ALUMINUM ELECTROLYTIC CAPACITORS
UR
Chip Type, High CV
series
Chip type, higher capacitance in larger case sizes.
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine using carrier tape.
UG
Extended
range
UR
Higher
C/V
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
tan
δ
WX
Performance Characteristics
– 40 ~ +85°C
4 ~ 100V
3.3 ~ 1500µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage, leakage current is not more than 0.03CV (µA) .
Measurement frequency : 120Hz, Temperature : 20°C
Rated voltage (V)
tan
δ
(MAX.)
4
0.35
6.3
0.28
4
7
15
10
0.24
6.3
5
10
16
0.20
10
4
8
25
0.16
16
3
6
25
2
4
35
0.14
35
2
3
50
0.12
50
2
3
63
0.12
63
2
3
100
0.12
100
2
3
Measurement frequency: 120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance ratio
ZT / Z20 (MAX.)
Z– 40°C / Z+20°C
Endurance
After 2000 hours' application of rated voltage
at 85°C, capacitors meet the characteristic
requirements listed at right.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Shelf Life
After leaving capacitors under no load at 85°C for 1000 hours, they meet the specified
value for endurance characteristics listed above.
The capacitors shall be kept on the hot plate maintained at 250°C,
for 30 seconds. After removing from the hot plate and restored
at room temperature, they meet the characteristic requirements
listed at right.
Black print on the case top.
Capacitance change
tan
δ
Leakage current
Resistance to soldering
heat
Marking
Within ±10% of initial value
Initial specified value or less
Initial specified value or less
Chip Type
(φ6.3,
φ8 ×
6.2)
Capacitance
Lot No.
φD±0.5
1
Trade mark
B±0.2
Plastic platform
0.3MAX.
2Voltage
C±0.2
Positive
0.5MAX.
Type numbering system (Example : 10V 100
µ
F)
1
2
3
4
5
6
7
8
9
10 11 12 13 14
UUR 1 A 1 0 1 M CR 1GS
Package code
A±0.2
Size code
Configuration
Capacitance tolerance (±20%)
N2
100
10V
Rated Capacitance (100µF)
Rated voltage (10V)
Series name
Type
H
1 Size
φ8 ×
6.2 only
2 Voltage mark for 6.3V is 6V .
In case of marking for
φ3
units, "V" for rated voltage is omitted.
L±0.3
Negative
φ
D
×
L
6.3
×
5.8
6.3
×
7.7
8
×
6.2
8
×
10
10
×
10
E
Code
A±0.2
CR
CR
CR
NR
NR
•
The lead-free product is also available upon request.
(φ8
×
10,
φ10 ×
10)
Positive
0.5MAX.
Lot No.
Trade mark
Plastic platform
0.3MAX.
Capacitance
Voltage
φD±0.5
B±0.2
φ
D
×
L
In this case, L will be put at 11th digit of type numbering system.
Size
φ8 ×
6.2, CL will be put at 10th and 11th digit of type numbering system.
(mm)
C±0.2
6.3
×
5.8
2.4
6.6
6.6
2.2
5.8
0.5 ~ 0.8
6.3
×
7.7
2.4
6.6
6.6
2.2
7.7
0.5 ~ 0.8
8
×
6.2
3.3
8.3
8.3
2.3
6.2
0.5 ~ 0.8
8
×
10
2.9
8.3
8.3
3.1
10
0.8 ~ 1.1
10
×
10
3.2
10.3
10.3
4.5
10
0.8 ~ 1.1
L±0.5
Pressure relief vent
Negative
H
Dimension table in next page.
A±0.2
A
B
C
E
L
H
N2
100
35V
E
A±0.2
CAT.8100T
ALUMINUM ELECTROLYTIC CAPACITORS
UR
Cap.(µF)
3.3
4.7
10
22
33
47
100
150
220
330
470
680
1000
1500
series
Dimensions
V
Code
3R3
4R7
100
220
330
470
101
151
221
331
471
681
102
152
6.3
×
5.8
6.3
×
7.7
8
×
10.
8
×
10.
10
×
10.
152
200
284
344
347
8
×
6.2 160 (143)
8
×
6.2 190 (188)
8
×
10.
8
×
10.
265
6.3
×
5.8
6.3
×
5.8
70
8
×
6.2
125
6.3
×
5.8
65
8
×
6.2 145 (143)
6.3
×
5.8
55
6.3
×
5.8
45
8
×
6.2 95 (94)
8
×
10. 140 (105)
238
289
6.3
×
5.8
8
×
6.2
8
×
10.
8
×
10.
31
46
96
117
140
232
4
0G
6.3
0J
10
1A
16
1C
25
1E
35
1V
50
1H
63
1J
φ
D
×
L (mm)
100
2A
6.3
×
5.8
8
×
10.
8
×
10.
10
×
10.
10
×
10.
29
77
100
130
155
8
×
6.2 40 (35)
8
×
6.2 105 (94)
8
×
10.
8
×
10. 175 (132) 10
×
10. 195 (181) 10
×
10.
85
6.3
×
7.7 151
8
×
10. 192
8
×
10. 214
10
×
10.
8
×
6.2 175 (173) 8
×
10. 215 (162) 10
×
10. 250 (232) 10
×
10. 265 (246) 10
×
10.
8
×
10. 240
8
×
10. 270
10
×
10. 305 (284) 10
×
10. 324
8
×
10. 290
10
×
10. 330 (307) 10
×
10. 393
374
454
10
×
10.
396
318
10
×
10.
10
×
10. 400 (372) 10
×
10.
10
×
10.
489
Case size Rated
ripple
Rated Ripple (mA rms) at 85°C 120Hz
Size
φ6.3 ×
5.8 is available for capacitors marked. " "
Size
φ6.3 ×
7.7 is available for capacitors marked. " "
Size
φ8 ×
10 is available for capacitors marked. " "
In this case, 6 will be put at 12th digit of type numbering system.
Frequency coefficient of rated ripple current
Cap.(µF)
Frequency
00
~ 47V
100 ~ 1500
50 Hz
0.80
0.85
120 Hz
1.00
1.00
300 Hz
1.15
1.08
1 kHz
1.40
1.20
10 kHz~
1.67
1.30
Taping specifications are given in page 22.
Recommended land size are given in page 23
Please refer to page 3 for the minimum order quantity.
CAT.8100T
