4.
SPECIFICATIONS FOR EACH SERIES
Conductive polymer type
SEQP
Specifications for
each series
Series
125°C guaranteed,
32V product
This series has advanced characteristics in resistance to heat compared with the
SEP series, and adds a rated voltage of 32V. Suitable for use in increasing device
reliability, 32V products may be used on 16 to 24V line industrial devices.
Lead free-flow is supported.
■Specifications
Items
Category temperature range
Tolerance on rated capacitance
Tangent of loss angle
Leakage current
※1
ESR
Characteristics of impedance
ratio at high temp. and low temp.
Endurance
Conditions
120Hz
120Hz
After 2 minutes
Based the value at
100KHz，+20°C
125°C, 1,000h, Rated
voltage applied
60°C, 90 to 95% RH,
1,000h,
No-applied voltage
Flow method
(260±5°C X 10s)
Marking : Polarity( ), Rated voltage
(Purple) SEQP, Rated capacitance, Lot.No.
Characteristics
-55°C to +125°C
M :
±20%
Less than or equal to the value of Table6
Less than or equal to the value of Table6
Less than or equal to the value of Table6
Z / Z
20°C
0.75 to 1.25
-55°C
0.75 to 1.25
Z / Z
20°C
+125°C
Within
±20%
∆C/C
2 times or less than an initial standard
tanδ
2 times or less than an initial standard
ESR
Leakage current
Below an initial standard
Within
±20%
∆C/C
1.5 times or less than an initial standard
tanδ
1.5 times or less than an initial standard
ESR
Leakage current Below an initial standard (after voltage processing)
Within
±5%
∆C/C
Below an initial standard
tanδ
Below an initial standard
ESR
Leakage current Below an initial standard (after voltage processing)
Damp heat (Steady state)
Resistance to
soldering heat
※1
In case of some problems for measured values, measure after applying rated voltage for 120 minutes at 125
°C
.
■Dimensions
φD
φd
（＋）
F
(unit : mm)
Size Code
C6
E7
F8
E12
F13
φD+0.5max.
Lmax.
6.0
7.0
8.0
12.0
13.0
F
2.5±0.5
3.5±0.5
5.0±0.5
3.5±0.5
5.0±0.5
φd±0.05
0.45
0.45
0.50
0.60
0.60
15min.
L
19min.
4min.
6.3
8.0
10.0
8.0
10.0
■Size
List
µF
RV
(SV)
RV : Rated voltage
4.0
(5.2)
6.3
(8.4)
10
(11.5)
(SV) : Surge (room temperature)
16
(18.4)
20
(23)
32
(37)
6.8
15
18
22
39
47
56
68
82
100
120
150
180
270
330
470
560
680
820
1200
E7
F8
E12
C6
C6
E7
C6
F8
C6
E7
C6
E7
E12
F8
F13
F13
E7
F8
E12
F8
E12
F13
F8
E12
F13
F13
E7
E12
※For
the minimum packing quantity, please refer to page 51
.
32
4.
SPECIFICATIONS FOR EACH SERIES
■Table6
SEQP Series Characteristics List
Size
Code
Part Number
※1
20SEQP22M
16SEQP39M
C6
10SEQP56M
6SEQP82M
4SEQP150M
32SEQP6R8M
20SEQP47M
16SEQP82M
E7
10SEQP120M
6SEQP150M
4SEQP330M
32SEQP15M
20SEQP68M
16SEQP150M
F8
10SEQP270M
6SEQP330M
4SEQP680M
32SEQP18M
20SEQP100M
16SEQP180M
E12
10SEQP330M
6SEQP470M
4SEQP560M
20SEQP150M
16SEQP330M
F13
10SEQP560M
6SEQP820M
4SEQP1200M
10
6.3
4
32
20
16
10
6.3
4
20
16
10
6.3
4
270
330
680
18
100
180
330
470
560
150
330
560
820
1200
25
25
25
50
24
20
17
15
13
20
16
13
12
12
1170
1170
1170
790
1050
1151
1250
1332
1430
1367
1493
1655
1721
1721
3700
3700
3700
2500
3320
3640
3950
4210
4520
4320
4720
5230
5440
5440
0.12
0.12
0.12
0.12
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.18
540
416
544
115
400
576
660
592
448
600
792
840
775
960
10
6.3
4
32
20
16
120
150
330
15
68
150
35
35
35
80
40
30
810
810
810
560
759
955
2560
2560
2560
1800
2400
3020
0.12
0.12
0.12
0.10
0.12
0.12
600
472
660
96
272
480
Rated
Voltage
(V)
20
16
10
6.3
4
32
20
16
Rated ripple current Allowable ripple current Tangent of
Rated
ESR
Capacitance 100kHz to 300kHz
loss angle
100kHz (mArms)
※3
(µF)
(mΩ) (max.)
(max.)
105°C＜Tx≦125°C
Tx≦105°C
22
39
56
82
150
6.8
47
82
60
50
45
45
40
100
45
40
458
512
537
537
572
440
598
670
1450
1620
1700
1700
1810
1400
1890
2120
0.10
0.10
0.12
0.12
0.12
0.10
0.12
0.12
Leakage
current (µA)
(max.)※2
220
Specifications for
each series
312
280
258
300
44
470
656
※1
※2
※3
Capacitance tolerance : M
±20%
After 2 minutes
Tx : Ambient temperature
Frequency coefficient for ripple current
Frequency
Coefficient
120Hz≦ f
＜1kHz
0.05
1kHz≦ f
＜10kHz
0.3
10kHz≦ f
＜100kHz
0.7
100kHz≦ f
≦500kHz
1
33
