76650-0083 Overview

Vertical Header and Receptacle, 4 Circuit

Preview

Download Datasheet

View All

1801 Morgan Street

Rockford, Illinois 61102

800-435-2931

www.molexkits.com

Datasheet for 76650-0083

General Information

Part Number:

Manufacturer:

Title:

Description:

Product Family:

Certificates:

76650-0083

Molex / Waldom

Mini-Fit Jr. Connector Kit

Vertical Header and Receptacle, 4 Circuit

Mini-Fit Jr.™

(Molex parts within this kit) - EU and China RoHS, UL, CSA and TUV

Country of Origin:

Kit assembled in U.S.A.

Specifications

Design

Configuration:

Pitch:

Connector Type:

Mounting

Orientation:

Circuit Sizes:

Current Rating:

Voltage:

Wire size:

Product Highlights

The Mini-Fit Jr. Series is designed for high current/high density applications. The

Mini-Fit Jr. is appropriate for both power and signal applications. The Mini-Fit

product family accepts the same terminals and application tooling, further reducing

your design and qualification effort.

Features and Benefits

• Fully isolated terminals

• Positive housing locks

• Four point of contact for reliability

• Low engagement force terminals

Applications

• Security and Alarms

• Vending and Gaming Machines

• White Goods

• Production Equipment

• Broadcast Equipment

• Telecom Infrastructure

Wire-to-Board

4.2mm (.165")

Receptacles and Vertical Headers

Vertical

4

6 Amps

600 Volts

24-18 AWG

For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com

Page 1 of 2
