N1608Z121T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> N1608Z121T

N1608Z121T: DescriptionData Line Filter, 1 Function(s), 0.2A; CategoryAnalog mixed-signal IC filter; File Size145KB，4 Pages; ManufacturerTOKO, INC.; Websitehttps://www.murata.com/

Download Datasheet Parametric Compare View All

N1608Z121T Overview

Data Line Filter, 1 Function(s), 0.2A

N1608Z121T Parametric

Parameter Name	Attribute value
Maker	TOKO, INC.
Reach Compliance Code	unknow
ECCN code	EAR99
Maximum DC resistance	0.2 Ω
filter type	DATA LINE FILTER
high	0.8 mm
length	1.6 mm
Manufacturer's serial number	N-Z
Installation type	SURFACE MOUNT
Number of functions	1
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output impedance	120 OHM Ω
method of packing	TAPE AND REEL
physical size	L1.6XB0.8XH0.8 (mm)
Rated current	0.2 A
width	0.8 mm

Preview

Download Datasheet

View All

SMD-Type Chip Filters

Chip suppressors

Low-Loss N-Z Series

• Tape and Reel Dimensions (see page 144)

•Reliability Test (see page 147)

•Precautions (see page 146)

Model

Impedance ( )

at 100MHz

DC resistance

(m ) max.

Rated current

(mA)

N1005Z100

N1005Z400

N1005Z600

N1005Z800

N1005Z121

N1005Z201

N1005Z301

N1608Z300

N1608Z800

N1608Z121

N1608Z301

N1608Z601

N1608Z102

N2012Z260

N2012Z800

N2012Z121

N2012Z221

N2012Z301

N2012Z601

N2012Z102

N2012Z202

10±25%

40±25%

60±25%

80±25%

120±25%

220±25%

300±25%

30±25%

80±25%

120±25%

300±25%

600±25%

1000±25%

26±25%

80±25%

120±25%

220±25%

300±25%

600±25%

1000±25%

2000±25%

100

150

300

400

600

800

100

200

300

500

700

200

250

300

400

600

1000

1200

100

200

100

600

300

200

SMD-Type Chip Filters

• Operating temperature range: –55 to +125˚C

• Storage temperature range (taping): –5 to +40˚C (bulk): –55 to +125˚C

Shape and Dimensions

Circuit Diagram

Type

N1005Z

N1608Z

N2012Z

1.0±0.05

1.6±0.15

2.0±0.2

0.5±0.05

0.8±0.15

1.25±0.2

0.5±0.05

0.8±0.15

0.9±0.2

C min.

0.1

0.3

[mm]

Numbering System

N 2012 Z 300 T

Product type N : Normal Mode Chip Suppressors

Dimensions 1005 : 1.0 0.5 0.5mm, 1608 : 1.6 0.8 0.8mm, 2012 : 2.0 1.25 0.9mm,

Material

Impedance 300 : 30 , 121 : 120 , 102 : 1000

Packaging T : Taping, 1005 : 4000pcs./reel, 1608 : 3000pcs./reel, 2012 : 3000pcs./reel,

NEC TOKIN control number

EMC GENERAL VOL.01

133

N1608Z121T Related Products

	N1608Z121T	N1608Z300T	N1608Z102T	N1608Z301T	N2012Z102T	N2012Z121T	N2012Z301T
Description	Data Line Filter, 1 Function(s), 0.2A	Data Line Filter, 1 Function(s), 0.2A	Data Line Filter, 1 Function(s), 0.1A	Data Line Filter, 1 Function(s), 0.2A	Data Line Filter, 1 Function(s), 0.2A	Data Line Filter, 1 Function(s), 0.3A	Data Line Filter, 1 Function(s), 0.2A
Maker	TOKO, INC.	TOKO, INC.	TOKO, INC.	TOKO, INC.	TOKO, INC.	TOKO, INC.	TOKO, INC.
Reach Compliance Code	unknow	unknown	unknow	unknow	unknow	unknow	unknow
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum DC resistance	0.2 Ω	0.1 Ω	0.7 Ω	0.3 Ω	1 Ω	0.3 Ω	0.4 Ω
filter type	DATA LINE FILTER	DATA LINE FILTER	DATA LINE FILTER	DATA LINE FILTER	DATA LINE FILTER	DATA LINE FILTER	DATA LINE FILTER
high	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.9 mm	0.9 mm	0.9 mm
length	1.6 mm	1.6 mm	1.6 mm	1.6 mm	2 mm	2 mm	2 mm
Manufacturer's serial number	N-Z	N-Z	N-Z	N-Z	N-Z	N-Z	N-Z
Installation type	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Number of functions	1	1	1	1	1	1	1
Maximum operating temperature	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Output impedance	120 OHM Ω	30 OHM Ω	1000 OHM Ω	300 OHM Ω	1000 OHM Ω	120 OHM Ω	300 OHM Ω
method of packing	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL	TAPE AND REEL
physical size	L1.6XB0.8XH0.8 (mm)	L1.6XB0.8XH0.8 (mm)	L1.6XB0.8XH0.8 (mm)	L1.6XB0.8XH0.8 (mm)	L2XB1.25XH0.9 (mm)	L2XB1.25XH0.9 (mm)	L2XB1.25XH0.9 (mm)
Rated current	0.2 A	0.2 A	0.1 A	0.2 A	0.2 A	0.3 A	0.2 A
width	0.8 mm	0.8 mm	0.8 mm	0.8 mm	1.25 mm	1.25 mm	1.25 mm
