Datasheet for 76650-0006
General Information
Part Number:
76650-0006
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
I-Pass Connector Kit
SMT High Speed I/O
iPass™
(Molex Parts within this kit) - EU and China RoHS Compliant
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire:
Product Highlights
The SMT design provides placement options on both sides of the PCB, as well as
placement stability. With a pitch of 0.8mm (.031"), the design also allows for easy
routing. Plus, standoffs allow for easy PCB cleaning after soldering.
The iPass Interconnect System offers both connectors and cable assemblies
that enable flexible speed compatibility for applications ranging from 1.5G up
through 10G, and is an ideal interconnect solution for the growing server
storage market.
Wire-to-Board
0.8mm (0.031”)
Receptacle
Right Angle
26
0.5 Amps
30 Volts AC(RMS)/DC
Use iPass™ Cables 74547 Series
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0006
Features and Benefits
• Multiple guide rail configurations provide
board design flexibility
• Diecast guide rail provides robust chassis-
to-chassis interface
• Guide frame gaskets provide improved
EMI performance
• Screw attachment for the guide rail to PCB
provides a durable I/O connection during
the cable management process
• Designed for placement beneath guide
frame for external applications
• High-temperature thermoplastic for lead-
free processing
• Alignment posts provide stability for
placement on the PCB
• Standoffs allow for easy PCB cleaning
after soldering
• SMT design allows for ease of routing and
provides the option for placement on both
sides of the PCB
Bill of Materials for Part No. 76650-0006
Country
Molex Part No. of Origin
75586-0009
74548-0205
74548-0208
74548-0211
USA
China
China
China
Description
I-Pass 26 Circuit SMT Right Angle Ext.
I-Pass Guide Frame 1x4 Port Size, Port Keying 4
I-Pass Guide Frame 1x2 Port Size, Port Keying 4
I-Pass Guide Frame 1x1 Port Size, Port Keying 4
Quantity in
Kit
10
1
1
4
Applications
• HBAs (Host Bus Adapters) Servers
• Storage Racks
• Switches and Routers
• RAID (Redundant Array of Independent Disks)
• JBOD (Just a Bunch of Disks)
• Industrial Computers and Work Stations
• Removable Media Drives and Memory Modules
• Graphic Subsystems
• Networking
• Base Station
• Enterprise Routers and Switches
• Inverse Mux
• Network Interface Cards
No Recommended Molex Tool for Part No. 76650-0006
