70982-1003 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 70982-1003

70982-1003: Description60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE; CategoryThe connector; File Size31KB，2 Pages; ManufacturerMolexKits; Websitehttp://www.molexkits.com

Download Datasheet Parametric Compare View All

70982-1003 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	70982-1003	-	-	View	Buy Now

70982-1003 Overview

60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE

70982-1003 Parametric

Parameter Name	Attribute value
Contact materials	NOT SPECIFIED
Total number of contacts	60
Lead-free	Yes
EU RoHS regulations	Yes
state	ACTIVE
Options	GENERAL PURPOSE
Shell style	RECEPTACLE
Manufacturer Series	70928
Contact surface matching	GOLD (30) OVER NICKEL
Contact coated terminals	TIN (100) OVER NICKEL
Connection Type	TELECOM AND DATACOM CONNECTOR
Connector male and female	FEMALE
insert material	GLASS FILLED POLYMER
collocation information	MULTIPLE MATING PARTS AVAILABLE
Installation method	RIGHT ANGLE
Installation type	BOARD AND PANEL
Shell material	STEEL, TIN PLATED
Terminal type	SOLDER
UL flammability code	94V-0

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0145

General Information

Part Number:

76650-0145

Manufacturer:

Title:

Description:

Product Family:

Certificates:

Molex / Waldom

LFH Matrix 50 Connector Kit

High Speed I/O Right Angle Plug, Receptacle and Hardware

LFH™ Matrix 50

(Molex Parts within this kit) - UL and CSA

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Current Rating:

Voltage Rating:

Wire size:

Product Highlights

The Low Force Helix (LFH) contact was designed for high-pin count signal

applications where there is a need for reliability and performance. Designed

for both cable-to-board and board-to-board applications, the system's low

insertion forces make it ideal for situations where multiple single lines need

to be terminated or packaged in a limited space. The patented "helix" plug pin

interfaces with a split-beam receptacle contact giving a low insertion force with

2-point contact reliability. Rated at 4 Gbps.

Features and Benefits

• High density contact interface, more

terminals in a smaller package

• High pin count, flexibility in many different

applications

• Low mating force, aids in the mating of the

final product

• Wire termination by weld or solder of

terminal sticks, ease of manufacturability

and reliability

• Shielded, protects signal integrity

• High cycle life 5,000 cycles

Applications

• Mainframe Computers

• Mass Storage

• Portable POS Units

• Network Interface Cards

• Routers

• Switches

• Audio, Video Editing and Storage

• Military Data Communication and Video

Equipment (cots)

• Medical Devices

(Wire-to-Board) and (Board-to-Board)

1.27mm (.050")

Plugs and Receptacles

Right Angle and Vertical

1 Amp

40 Volts

36-28 AWG

For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com

Page 1 of 2

70982-1003 Related Products

	70982-1003	62200-1500	71629-4000	76650-0145	70928-2001	62200-1100	51-24-2021	15-92-2250	70929-2000
Description	60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE	60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE	60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE	60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE	60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE	60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE	60 CONTACT(S), FEMALE, RIGHT ANGLE TELECOM AND DATACOM CONNECTOR, SOLDER, RECEPTACLE	60 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, SOLDER, PLUG	60 CONTACT(S), MALE, TELECOM AND DATACOM CONNECTOR, WELD OR SOLDER, PLUG
Contact materials	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Total number of contacts	60	60	60	60	60	60	60	60	60
Lead-free	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
EU RoHS regulations	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes	Yes
state	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE	ACTIVE
Options	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Shell style	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	RECEPTACLE	plug	plug
Manufacturer Series	70928	70928	70928	70928	70928	70928	70928	70929	70929
Contact surface matching	GOLD (30) OVER NICKEL	GOLD (30) OVER NICKEL	GOLD (30) OVER NICKEL	GOLD (30) OVER NICKEL	GOLD (30) OVER NICKEL	GOLD (30) OVER NICKEL	GOLD (30) OVER NICKEL	NOT SPECIFIED	MATTE Tin
Contact coated terminals	TIN (100) OVER NICKEL	TIN (100) OVER NICKEL	TIN (100) OVER NICKEL	TIN (100) OVER NICKEL	TIN (100) OVER NICKEL	TIN (100) OVER NICKEL	TIN (100) OVER NICKEL	NOT SPECIFIED	MATTE Tin
Connection Type	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	TELECOM AND DATACOM CONNECTOR	Telecommunications and Datacom Connectors	Telecommunications and Datacom Connectors
Connector male and female	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	FEMALE	Pin	Pin
collocation information	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE	MULTIPLE MATING PARTS AVAILABLE
Installation type	BOARD AND PANEL	BOARD AND PANEL	BOARD AND PANEL	BOARD AND PANEL	BOARD AND PANEL	BOARD AND PANEL	BOARD AND PANEL	BOARD AND PANEL	CABLE
Shell material	STEEL, TIN PLATED	STEEL, TIN PLATED	STEEL, TIN PLATED	STEEL, TIN PLATED	STEEL, TIN PLATED	STEEL, TIN PLATED	STEEL, TIN PLATED	POLYMER	POLYMER
Terminal type	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	SOLDER	welding	Welding and Solder
UL flammability code	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0	94V-0
insert material	GLASS FILLED POLYMER	GLASS FILLED POLYMER	GLASS FILLED POLYMER	GLASS FILLED POLYMER	GLASS FILLED POLYMER	GLASS FILLED POLYMER	GLASS FILLED POLYMER	-	Glass FILLED Liquid Crystal Polymer
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	-	-
