780-555
Rubber Covers for Tactical
Equipment and Field Instruments
– These friction-fit covers provide dust
and splash protection.
Two Tether Styles
– Choose ring
terminals for attachment to a panel,
or choose slip knots for cable
attachment.
-55° to +125° Temperature Range
MATERIALS & FINISHES
Cover
Cord
Ring
Terminal
Slip Collar
Crimp Ring
SBR Rubber Per ASTM
D2000 Type C
Nylon Per MIL-C-43307
Stainless Steel
Kynar
Copper, Black Oxide
Finish
Fits Metal Shell
M83513 Type
Connectors
HOW TO ORDER 780-555 RUBBER PROTECTIVE COVERS
Series
780-555
Connector
Layout
9P
15P
21P
25P
31P
37P
51P
51-2P
67P
69P
100P
9S
15S
21S
25S
31S
37S
51S
51-2S
67S
69S
100S
Nylon Cord Option
Omit
–
(leave blank)
Cover only, no cord
Nylon Cord
Length
Length in One
Inch Increments
Example: “6” equals
six inches.
±
.250 Inches
±
6.35 mm
Attachment Option
Ring Terminal
06
–
.125 (3.2) I.D.
01
–
.140 (3.6) I.D.
05
–
.167 (4.2) I.D.
04
–
.197 (5.0) I.D.
Rubber Type
Omit
Standard
Rubber
G
–
Nylon Cord
C
Conductive
Rubber
SK
–
Slip Knot
Sample Part Number
780-555
37P
G
.40 (10.2)
.25 (6.4) MAX
.310 (7.9) MAX
RING
TERMINAL
4
– SK
LENGTH
LENGTH
DETERMINED AT
.50 (12.7) DIA.
B
SLIP
A
A Max.
Layout
9P, 9S
15P, 15S
21P, 21S
25P, 25S
31P, 31S
37P, 37S
In.
.830
.980
1.130
1.230
1.380
1.530
mm.
21.08
24.89
28.70
31.24
35.05
38.86
In .
KNOT
B Max.
mm.
A Max.
Layout
51P, 51S
51-2P, 51-2S
67P, 67S
69P, 69S
100P, 100S
In.
1.480
1.880
2.770
1.780
2.215
mm.
37.59
47.75
70.36
45.21
56.26
In .
B Max.
mm.
.370
.370
.370
.370
.370
.370
9.40
9.40
9.40
9.40
9.40
9.40
.410
.370
.370
.410
.460
10.41
9.40
9.40
10.41
11.68
© 2011 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
N-7
Micro-D
Accessories
“Marshal Bean”
Protective Rubber Covers with Tether Rope
