CQF915/608-19390 datasheet, PDF

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> CQF915/608-19390

CQF915/608-19390: DescriptionOptoelectronic Device; CategoryLED optoelectronic/LED photoelectric; File Size110KB，4 Pages; ManufacturerJDS Uniphase Corporation ( VIAVI ); Websitehttp://www.jdsu.com/index.html

Download Datasheet Parametric View All

CQF915/608-19390 Overview

Optoelectronic Device

CQF915/608-19390 Parametric

Parameter Name	Attribute value
Maker	JDS Uniphase Corporation ( VIAVI )
Reach Compliance Code	compli
Optoelectronic device types	OPTOELECTRONIC DEVICE

Preview

Download Datasheet

View All

Product Bulletin

CQF915/608 Series

1550 nm WDM DFB Lasers for

Direct Digital Modulation

The CQF915/608 is a high-power, directly

modulated laser source in a butterfly package for

metro WDM systems up to 180 km. The laser is

pigtailed with a single-mode fiber and shows

excellent thermal stability (e.g. wavelength drift

with case temperature is much better than

1 pm/°C). Dependence of the optical isolation on

case temperature is minimized by a cooled isolator.

The internal bias-T network and built-in monitor

diode enable simple DC-bias conditioning and

output power stabilization of the laser diode.

Under small signal modulation conditions, the

bandwidth of the device exceeds 3 GHz. Due to the

intrinsic low chirp characteristic of the DFB laser,

the device is especially suitable for digital

transmission at 1550 nm. Based on standard

single-mode fiber with non-zero dispersion, the

maximum dispersion penalty at BER = 10

-10

is less

than 1.5 dB, for a total dispersion of up to

3240 ps/nm at 1550 nm. Long-term wavelength

stability has been established by wavelength drift

tests.

Key Features

1550 nm (WDM) DFB laser diode

2.5 Gb/s suitable for OC-48/STM-16

Built-in cooled optical isolator

Wavelengths available from 1527 to 1610 nm

(C and L bands)

electrical impedance matching

180 km distance (3240 ps/nm dispersion at

1550 nm)
