IDT54/74FCT16245T/AT/CT/ET
FAST CMOS 16-BIT BIDIRECTIONAL TRANSCEIVER
MILITARY AND INDUSTRIAL TEMPERATURE RANGES
FAST CMOS 16-BIT
BIDIRECTIONAL
TRANSCEIVER
FEATURES:
•
•
•
•
•
•
•
•
•
0.5 MICRON CMOS Technology
High-speed, low-power CMOS replacement for ABT functions
Typical t
SK(o)
(Output Skew) < 250ps
Low input and output leakage
≤
1µA (max.)
ESD > 2000V per MIL-STD-883, Method 3015; > 200V using
machine model (C = 200pF, R = 0)
High drive outputs (–32mA I
OH
, 64mA I
OL
)
Power off disable outputs permit “live insertion”
Typical V
OLP
(Output Ground Bounce) < 1.0V at V
CC
= 5V,
T
A
= 25°C
Available in the following packages:
– Industrial: SSOP, TSSOP
– Military: CERPACK
IDT54/74FCT16245T/AT/CT/ET
DESCRIPTION:
The FCT16245T 16-bit transceiver is built using advanced dual metal CMOS
technology. These high-speed, low-power transceivers are ideal for
synchronous communication between two busses (A and B). The Direction and
Output Enable controls operate these devices as either two independent 8-bit
transceivers or one 16-bit transceiver. The direction control pin (xDIR) controls
the direction of data flow. The output enable pin (xOE) overrides the direction
control and disables both ports. All inputs are designed with hysteresis for
improved noise margin.
The FCT16245T is ideally suited for driving high-capacitance loads and low-
impedance backplanes. The output buffers are designed with power off disable
capability to allow "live insertion" of boards when used as backplane drivers.
FUNCTIONAL BLOCK DIAGRAM
1
DIR
1
OE
1
A
1
1
B
1
1
A
2
1
B
2
1
A
3
1
B
3
1
A
4
1
B
4
1
A
5
1
B
5
1
A
6
1
B
6
1
A
7
1
B
7
1
A
8
1
B
8
2
DIR
2
OE
2
A
1
2
B
1
2
A
2
2
B
2
2
A
3
2
B
3
2
A
4
2
B
4
2
A
5
2
B
5
2
A
6
2
B
6
2
A
7
2
B
7
2
A
8
2
B
8
IDT and the IDT logo are registered trademark of Integrated Device Technology, Inc.
MILITARY AND INDUSTRIAL TEMPERATURE RANGES
1
© 2009 Integrated Device Technology, Inc.
JANUARY 2009
DSC-5456/9
IDT54/74FCT16245T/AT/CT/ET
FAST CMOS 16-BIT BIDIRECTIONAL TRANSCEIVER
MILITARY AND INDUSTRIAL TEMPERATURE RANGES
PIN CONFIGURATION
1
DIR
1
B
1
1
B
2
ABSOLUTE MAXIMUM RATINGS
(1)
Symbol
V
TERM
(2)
Description
Terminal Voltage with Respect to GND
Terminal Voltage with Respect to GND
Storage Temperature
DC Output Current
Max
–0.5 to +7
–0.5 to V
CC
+0.5
–65 to +150
–60 to +120
Unit
V
V
°C
mA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
1
OE
1
A
1
1
A
2
V
TERM
(3)
T
STG
I
OUT
GND
1
B
3
1
B
4
GND
1
A
3
1
A
4
V
CC
1
B
5
1
B
6
V
CC
1
A
5
1
A
6
NOTES:
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may
cause permanent damage to the device. This is a stress rating only and functional
operation of the device at these or any other conditions above those indicated in
the operational sections of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect reliability.
2. All device terminals except FCT162XXXT and FCT166XXXT (APort) Output and
I/O terminals.
3. Output and I/O terminals terminals for FCT162XXX and FCT166XXXT (A-Port).
CAPACITANCE
(T
A
= +25°C, F = 1.0MHz)
Symbol
C
IN
C
OUT
Parameter
(1)
Input Capacitance
Output Capacitance
Conditions
V
IN
= 0V
V
OUT
= 0V
Typ.
3.5
3.5
Max.
6
8
Unit
pF
pF
GND
1
B
7
1
B
8
2
B
1
2
B
2
GND
1
A
7
1
A
8
2
A
1
2
A
2
NOTE:
1. This parameter is measured at characterization but not tested.
PIN DESCRIPTION
Pin Names
xOE
xDIR
xAx
xBx
Description
Output Enable Inputs (Active LOW)
Direction Control Inputs
Side A Inputs or 3-State Outputs
Side B Inputs or 3-State Outputs
GND
2
B
3
2
B
4
GND
2
A
3
2
A
4
V
CC
2
B
5
2
B
6
V
CC
2
A
5
2
A
6
FUNCTION TABLE
(1)
Inputs
xOE
L
L
H
xDIR
L
H
X
Outputs
Bus B Data to Bus A
Bus A Data to Bus B
High Z State
GND
2
B
7
2
B
8
2
DIR
GND
2
A
7
2
A
8
2
OE
SSOP/ TSSOP CERPACK
TOP VIEW
NOTE:
1. H = HIGH Voltage Level
L = LOW Voltage Level
X = Don’t Care
Z = High-Impedance
2
IDT54/74FCT16245T/AT/CT/ET
