PIN RECEPTACLES
With Organic Fibre Plug® Solder Barrier
(see specific contact range on pages 220 - 228)
PR
E
CI
M
ON
S
I
CHI
A
PINS
NE
D
0337
0,51
4280
1,98 DIA.
1,57 DIA.
0,51
2,26
5280
2,16 DIA.
1,57 DIA.
1,42 DIA.
0,23
1,3 DIA.
0,23
1,14
2,26
2,54
0332
0,46
1,98 DIA.
1,47 DIA.
2,24 2,54
2,29
DIA.
1,83 DIA.
1,57
2,67
2,54
1,42 DIA.
1,19 DIA.
0,23
1,3 DIA.
1,55 DIA.
0,23
0337-0-XX-XX-15-XX-10-0
4280-0-XX-XX-16-XX-10-0
5280-0-XX-XX-16-XX-40-0
0332-0-XX-XX-18-XX-10-0
Solder mount in Ø1,68±0,08 PTH. Solder mount in Ø1,7±0,08 PTH.
Solder mount in Ø1,7±0,08 PTH. Solder mount in Ø2,01±0,08 PTH.
#15
Contact for Ø0,51-0,81 pins.
#16
Contact for Ø0,56-0,86 pins.
#16
Contact for Ø0,56-0,86 pins.
#18
Contact for Ø0,94-1,09 pins.
Also available on 8mm wide carrier Also available on 8mm wide carrier Also available on 16mm wide carrier Also available on 16mm wide carrier
tape: 6,000 parts per 330mm reel. tape: 6,000 parts per 330mm reel. tape: 2,200 parts per 330mm reel. tape: 2,200 parts per 330mm reel.
0479
0,46
2,29
DIA.
0375
0,76
0353
0,76
3,18 DIA.
0384
0,71
3,05 DIA.
4,52 4,88
2,54 DIA.
2,01 DIA.
2,72 3,05
1,83
DIA.
3,56
2,49 DIA.
2,46 DIA.
3,15
3,56
1,63
DIA.
0,23
1,73 DIA.
0,23
1,98 DIA.
0,23
2,24 DIA.
0,23
0479-0-XX-XX-34-XX-10-0
0375-0-XX-XX-02-XX-10-0
0353-0-XX-XX-03-XX-10-0
0384-0-XX-XX-23-XX-10-0
Solder mount in Ø1,96±0,08 PTH. Solder mount in Ø2,21±0,08 PTH. Solder mount in Ø2,69±0,08 PTH. Solder mount in Ø2,67±0,08 PTH.
#02
Contact for Ø1,02-1,27 pins.
#34
Contact for Ø0,81-1,17 pins.
#03
Contact for Ø1,02-1,52 pins.
#23
Contact for Ø1,14-1,65 pins.
Also available on 16mm wide carrier Also available on 12mm wide carrier Also available on 12mm wide carrier Also available on 12mm wide carrier
tape: 2,200 parts per 330mm reel. tape: 4,500 parts per 330mm reel. tape: 1,300 parts per 330mm reel. tape: 2,000 parts per 330mm reel.
0376
0,76
3,56 DIA.
3,18 DIA.
3,96 4,6
0321
0,76
3,96
DIA.
3,45
DIA.
3,63 4,19
3435
1,83 DIA.
1,63 DIA.
1,55
DIA.
0,76
2,24
3,30
5,33
1,09 DIA.
2,72 DIA.
0,46
3,1
DIA.
0,46
0,91 DIA.
0,23
0376-0-XX-XX-07-XX-10-0
0321-0-XX-XX-08-XX-10-0
3435-0-XX-XX-47-XX-04-0
Solder mount in Ø3,38±0,08 PTH. Solder mount in Ø3,66±0,08 PTH. Solder mount in Ø1,17±0,08 PTH.
#08
Contact for Ø2,13-2,59 pins.
#47
Contact for Ø0,64-0,91 and
#07
Contact for Ø1,65-2,08 pins.
0,64 square pins.
Also available on 16mm wide carrier Also available on 16mm wide carrier
tape: 1,500 parts per 330mm reel. tape: 1,700 parts per 330mm reel.
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
SOLDER BARRIER:
Organic Fibre Plug®
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±0,13
DIAMETERS: ±0,05
ANGLES:
± 2°
ORDER CODE: XXXX - 0 - XX - XX - XX - XX -XX - 0
BASIC PART #
SPECIFY PACKAGING:
SPECIFY CONTACT FINISH:
27
0,76μm GOLD OVER NICKEL (RoHS)
43
Discrete Receptacles
67
Supplied on 330mm Reels
01
5,08μm TIN/LEAD OVER NICKEL
80
5,08μm TIN OVER NICKEL (RoHS)
SPECIFY SHELL FINISH:
01
5,08μm TIN/LEAD OVER NICKEL
RoHS
80
5,08μm TIN OVER NICKEL (RoHS)
CONTACT
2002/95/EC
#02,#07,#08,#15,#16,#18,#23,#34 or #47
CONTACT (DATA ON PAGES 220 - 228)
w w w. m i l l - m a x . c o m
165
516-922-6000
