1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0142
General Information
Part Number:
76650-0142
Manufacturer:
Title:
Description:
Product Family:
Certificates:
Molex / Waldom
Sealed USB Industrial Connector and Cable Kit
USB Type A and B Shielded Panel Mount Plug, Receptacle and Cable, IP-67
Industrial USB
(Molex Parts within this kit) - EU RoHS Compliant, UL, CSA and TUV
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Connector Type:
Mounting
Orientation:
USB Type:
Current Rating:
Voltage:
Product Highlights
Industrial USB (Universal Serial Bus) connectors bring one of the most popular and
convenient I/O connectors into harsh commercial and industrial environments. USB
connectors are ideal for both short-term diagnostics (that require simple and fast
setup), without having to turn off computers or equipment, and permanent
installations for data acquisition systems. The rugged, plug and receptacle designs
feature bayonet style latches, encapsulated PCB receptacles and over molded
cable assemblies to help keep out dust, debris and water.
Features and Benefits
• IP67 Rating ensures cordsets are
water and dust tight for functional integrity
• Fully shielded cable provides Electro
Magnetic Interference/Radio Frequency
Interference (EMI/RFI) protection
• Over molded cordsets, allow faster
installation at customer site versus field-
wireable designs
• Bayonet-style latch receptacle provides
quick and easy connection and ensures
proper insertion depth with mating
• Ease-of-use
Applications
• Factory Automation
• Industrial Computers and Controllers
• Factory Peripherals
• Printers
• Barcode Scanners
• Robotics
• Vision Systems
• Motion and Process Controls
• Test and Measurement Equipment
• Medical Devices
• Factory Networking Installations
• Production Equipment
(Wire-to-Board) and (Wire-to-Wire)
Receptacles and Plugs, Cables
Vertical (Receptacles)
A and B
1 Amp
30 VoltsAC (RMS)
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 1 of 2
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0142
Bill of Materials for Part No. 76650-0142
Country
Molex Part No. of Origin
84727-1005
84728-1005
84729-0001
84729-0004
84729-0009
84730-0001
84732-0001
Description
Quantity in
Kit
1
1
1
1
1
1
1
Mexico
0.5 Ft Long, 5C Pigtailed, USB Type A, Plug, Shielded
Mexico
0.5 Ft Long, 5C Pigtailed, USB Type B, Plug, Shielded
0.5 Ft Long, 28 AWG 5C Pigtailed, USB Type A, Panel
Taiwan
Mount Receptacle
2.62 Ft Long USB Type A, Panel Mount, Receptacle to Plug,
Taiwan
Cordset
Taiwan
USB Type A, Panel Mount PCB, Receptacle
Mexico
USB Type B Panel Mount PCB Receptacle
31.5" Long, Dual USB Type A to Type B Plug Coupler
Mexico
Cordset
No Recommended Molex Tool for Part No. 76650-0142
For additional Molex / Waldom Design and Solution Kits please go to www.molexkits.com
Page 2 of 2
