Type 950
Metallized Polypropylene Film Capacitors
AC Rated, Round, Axial Leaded
Motor Run, HID Lighting
Type 950
axial-leaded, metallized polypropylene
capacitors with high capacitance values are ideal
for high intensity discharge lighting and motor run
applications. Flame retardant outer wrap and epoxy end
seals provide moisture resistance. Type 950 features
operating temperatures to 90°C without derating and
very low ESR characteristics. This non-protected film
capacitor has Underwriters Laboratories, Inc. recognition
for construction only under U.L. File Number E128034(N).
Specifications
Capacitance Range:
5 µF to 150 µF
Voltage Range:
250 Vac, 50/60 Hz
Capacitance Tolerance:
±10% (K) standard
±6% (H) optional
Operating Temperature Range:
–55 ºC to +90 ºC
Dielectric Strenght:
160% rated voltage for 1 minute
Dissipation Factor (DF):
.15% Max. @ 120 Hz
Insulation Resistance (IR):
100,000 MΩ x µF
Life Test:
1,000 hours at 90 ºC at 125% rated voltage
12
.3 062
0 .
±0
Complies with the EU Directive 2002/95/EC
requirement restricting the use of Lead (Pb),
Mercury (Hg), Cadmium (Cd), Hexavalent
chromium (Cr(VI)), PolyBrominated Biphenyls
(PBB) and PolyBrominated Diphenyl Ethers
(PBDE).
CDE Cornell Dubilier•1605 E. Rodney French Blvd•New Bedford, MA 02744•Phone: (508)996-8561•Fax: (508)996-3830•www.cde.com
Type 950
Metallized Polypropylene Film Capacitors
Ratings
Catalog
Cap.
(µF)
5.0
7.0
8.0
10.0
12.0
13.0
14.0
15.0
16.0
17.0
17.5
20.0
22.5
24.0
26.0
28.0
30.0
32.0
34.0
35.0
36.0
40.0
42.0
45.0
48.0
50.0
Part Number
Solid Leads
950CQW5K-F
950CQW7K-F
950CQW8K-F
950CQW10K-F
950CQW12K-F
950CQW13K-F
950CQW14K-F
950CQW15K-F
950CQW16K-F
950CQW17K-F
950CQW20K-F
950CQW24K-F
950CQW26K-F
950CQW28K-F
950CQW30K-F
950CQW32K-F
950CQW34K-F
950CQW35K-F
950CQW36K-F
950CQW40K-F
950CQW42K-F
950CQW45K-F
950CQW48K-F
950CQW50K-F
Catalog
Part Number
Flexible Leads
250 Vac
950FQW5K-F
950FQW7K-F
950FQW8K-F
950FQW10K-F
950FQW12K-F
950FQW13K-F
950FQW14K-F
950FQW15K-F
950FQW16K-F
950FQW17K-F
950FQW20K-F
950FQW24K-F
950FQW26K-F
950FQW28K-F
950FQW30K-F
950FQW32K-F
950FQW34K-F
950FQW35K-F
950FQW36K-F
950FQW40K-F
950FQW42K-F
950FQW45K-F
950FQW48K-F
950FQW50K-F
0.906(23.0)
1.035(26.3)
1.094(27.8)
0.996(25.3)
1.075(27.3)
1.110(28.2)
1.146(29.1)
1.181(30.0)
1.213(30.8)
1.248(31.7)
1.264(32.1)
1.339(34.0)
1.413(35.9)
1.457(37.0)
1.508(38.3)
1.559(39.6)
1.610(40.9)
1.575(40.0)
1.614(41.0)
1.654(42.0)
1.693(43.0)
1.713(43.5)
1.752(44.5)
1.811(46.0)
1.850(47.0)
1.890(48.0)
1.752(44.5)
1.755(44.5)
1.752(44.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.500(63.5)
2.894(73.5)
2.894(73.5)
2.894(73.5)
2.894(73.5)
2.894(73.5)
2.894(73.5)
2.894(73.5)
2.894(73.5)
2.894(73.5)
9
9
9
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
6
52.0
55.0
56.0
60.0
65.0
68.0
70.0
72.0
75.0
78.0
80.0
82.0
85.0
90.0
92.0
95.0
950CQW52K-F
950CQW55K-F
950CQW56K-F
950CQW60K-F
950CQW65K-F
950CQW68K-F
950CQW70K-F
950CQW72K-F
950CQW75K-F
950CQW78K-F
950CQW80K-F
950CQW82K-F
950CQW85K-F
950CQW90K-F
950CQW92K-F
950CQW95K-F
D
L
dV/dt
Cap.
(µF)
(inches)(mm) (inches)(mm) (V/μs)
Catalog
Part Number
Solid Leads
Catalog
Part Number
250 Vac
950FQW52K-F
950FQW55K-F
950FQW56K-F
950FQW60K-F
950FQW65K-F
950FQW68K-F
950FQW70K-F
950FQW72K-F
950FQW75K-F
950FQW78K-F
950FQW80K-F
950FQW82K-F
950FQW85K-F
950FQW90K-F
950FQW92K-F
950FQW95K-F
1.969(50.0)
2.008(51.0)
2.028(51.5)
1.890(48.0)
1.929(49.0)
2.008(51.0)
2.047(52.0)
2.087(53.0)
2.126(54.0)
2.146(54.5)
2.165(55.0)
2.185(55.5)
2.224(56.5)
1.969(50.0)
2.008(51.0)
2.047(52.0)
2.087(53.0)
2.126(54.0)
2.185(55.5)
2.224(56.5)
2.283(58.0)
2.323(59.0)
2.362(60.0)
2.362(60.0)
2.362(60.0)
2.362(60.0)
2.402(61.0)
2.894(73.5)
2.894(73.5)
2.894(73.5)
3.386(86.0)
3.386(86.0)
3.386(86.0)
3.386(86.0)
3.386(86.0)
3.386(86.0)
3.386(86.0)
3.386(86.0)
3.386(86.0)
3.386(86.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
4.409(112.0)
6
6
6
5
5
5
5
5
5
5
5
5
5
4
4
4
4
4
4
4
4
4
4
4
4
4
4
D
L
dV/dt
Flexible Leads (inches)(mm)
(inches)(mm) (V/μs)
950CQW17P5K-F 950FQW17P5K-F
950CQW22P5K-F 950FQW22P5K-F
100.0 950CQW100K-F 950FQW100K-F
105.0 950CQW105K-F 950FQW105K-F
110.0 950CQW110K-F 950FQW110K-F
115.0 950CQW115K-F 950FQW115K-F
120.0 950CQW120K-F 950FQW120K-F
125.0 950CQW125K-F 950FQW125K-F
130.0 950CQW130K-F 950FQW130K-F
135.0 950CQW135K-F 950FQW135K-F
140.0 950CQW140K-F 950FQW140K-F
145.0 950CQW145K-F 950FQW145K-F
150.0 950CQW150K-F 950FQW150K-F
Other capacitance values, sizes and performance specifications are available. Contact us.
