SPECIFICATION CONTROL DRAWING
Product Revisions
Part Names
D-150-0228
D-150-0229
D-150-0230
D-150-0231
D-150-0232
D-150-0233
D-150-0234
D-150-0235
D-150-0236
D-150-0237
D-150-0238
A
B
B
A
A
B
B
A
A
A
A
Primary
No.
1
1
1
2
2
2
2
3/4
3/4
3/4
3/4
AWG
Range
26-20
20-16
16-12
26-20
18-16
14
12
26-20
22-20
18-16
14-12
Color
Code
Red
Blue
Yellow
Red
Blue
Yellow
Yellow
Red
Red
Blue
Yellow
L Max
80.52 (3.170)
80.52 (3.170)
80.52 (3.170)
105.92 (4.170)
105.92 (4.170)
105.92 (4.170)
105.92 (4.170)
105.92 (4.170)
105.92 (4.170)
105.92 (4.170)
105.92 (4.170)
Product Dimensions
øD1
A2.54
(0.100)
50.30 (1.970)
3.00 (0.118)
50.30 (1.970)
4.00 (0.157)
50.30 (1.970)
5.00 (0.197)
74.93 (2.950)
4.00 (0.157)
74.93 (2.950)
5.00 (0.197)
74.93 (2.950)
6.00 (0.236)
74.93 (2.950)
9.04 (0.356)
74.93 (2.950)
4.00 (0.157)
74.93 (2.950)
5.00 (0.197)
74.93 (2.950)
6.00 (0.236)
74.93 (2.950)
9.04 (0.356)
øD2
1.14 (0.045)
1.63 (0.064)
2.46 (0.097)
1.14 (0.045)
1.63 (0.064)
2.46 (0.097)
2.46 (0.097)
1.14 (0.045)
1.14 (0.045)
1.63 (0.064)
2.46 (0.097)
øD3
2.79 (0.110)
4.00 (0.157)
4.32 (0.170)
2.16 (0.085)
2.79 (0.110)
4.32 (0.170)
4.32 (0.170)
2.16 (0.085)
2.16 (0.085)
2.79 (0.110)
4.32 (0.170)
MATERIALS
1. SOLDERSHIELD SPLICE SLEEVE: Heat-shrinkable, radiation cross-linked modified polyvinylidene fluoride sleeve,
containing two environment resistant sealing rings and a solder impregnated, flux-coated copper-wire braid.
Transparent blue.
SOLDER: TYPE Sn63 per ANSI J-STD-006.
FLUX:
TYPE ROM1 per ANSI J-STD-004.
2. CRIMP SPLICE (1, 2, OR 4 PER KIT): Nickel-plated copper alloy.
3. SEALING SPLICE SLEEVE (1, 2, OR 4 PER KIT): Heat-shrinkable, radiation cross-linked modified polyvinylidene fluoride
sleeve, containing two environment resistant sealing rings. Transparent blue.
APPLICATION
1. These kits are designed to make an environment-resistant, 1 to 1 in-line splice in shielded single, twisted pair, trio and quad
cables having nickel-plated conductors and insulations rated for 135C minimum.
2. Temperature rating: -55C to +150C.
3. For installation procedures refer to the applicable sections of Raychem Process Standard RCPS 150-02.
TE Connectivity
305 Constitutional Drive
Menlo Park, CA 94025 USA
RAYCHEM
Products
TITLE :
(1 TO 1 SPLICES-CRIMP)
SOLDERSHIELD SPLICE KIT, SHIELDED
CABLE 26 THRU 12 AWG, Ni PLATED,
1 TO 4 CONDUCTORS
Unless otherwise specified dimensions are in millimeters.
Inches dimensions are in between brackets.
TOLERANCES:
ANGLES: N/A
TE Connectivity reserves the right to amend this
0.00 N/A
drawing at any time. Users should evaluate the
0.0 N/A
ROUGHNESS IN
suitability of the product for their application.
0 N/A
MICRON
DRAWN BY:
REPLACES:
DCR NUMBER:
DOCUMENT NO.:
DATE:
D-150-0228/-0238
DOC ISSUE:
15-Apr-11
PROD. REV.
SCALE:
SIZE:
7
SHEET:
M. FORONDA
D000671
D010337
SEE TABLE
None
A
1 of 1
Print Date: 9-May-11
If this document is printed it becomes uncontrolled. Check for the latest revision.
