Datasheet for 76650-0149
General Information
Part Number:
76650-0149
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
Sealed USB and RJ-45 Industrial Connector and Cable Kit
Sealed Bayonet-Style Plug Receptacle and Cable
Industrial USB and RJ-45
(Molex Parts within this kit) - EU RoHS Compliant
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Connector Type:
Mounting
Orientation:
Current Rating:
Voltage:
Product Highlights
Industrial USB (Universal Serial Bus) connectors bring one of the most popular and
convenient I/O connectors into harsh commercial and industrial environments. USB
connectors are ideal for both short-term diagnostics (that require simple and fast
setup), without having to turn off computers or equipment, and permanent
installations for data acquisition systems. The rugged, plug and receptacle designs
feature bayonetstyle latches, encapsulated PCB receptacles and overmolded cable
assemblies to help keep out dust, debris and water.
Ethernet connectors are of Category 5e transmission performance and TIA/EIA-568-
B (RJ-45) connection interface. RJ-45 EtherNet/IP* Cordsets and Receptacles are
ideal for use in environments where EtherNet protocol is used, including
manufacturing facilities, water treatment plants and transportation hubs. Designed
with one sealing surface, the connectors ensure optimum performance even in
harsh environments.
*EtherNet/IP and †DeviceNet are trademarks of the Open DeviceNet Vendor Association.
(Wire-to-Board) and (Wire-to-Wire)
Receptacles and Plugs, Cables
Vertical (Receptacles)
1 Amp and 1.5 Amps
30 VoltsAC (RMS) and 125 Volts
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 3
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0149
Features and Benefits
• IP67 and NEMA 6P Rating ensures
cordsets are water and dust tight for
functional integrity
• Fully shielded cable provides Electro
Magnetic Interference/Radio Frequency
Interference (EMI/RFI) protection
• Over molded cordsets, allow faster
installation at customer site versus field-
wireable designs
Features and Benefits continued
• Bayonet-style latch receptacle provides
quick and easy connection and ensures
proper insertion depth with mating
• Ease-of-use
• Meets Open DeviceNet † Vendors’
Association and ControlNet ‡ Vendors’
Association IP Specifications
• One Sealing Surface means less
likelihood of failure
• Easy termination allows custom length
cable to be made in field
• Robust bayonet style lock
• Simple error free mating
Applications
• Factory Automation
• Industrial Computers
• Industrial Controllers
• Factory Peripherals
• Printers
• Barcode Scanners
• Robotics
• Vision Systems
• Motion and Process Controls
Applications continued
• Test and Measurement Equipment
• Medical Devices
• Factory Networking Installations
• Production Equipment
• Industrial Environment: Food and Beverage,
Automotive, Chemical and Other continuous
and batch processes
• Water Treatment plants: Waste water, Municipal
drinking water
• Transportation Hubs: Airports, Bus Stations, Rail
Stations
• Metal and explosive detectors
• EDS's (Explosive Detection System)
• ETD's (Explosive Trace Detector)
*EtherNet/IP and †DeviceNet are trademarks of the Open DeviceNet Vendor Association.
‡ ControlNet is a trademark of ControlNet International, Ltd.
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 2 of 3
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0149
Bill of Materials for Part No. 76650-0149
Country
Molex Part No. of Origin
84729-0001
84729-0004
84729-0009
84730-0001
84700-0001
84700-0002
84700-0003
84702-0005
84702-0006
Description
0.5 Ft Long, 28 AWG 5C Pigtailed, USB Type A, Panel
Taiwan
Mount Receptacle
2.62 Ft Long USB Type A, Panel Mount, Receptacle to Plug,
Taiwan
Cordset
Quantity in
Kit
1
1
1
1
1
1
1
1
1
Taiwan
USB Type A, Panel Mount PCB, Receptacle
Mexico
USB Type B Panel Mount PCB Receptacle
Mexico
Receptacle Panel Mount Assembly RJ-45 CAT5e
Mexico
Plug Field Wireable Assembly RJ-45 CAT5e
Mexico
Dust Cover for RJ-45 Bayonet-Style Latch Connector
Mexico
Receptacle PCB Mount Assembly RJ-45 CAT5e
Mexico
Receptacle Punchdown Panel Mount RJ-45 CAT5e
No Recommended Molex Tool for Part No. 76650-0149
