ALUMINUM ELECTROLYTIC CAPACITORS
NX
Screw Terminal Type, High ripple longer life.
series
Suited for use in industrial power supplies for inverter circuitry, etc.
High ripple current, extra-high voltage application.
High reliability, long life for 20,000 hours application of rated ripple
current at +85°C.
Extended range up to
φ
100
×
250L
size.
Flame retardant electroly to type available.
Bushing type for better vibration and insulation also available.
QR
High Speed
charge-
discharge
NX
Long life
NR
Specifications
Item
Performance Characteristics
Category
Temperature Range
Rated
Voltage Range
Rated
Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
–
25 ~ +85
°C
350 ~ 630V
1000 ~ 27000
µ
F
± 20%
at 120Hz, 20°C
After 5 minutes' application of rated voltage, leakage current is not more than
3 CV
(
µ
A) or 5 mA, whichever is smaller (at 20°C).
[C : Rated Capacitance(µF), V : Voltage ( V ) ]
See P199 (Measurement frequency:120Hz,
Rated voltage (V)
Temperature:20°C)
350 ~ 630
Z—25°C/Z+20°C
8
Measurement frequency : 120Hz
Stability at Low Temperature
Impedance ratio ZT/Z20(MAX.)
Endurance
After an application of DC voltage (in the range of rated voltage even after over-lapping the standard ripple current) for 20,000 hours at 85°C, capacitors shall meet the
characteristics requirements indicated at right. (2000 hours at 85°C for the parts rated at 630V, 5000 hours at 85°C for the parts rated at 500V and 550V)
After an application of DC voltage (in the range of rated DC voltage even after
Capacitance change
Within ±20% of initial value
over-lapping the maximum allowable ripple current) for 5000 hours at 85°C,
tan
δ
300% or less of initial specified value
capacitors meet the characteristic requirements listed at right.
Leakage current
Initial specified value or less
After leaving capacitors under no load at 85°C for 1000 hours, they meet the specified value for
endurance
characteristics listed above.
Printed with white color letter on black sleeve.
Shelf Life
Marking
Drawing
Method mount metal bracket
Bottom plate
Method to mount resin bushing (φ76.2 ) (Apply to L=150 or more)
Hexagenal headed bolt
Sleeve
0
°
12
Bottom plate
Sleeve
Resin bushing
Hexagenal headed bolt
φ4.5
Pressure
relief vent
Pressure relief vent
83.7
D
+2MAX
W
±
1
h
H
±
1
L
+
MAX.
±
1
P
±
2
B
A
±
2
74.4
L+3MAX.
T
U
105
120
Method to mount resin bushing (φ90) (Apply to L=150 or more)
U
S
Bottom plate
Sleeve
Resin bushing
Hexagenal headed bolt
°
120
B
3-leg brackets for
φ90
capacitors have different
hole shapes from the ordinary ones illustrated
below.
P
Pressure
relief vent
31.8±1
T
102.5
95.5
A
±
2
P
65.7
5
L+3MAX.
57.5
63.5
φ6.0
Pressure relief vent
7
30
°
●
Dimension
of terminal pitch (W) and length (
R
) and Nominal dia.of bolt
W
22.0
28.6
31.8
31.8
41.5
R
6
6
6
6
10
α
3
3
3
3
4
M5
M5
M5
M5
M8
(mm)
φD
51
63.5
76.2
90
100
●
Dimensions
Type numbering system
(Example :
450V 2200µF)
1
2
3
4
5
6
7
8
9
10 11
12 13 14
Mounting bracket
Nominal dia. of bolt
L N X 2W 2 2 2 M SM
Case dia. code
of mounting bracket
3--Leg
51
32.5
38.5
7.5
5.0
12
60
20
15
63.5
38.1
43
8.0
5.0
14
60
25
20
76.2
44.5
49.2
7.0
5.0
14
60
30
24
90
50.8
58.5
8.0
5.0
18
60
35
25
100
56.3
62
8.0
5.0
16
60
36
30
51
33.2
40
6.0
4.5
14
30
25
15
(mm)
2--Leg
63.5
40.5
46.5
7.0
4.5
14
30
35
20
76.2
46.5
53
6.0
4.5
14
30
35
20
90
53
59
6.0
4.5
14
30
35
20
Configuration
Capacitance tolerance(
±20%
)
Rated Capacitance(2200µF)
Leg shape
Symbol
φD
P
A
T
S
U
°
φD
Code
F
51
63.5 G
76.2 H
J
90
K
100
Code less 3-leg brackets
2-leg brackets
BB
No brackets
BN
Rated voltage(450V)
Series name
H
h
●
Type
Resin bushing available upon request.
Please contact to us if PVCless products are required.
Dimension table in next page.
CAT.8100T
