RCR
anti-surge power type leaded resistor
resistors
EU
features
•
Excellent anti-surge characteristics
•
Stable characteristics of moisture resistance
up to high resistance range.
•
RCR50 +(1MΩ - 12MΩ), RCR50EN (1MΩ - 12MΩ) and
RCR60 (1MΩ - 12MΩ) are discharge resistors recognized
by UL1676 and c-UL(CSA-C22.2 No.1-M94).
•
RCR50EN (100kΩ - 33MΩ) and RCR60 (470kΩ - 56MΩ)
is approved by EN60065 14.1 safety. There is the case that
RCR50EN cannot meet CLASS II depending on a use.
•
Marking: Blue-gray body color with color-coded bands
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
•
Surface mount style “N” forming is suitable for automatic mounting
Type
L
t
D
Trimming Line
Ceramic Core
t
d
l
RCR16
RCR25
L
.126±.008
(3.2±0.2)
.248±.02
(6.3±0.5)
Dimensions
inches
(mm)
D
d (nom.)
C (max.) t (max.)
.134
(3.4)
.28
(7.1)
—
—
.067
+.008
-.004
(1.7
+0.2
)
-0.1
.098±.02
(2.5±0.5)
.138±.016
(3.5±0.4)
.157±.02
(4.0±0.5)
.236
+.039
-.016
(6.0
+1.0
-0.4
)
dimensions
and construction
l*
.018
(0.45)
.024
(0.6)
.028
(0.7)
.031
(0.8)
.031
(0.8)
J
Tolerance
F: ±1%
J: ±5%
.787 Min.
(20.0 Min.)
RCR50(+)
.374±.039
RCR50EN
(9.5±1.0)
Marking
Resistive
Film
End
Cap
Lead
Wire
RCR60
RCR75
.374
+.039
-.004
(9.5
+1.0
)
-0.2
.472±.039
(12±1.0)
—
—
A
—
.118
(3.0)
.118
(3.0)
.118
(3.0)
Flame Retardant Coating
C
* Lead length changes depending on taping and forming.
ordering information
New Part #
RCR
Type
RCR
50
Power
Rating
16: 0.25W
25: 0.25W
50: 0.5W
60: 1W
75: 2W
100: 3W
RCR100
.610±.039
(15.5±1.0)
T52
Taping and Forming
RCR16: T26, T52
RCR25: T26, T52
RCR50(+, EN): T52
RCR60: T52
RCR75: T52
RCR100: T521, T631
L,M Forming
EN
Safety Appr.
Marking
RCR50+: +
RCR50EN:
EN
Blank:
Others
C
Termination
Material
C: SnCu
105
Nominal
Resistance
2 significant
figures + 1
multiplier for ±5%
3 significant
figures + 1
multiplier for ±1%
Packaging
A: Ammo
R: Reel
TEB: Plastic
embossed:
N forming
applications and ratings
Part
Designation
RCR16
RCR25
RCR50
RCR50+
RCR50EN
RCR60
RCR75
RCR100
1.0W
2.0W
3.0W
1000V
0.5W
700V
1MΩ - 9.1MΩ
100kΩ - 9.1MΩ
100kΩ - 9.1MΩ
100kΩ - 9.1MΩ
100kΩ - 9.1MΩ
0.25W
Power
Rating
@ 70°C
Minimum
Dielectric
Withstanding
Voltage
300V
Resistance
Range
E-24, E-96
(F±1%)
100kΩ - 1MΩ
100kΩ - 9.1MΩ
3.3Ω - 910kΩ
Resistance
Range
E-24
(J±5%)
100kΩ - 5.1MΩ
100kΩ - 33MΩ
3.3Ω - 910kΩ
13MΩ - 33MΩ
1MΩ - 12MΩ
100kΩ - 33MΩ
100kΩ - 56MΩ
100kΩ - 100MΩ
100kΩ - 33MΩ
Absolute
Maximum
Working
Voltage
500V
DC 1600V
AC 1150V
Absolute
Maximum
Overload
Voltage
1000V
DC 2000V
AC 1500V
Operating
Temperature
Range
2000V
2500V
-55°C to +155°C
4000V
5000V
5000V
For further information on packaging, please refer to Appendix C.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
12/18/12
116
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
anti-surge power type leaded resistor
environmental applications
Derating Curve
100
80
% Rated Power
60
40
20
0
-60 -40 -20
-55
Notice of Surge Load
Surge withstanding load voltage for the resistors cannot be guaranteed when
the undermentioned 4 items get to a remarkable overload in comparison with
the conditions shown by surge withstanding voltage in Anti-surge
characteristics. Please contact KOA in advance if such a case is anticipated.
