS
Natural anodised aluminium
Natural anodised aluminium
Viton
Brass to BS2874 CZ108 copper flash
undercoat with silver flash finish
Polycarbonate
PC5430 resin
Nylon 6 A82
925-000-00 is brass tin plated.
For use with 695 series lamps.
Dimensions in mm (Typical)
Not to scale
Termination
Lock Washer
Fresnel lens
Header
Spring Steel
Encapsulation
TECHNICAL CHARACTERISTICS
SERIES
695
MAXIMUM
POWER
DISSIPATION
mw
MAXIMUM
REVERSE
VOLTAGE
1000
Vdc
PANEL
CUTOUT
12.7
mm
NUT
MOUNTING
TORQUE
1.0
Nm
MINIMUM
MOUNTING
CENTRES
19.5
mm
MIN/MAX.
PANEL
THICKNESS
mm
2.0-10.0
825
OPTIONAL FLYING LEAD TERMINATIONS
ORDER
CODE
SUFFIX
15
15
19
19
SUPPLY
VOLTAGE
DC Products
AC Products
DC Products
AC Products
WIRE
COLOUR
WIRE
LENGTH
NO/DIAMETER
OF
CONDUCTORS
DIAMETER
OVER
INSULATION
COMMENTS
Red-anode / Black-cathode 150mm
Brown-live / Blue-neutral
150mm
19/0.15mm
1.2mm
Customised
lengths
available
Red-anode / Black-cathode 1000mm
Brown-live / Blue-neutral
1000mm
website: www.marl.co.uk • email: sales@marl.co.uk •
•
Telephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
relating to either products or service. Marl International reserve the right to alter without notice the specification or any conditions of supply
for products or service.
© MARL INTERNATIONAL LTD 2008 : DS 002/08 Issue 2
BS EN ISO 9001:2000
Approved Manufacturer
Page 2 of 3
DERATING INFORMATION
501 & 521
532, 930 & 997
PART NO.
695-501-20-15
COLOUR
Red
(Vdc) Vopr
5/6Vdc
24Vdc
VOLTAGE DC
PART NO.
695-521-72
COLOUR
Yellow
Green
(Vdc) Vopr
24Vac
48Vac
VOLTAGE DC
695-501-22-52
695-501-25-50
Red
Red
Red
695-501-25-51
695-501-42
695-501-58
695-501-72
110Vdc
695-521-74
695-501-25-52
Red
110Vdc
15Vdc
70Vdc
48Vac
24Vac
695-532-25-50
695-532-58
Yellow
Green
Red
Red
Red
110Vdc
695-532-25-52
110Vdc
70Vdc
695-509-75
695-509-22
695-501-74
695-521-25-50
695-521-58
695-521-22-51
695-521-25-52
695-521-58-19
Yellow
Yellow
Yellow
Red
Yellow
Yellow
110Vac
110Vdc
70Vdc
24Vdc
24Vdc
695-930-25-50
695-930-76
695-930-20-15
695-906-75
695-532-58-19
695-930-52-50
Blue
Blue
Blue
Yellow
Green
Green
110Vdc
Blue
110Vdc
230Vac
5Vdc
5/6Vdc
110Vac
70Vdc
695-997-72
UNITS
Yellow
Yellow
110Vdc
70Vdc
695-997-74
White
UNITS
695-997-76
White
24Vac
White
48Vac
230Vac
The products listed above illustrate all of the options available to order. These products may have custom
contact sales for further information.
modifications that alter their operation beyond the generic information contained within this datasheet. Please
website: www.marl.co.uk • email: sales@marl.co.uk •
•
Telephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
relating to either products or service. Marl International reserve the right to alter without notice the specification or any conditions of supply
for products or service.
© MARL INTERNATIONAL LTD 2008 : DS 002/08 Issue 2
BS EN ISO 9001:2000
Approved Manufacturer
Page 3 of 3
