Capacitance Change with Reference to +25°C and 0 VDC Applied (TCC)
Aging Rate (Max % Cap Loss/Decade Hour)
Dielectric Withstanding Voltage (DWV)
Dissipation Factor (DF) Maximum Limit @ 25ºC
Insulation Resistance (IR) Limit @ 25°C
-55°C to +200°C
±30 ppm/ºC
0%
150% of rated voltage for voltage rating of < 1,000 V
120% of rated voltage for voltage rating of ≥ 1,000 V
(5 ±1 seconds and charge/discharge not exceeding 50 mA)
0.1%
1,000 MΩ microfarads or 100 GΩ
(500 VDC applied for 120 ±5 seconds @ 25°C)
Parameters/Characteristics
To obtain IR limit, divide MΩ-µF value by the capacitance and compare to GΩ limit. Select the lower of the two limits.
Capacitance and dissipation factor (DF) measured under the following conditions:
1 MHz ±100 kHz and 1.0 Vrms ±0.2 V if capacitance ≤ 1,000 pF
1 kHz ±50 Hz and 1.0 Vrms ±0.2 V if capacitance > 1,000 pF
Note: When measuring capacitance it is important to ensure the set voltage level is held constant. The HP4284 and Agilent E4980 have a feature known as
Automatic Level Control (ALC). The ALC feature should be switched to "ON."
Post Environmental Limits
High Temperature Life, Biased Humidity, Moisture Resistance
Dielectric
C0G
Rated DC Voltage Capacitance Value
All
All
DF (%)
0.5
Cap Shift
IR
0.3% or ±0.25 pF 10% of Initial Limit
Ultimate Voltage Breakdown (UVBD) – Typical Mean Breakdown Voltage Ratings
Table 1 – Pulse Detonation Series, Capacitance Range Waterfall
Case Size (in.)
Length
Width
Thickness
Max.
Bandwidth
mm
(in.)
mm
(in.)
mm
(in.)
mm
(in.)
2824
7.10 ± 0.40
(0.280 ± 0.016)
6.10 ± 0.40
(0.240 ± 0.016)
2.5
(0.098)
0.76 ± 0.40
(0.030 ± 0.016)
C
B
D
F
1.5K 1.8K 2.5K 3.5K
3040
7.60 ± 0.40
(0.300 ± 0.016)
10.20 ± 0.40
(0.402 ± 0.016)
2.5
(0.098)
0.76 ± 0.40
(0.030 ± 0.016)
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
3640
9.10 ± 0.40
(0.358 ± 0.016)
10.20 ± 0.40
(0.402 ± 0.016)
2.5
(0.098)
0.76 ± 0.40
(0.030 ± 0.016)
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
4040
10.20 ± 0.40
(0.402 ± 0.016)
10.20 ± 0.40
(0.402 ± 0.016)
2.5
(0.098)
0.76 ± 0.40
(0.030 ± 0.016)
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
4540
11.40 ± 0.40
(0.449 ± 0.016)
10.20 ± 0.40
(0.402 ± 0.016)
2.5
(0.098)
0.76 ± 0.40
(0.030 ± 0.016)
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
G
4K
Rated Voltage (VDC)
Voltage Code
Breakdown Voltage (VDC)
500 630
1K
1.5K 2K 500 630
1K
1.5K 2K 500 630
1K
1.5K 2K 500 630
1K
1.5K 2K 500 630
1K
1.5K 2K
Capacitance
5,600pF
6,800pF
8,200pF
0.01µF
0.012µF
0.015µF
0.018µF
0.022µF
0.027µF
J = ±5%
0.033µF
K = ±10%
0.039µF
M = ±20%
0.047µF
0.056µF
0.062µF
0.068µF
0.072µF
0.082µF
0.1µF
0.12µF
0.15µF
Rated Voltage (VDC)
Voltage Code
Breakdown Voltage (VDC)
1
Capacitance
Tolerance
Capacitance Code (Available Maximum Capacitance)
1
682
562
103
153
223
333
473
683
104
500 630
1K
1.5K
C
B
D
F
1.5K 1.8K 2.5K 3.5K
2K 500 630
1K
1.5K
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
683
473
623
723
124
2K 500 630
1K
1.5K
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
104
154
2K 500 630
1K
1.5K
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
104
154
2K 500 630
1K
1.5K
G
C
B
D
F
4K 1.5K 1.8K 2.5K 3.5K
2K
G
4K
683
153
123
223
153
273
183
Only maximum available CV (capacitance /voltage) values are highlighted. Lower CV values are available upon request. Please contact KEMET to discuss your
specific CV requirement.
These products are protected under US Patents 7,172,985 and 7,670,981, other patents pending, and any foreign counterparts.
