10mm SOLID STATE LAMPS
L-813ID HIGH EFFICIENCY RED
L-813ED ORANGE
L-813GD GREEN
L-813YD YELLOW
Features
!
10mm DIAMETER BIG LAMP.
!
LOW POWER CONSUMPTION.
!
RELIABLE AND RUGGED.
!
LONG LIFE - SOLID STATE RELIABILITY.
Description
The High Efficiency Red and Orange source color devices
are made with Gallium Arsenide Phosphide on Gallium
Phosphide Orange Light Emitting Diode.
The Green source color devices are made with Gallium
Phosphide Green Light Emitting Diode.
The Yellow source color devices are made with Gallium
Arsenide Phosphide on Gallium Phosphide Yellow Light
Emitting Diode.
Package Dimensions
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: KDA0034
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: SEP/30/2001
DRAWN: X.M.Zhou
PAGE: 1 OF4
Selection Guide
Iv (m c d )
@ 20 m A
Min .
L-813ID
L-813ED
L-813GD
L-813YD
HIGH EFFICIENCY RED (GaAsP/GaP)
ORANGE (GaAsP/GaP)
GREEN (GaP)
YELLOW (GaAsP/GaP)
RED DIFFUSED
ORANGE DIFFUSED
GREEN DIFFUSED
YELLOW DIFFUSED
40
40
20
20
Ty p .
100
100
60
50
V i ew i n g
An g l e
2θ1/2
60 °
60 °
60 °
60 °
Par t No .
Dic e
L en s Ty p e
Note:
1.
θ1/2
is the angle from optical centerline where the luminous intensity is 1/2 the optical centerline value.
Electrical / Optical Characteristics at T
)
=25°C
°
Sy m b o l
Par am et er
D ev i c e
High Efficiency Red
Orange
Green
Yellow
High Efficiency Red
Orange
Green
Yellow
Ty p .
627
627
565
590
625
625
568
588
45
45
30
35
15
15
15
20
2.0
2.0
2.2
2.1
2.5
2.5
2.5
2.5
10
Max .
Un it s
Tes t Co n d it io n s
λ
peak
Peak Wavelength
nm
IF=20mA
λ
D
Dominate Wavelength
nm
IF=20mA
∆λ
1/2
High Efficiency Red
Oa
Spectral Line Halfwidth Grenge
r en
Yellow
Capacitance
High Efficiency Red
Orange
Green
Yellow
High Efficiency Red
Orange
Green
Yellow
All
nm
IF=20mA
C
pF
VF=0V;f=1MHz
V
F
I
R
Forward Voltage
V
IF=20mA
Reverse Current
uA
V R = 5V
Absolute Maximum Ratings at T
)
=25°C
°
Par am et er
Power dissipation
DC Forward Current
Peak Forward Current [1]
Reverse Voltage
Operating/Storage Temperature
Lead Solder Temperature [2]
Notes:
1. 1/10 Duty Cycle, 0.1ms Pulse Width.
2. 4mm below package base.
H i g h E f f i c i en c y
R ed
105
30
160
5
Or an g e
105
30
160
5
Gr een
105
25
140
5
-40
°
C To +85
°C
260
°
C For 5 Seconds
Yello w
105
30
140
5
Un it s
mW
mA
mA
V
SPEC NO: KDA0034
APPROVED : J. Lu
REV NO: V.1
CHECKED :
DATE: SEP/30/2001
DRAWN: X.M.Zhou
PAGE: 2 OF4
