1734417-7: DescriptionFLEX CABLE CONNECTOR,PCB MNT,7 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING; CategoryThe connector The connector; File Size182KB，2 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric Compare View All

1734417-7 Overview

FLEX CABLE CONNECTOR,PCB MNT,7 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING

1734417-7 Parametric

Parameter Name	Attribute value
Maker	TE Connectivity
Reach Compliance Code	unknow
body width	0.118 inch
subject depth	0.295 inch
body length	0.496 inch
Connector type	FFC/FPC CONNECTOR
Contact to complete cooperation	AU ON NI
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	75 mΩ
Contact style	BELLOWED TYPE
Dielectric withstand voltage	500VAC V
Durability	30 Cycles
Insulation resistance	100000000 Ω
Insulator color	BLACK
insulator material	THERMOPLASTIC
Plug contact pitch	0.039 inch
Installation option 1	LOCKING
Installation method	RIGHT ANGLE
Installation type	BOARD
PCB row number	1
Number of rows loaded	1
Maximum operating temperature	85 °C
Minimum operating temperature	-55 °C
PCB contact pattern	RECTANGULAR
Plating thickness	FLASH inch
Rated current (signal)	1.5 A
Guideline	UL
reliability	COMMERCIAL
Terminal pitch	0.9906 mm
Termination type	SURFACE MOUNT
Total number of contacts	7

Preview

Download Datasheet

View All

1734417-7 Related Products

	1734417-7	2-1734417-1	2-1734417-2	2-1734417-3	2-1734417-7	2-1734417-9
Description	FLEX CABLE CONNECTOR,PCB MNT,7 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING	FLEX CABLE CONNECTOR,PCB MNT,21 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING	FLEX CABLE CONNECTOR,PCB MNT,22 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING	FLEX CABLE CONNECTOR,PCB MNT,23 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING	FLEX CABLE CONNECTOR,PCB MNT,27 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING	FLEX CABLE CONNECTOR,PCB MNT,28 CONTACTS,1,SURFACE MOUNT TERMINAL,LOCKING
Reach Compliance Code	unknow	unknown	unknown	unknown	unknown	unknown
body width	0.118 inch	0.118 inch	0.118 inch	0.118 inch	0.118 inch	0.118 inch
subject depth	0.295 inch	0.295 inch	0.295 inch	0.295 inch	0.295 inch	0.295 inch
body length	0.496 inch	1.047 inch	1.087 inch	1.126 inch	1.283 inch	1.323 inch
Connector type	FFC/FPC CONNECTOR	FFC/FPC CONNECTOR	FFC/FPC CONNECTOR	FFC/FPC CONNECTOR	FFC/FPC CONNECTOR	FFC/FPC CONNECTOR
Contact to complete cooperation	AU ON NI	AU ON NI	AU ON NI	AU ON NI	AU ON NI	AU ON NI
Contact material	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE	PHOSPHOR BRONZE
contact mode	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Contact resistance	75 mΩ	75 mΩ	75 mΩ	75 mΩ	75 mΩ	75 mΩ
Contact style	BELLOWED TYPE	BELLOWED TYPE	BELLOWED TYPE	BELLOWED TYPE	BELLOWED TYPE	BELLOWED TYPE
Dielectric withstand voltage	500VAC V	500VAC V	500VAC V	500VAC V	500VAC V	500VAC V
Durability	30 Cycles	30 Cycles	30 Cycles	30 Cycles	30 Cycles	30 Cycles
Insulation resistance	100000000 Ω	100000000 Ω	100000000 Ω	100000000 Ω	100000000 Ω	100000000 Ω
Insulator color	BLACK	BLACK	BLACK	BLACK	BLACK	BLACK
insulator material	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC	THERMOPLASTIC
Plug contact pitch	0.039 inch	0.039 inch	0.039 inch	0.039 inch	0.039 inch	0.039 inch
Installation option 1	LOCKING	LOCKING	LOCKING	LOCKING	LOCKING	LOCKING
Installation method	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE	RIGHT ANGLE
Installation type	BOARD	BOARD	BOARD	BOARD	BOARD	BOARD
PCB row number	1	1	1	1	1	1
Number of rows loaded	1	1	1	1	1	1
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
PCB contact pattern	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Plating thickness	FLASH inch	FLASH inch	FLASH inch	FLASH inch	FLASH inch	FLASH inch
Rated current (signal)	1.5 A	1.5 A	1.5 A	1.5 A	1.5 A	1.5 A
Guideline	UL	UL	UL	UL	UL	UL
reliability	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal pitch	0.9906 mm	0.9906 mm	0.9906 mm	0.9906 mm	0.9906 mm	0.9906 mm
Termination type	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Total number of contacts	7	21	22	23	27	28
Objectid	-	305019914	305019915	305019916	305019920	305019921
ECCN code	-	EAR99	EAR99	EAR99	EAR99	EAR99