1. Peck voltage to be applied
2. Pulse width
3. Conditions of protecting insulation around the resistor
4. Situation of proximity conductivity object
10kV
0
20
40
60
80 100 120 140
70
Ambient Temperature
(°C)
160
155
For resistors operated at an ambient temperature
of 70°C or above, a power rating shall be derated
in accordance with the above derating curve.
For example: In the figure, a metal wire is placed
less than 5mm away from the resistor body,
Discharge
there is such a case that causes an electric
discharge by a surge load 10kV and then
destroys the outer coating.
About 5mm
Metal Wire
Performance Characteristics
Parameter
Resistance
Type
RCR16
RCR25
T.C.R.
RCR50 (+)
RCR50EN
RCR60
RCR75
RCR100
Overload
Resistance to Solder Heat
Terminal Strength
Rapid Change of Temperature
Moisture Resistance
Endurance @ 70°C
Resistance to Solvent
Requirement
∆
R ±(% + 0.05Ω)
Limit
Within regulated tolerance
T.C.R.
Resistance Range
±200ppm/°C 100kΩ - 5.1MΩ
±350ppm/°C
100kΩ - 33MΩ
±500ppm/°C
3.3Ω - 91kΩ
±350ppm/°C
100kΩ - 33MΩ
±350ppm/°C
100kΩ - 33MΩ
±350ppm/°C
100kΩ - 56MΩ
±350ppm/°C 100kΩ - 100MΩ
±200ppm/°C 100KΩ - 33MΩ
1%
1%
No mechanical damage
1%
5%
5%
No visible damage to protective coating
and marking
Typical
Test Method
—
Measuring points are 10mm ± 1mm from the end cap
—
Room temperature/100°C up
0.5%
0.5%
—
0.5%
2.5%
2.5%
—
Rated voltage x 2.5 or maximum overload voltage
for 5 seconds, whichever is less
260°C ± 5°C, 10 seconds ± 1 second or 350°C ± 10°C,
3.5 seconds ± 0.5 seconds
Twist 360°, 5 times
-55°C (30 minutes)/+155°C (30 minutes), 5 cycles
40°C ± 2°C, 90-95% RH, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
RCR16, 25, 50 (+), 60: W; RCR75, 100: Wx0.1
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
Isopropyl alcohol with ultrasonic washing, 2 minutes
Power: 0.3W/cm
2
, f: 28kHz, Temperature: 35°C ± 5°C
Discharge test: 2kV - 10kV, 0.01µF capacitor discharge
pulse, 10 times (1 pulse/5 seconds maximum)
Type RCR16 RCR25 RCR50, RCR50+
RCR50EN,
RCR60, RCR75,
RCR100
Surge Withstanding
10%
2.5%
Applied
Voltage
2kV
3kV
3.3Ω - 6.2Ω: 10kV
6.8Ω - 10Ω: 7kV
11Ω - 9.1kΩ: 5kV
10kΩ - 91kΩ: 7kV
100kΩ - 33MΩ: 10kV
10kV
EN60065 Test
(RCR50EN, RCR60 only)
20%
—
Discharge test: 10kV, 1000pF capacitor discharge pulse,
50 times (1 pulse/5 seconds maximum)
12/18/12
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
117
