Connection Systems
Receptacles
DC Micro Male, 4-Pin, 5-Pin or 8-Pin
Specifications
Receptacle Shell
Connector Insert
Contacts
Wire insulation
Temperature
Nickel-plated brass
Nylon
Machined brass with gold over nickel
plating
Oil resistant PVC, 22AWG stranded
copper, 300V
-20°C to +105°C (-4°F to +221°F)
Features
• Male bulkhead receptacles
• 4-, 5- or 8-pin configuration
• M16, M20 or 1/2in -14NPT mounting threads
Product Selection
Face View of Male
Wire Colour
1 Brown
2 White
3 Blue
4 Black
1 Brown
2 White
3 Blue
4 Black
5 Grey
1 Red
2 Blue
3 Green
4 Yellow
5 Black
6 White
7 N/C
8 Grey
Wire Rating
Length—m (ft)
0.1 (0.3)
M20 x 1.5
22AWG
300V
3A
0.3 (1)
0.1 (0.3)
M20 x 1.5
0.3 (1)
1/2in-14NPT
B
C
1/2in-14NPT
M16 x 1
B
C
A
Panel Mount Threads
M16 x 1
Drawing
A
Catalogue Number
888D-M4AC9-4N
888D-M4AC8-4N
888D-M4AC1-1F
888D-M5AC9-4N
888D-M5AC8-4N
888D-M5AC1-1F
2
3
1
4
2
3
5
1
4
M16 x 1
24AWG
36V DC/30V AC
1.5A
0.1 (0.3)
M20 x 1.5
A
888D-M8AC9-4N
2
1
3 5 4
6
7
8
B
888D-M8AC8-4N
Approximate Dimensions—mm (inch)
M16 threads
O-Ring
M20 threads
O-Ring
1/2in NPT threads
22.2 (0.88)
23.8 (0.94)
18
(0.71)
101.6 (4)
Ref
11.1
(0.44)
19.8 (0.78)
101.6 (4)
Ref
12.7
(0.5)
19.5 (0.77)
304.8 (12)
Ref
12.7
(0.5)
25.4 (1.0)
Dimensions are approximate. Illustrations are not drawn to scale.
15-18
22.2 (0.88)
23.8 (0.94)
