M2403 Series
SPECIFICATION FOR 2.5 x 3.2 mm SMT CRYSTAL OSCILLATOR
Ordering Information:
Product Series
(Supply Voltage Option)
Temperature Range
Code
6
M2403
2
Value
-20 to +70 °C
-40 to +85 °C
Stability
Code
3
4
5
6
Example: M240324TCN 25.000000 MHz
M2403
2
Value
±100 ppm
± 50 ppm
± 35 ppm
± 25 ppm
4
T
C
N
25.000000
Output Type
Code
F
Q
T
Value
Fixed
Standby
Tristate
G
40/60
CMOS
Symmetry
Code
C
Value
45/55
CMOS
Package/Lead
Configuration
Code
N
Value
Leadless
Frequency
MHz
xxx.xxxxxx
Electrical Specifications:
Parameter
Frequency of Operation
Frequency Stability
Output Type
Output Load
Symmetry (duty cycle)
Logic “1” Level
Logic “0” Level
Rise/Fall Time
Start-Up Time
Standby Current
Tristate or Standby Function
Symbol
F
O
F/F
Min.
1
Typ.
Max.
66
Units
MHz
ppm
Conditions
Frequency Stability
See Ordering Information
Output
HCMOS Compatible
15
T
DC
V
OH
V
OL
T
R
/T
F
See Ordering Information
90% V
DD
10% V
DD
10
10
50
Logic (70% V
DD
min) or floating
Logic (30% V
DD
max) to a high-Z state
pF
%
V
V
ns
ms
A
Ref to ½ V
DD
HCMOS load
HCMOS load
1 – 66 MHz
Standby Mode
Pad 1: Enables output
Pad 1: Disables output
3.465
6
15
10
1.5
1.2
1.0
0.8
0.7
0.5
0.5
0.4
V
mA
mA
ps
ps
ps
ps
ps
ps
ps
ps
ps
M2403
1.000 – 20.000 MHz
20.001 – 66.000 MHz
@ 1M (12 kHz to 1 MHz)
@ 20M (12 kHz to 20 MHz)
@ 25M (12 kHz to 20 MHz)
@ 30M (12 kHz to 20 MHz)
@ 40M (12 kHz to 20 MHz)
@ 50M (12 kHz to 20 MHz)
@ 66M (12 kHz to 20 MHz)
@ 70M (12 kHz to 20 MHz)
@ 100M (12 kHz to 20 MHz)
Supply Voltage & Power Consumption
Supply Voltage
Supply Current
V
DD
I
DD
3.135
3.300
Additional Specifications
Phase Jitter
1 of 3
M2403 Series
SPECIFICATION FOR 2.5 x 3.2 mm SMT CRYSTAL OSCILLATOR
Environmental & Mechanical Requirements:
Operating Temperature
Storage Temperature
Mechanical Shock
Vibration
Thermal Cycle
Hermeticity
Solderability
Max. Soldering Conditions
Package Type
T
A
See Ordering Information
°C
T
S
-55
+125
°C
Per MIL-STD-202, Method 213, Condition C (100 g’s, 6 ms duration, ½ sinewave)
Per MIL-STD-202, Method 201 & 204 (10 g’s from 10-2000 Hz)
Per MIL-STD-883, Method 1010, B (-55°C to 125°C, 15 min. dwell, 10 cycles)
Per MIL-STD-202, Method 112 (1 x 10
-8
atm cc/s of Helium)
Per EIAJ-STD-002
See solder profile, Figure 1
4-pad 2.5 X 3.2 X 1.2 mm leadless ceramic. RoHS compliant.
Dimensions, Marking, and Pin Out Information:
Pad
1
2
3
4
Function
Tristate, Standby or N/C
Ground
Output
+V
DD
Part Marking (MHz range)
Line 1
xxxMxxx
Line 2
M ywwv
xxxMxxx
y
ww
v
Legend
Frequency in MHz
Year
Work week
Factory code
Note : Layout should include 0.01 µF or larger bypass capacitor between +Vdd and ground.
2 of 3
M2403 Series
SPECIFICATION FOR 2.5 x 3.2 mm SMT CRYSTAL OSCILLATOR
Reflow Soldering Conditions:
Figure 1
Tape and Reel Specifications:
All dimensions are in mm.
A
3
B
3.7
C
1.5
D
3.5
E
1.4
F
4
G
4
H
8
J
250
K
13
L
21
M
60
MtronPTI reserves the right to make changes to the product(s) and service(s) described herein without notice.
No liability is assumed as a result of their use or application.
Rev.0 09/11/17
3 of 3
