FA
OS-CON
Series
TM
OS-CON
TM
Low ESR
Long Life
Solvent Proof
105 C
Maximum
Temperature
Actual
Size
OS -CON
TM
-105 C
FA
The FA series is an OS-CON
TM
series with higher capacitance values than the older CFM series. The
low ESR, high ripple current capability and small size make these capacitors ideal for use in low
profile DC-DC converters and also for stereo and video recorder applications. These capacitors can
be used in filter circuits of switching power supplies and also for noise limiters.
The FA series capacitors are solvent proof. Refer to the Mini-Glossary for cleaning guidelines and
recommended cleaning agents that are compatible with United Chemi-Con products.
Summary of Specifications
Radial lead terminals.
Capacitance range: 15 to 2,200µF.
Voltage range: 4 to 25VDC.
Category temperature range: 55 C to 105 C.
Leakage current: After 2 minutes with rated voltage applied at 20 C, see ratings
tables for leakage current values.
Standard capacitance tolerance: 20%; 10% optional for
Ø
6.3,
Ø
8 and
Ø
10.
Nominal case size (D L): 6.3 9.8mm to 16 25mm.
Rated lifetime: 1,000 to 2,000 hours at 105 C depending on case diameter.
66
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
FA Series
FA Specifications
Item
Category Temperature Range
Rated Voltage Range
Capacitance Range
Capacitance Tolerance
Leakage Current
Dissipation Factor ( Tan )
Temperature
Characteristics
55 to 105 C
4 to 25VDC
15 to 2,200 F
20% ( M );
10% ( K ) optional for
Ø
6.3,
Ø
8 and
Ø
10; at
20 C, 120Hz
Characteristics
After 2 minutes with rated voltage applied at
Tan
( DF ) at
20 C, see Ratings Tables for specified values.
20 C, 120Hz shall not exceed the specified values given in the Ratings Tables.
55 C,
40 C or 105 C value and
20 C value
At 100kHz, impedance ( Z ) ratio between the
shall not exceed the values given below.
Rated Voltage ( V )
Z ( 55 C ) / Z ( 20 C )
Z ( 40 C ) / Z ( 20 C )
Z ( 105 C ) / Z ( 20 C )
4 - 25
1.00 -1.25
1.00 -1.20
0.75 -1.00
OS -CON
TM
-105 C
FA
Rated Ripple Current Multipliers
Refer to Section 4 of the
Mini-Glossary for explanation of
Rated Ripple Current Multipliers.
Endurance
(Load Life)
Ambient Temperature ( C )
≤
45 C
1.0
65 C
0.85
85 C
0.7
95 C
0.4
105 C
0.25
The following specifications shall be satisfied when the capacitors are restored to 20 C after
subjecting them to the DC rated voltage for the specified test time at 105 C. (20V shall be
applied for the capacitors with a 25V rating.)
Case Diameter
Test Time
Ø
6.3,
Ø
8 &
Ø
10mm
Ø
12.5 &
Ø
16mm
2,000 Hours
1,000 Hours
Capacitance change :
≤
20% of initial measured value
Tan ( DF )
:
≤
150% of initial specified value
Leakage current
:
≤
initial specified value
Moisture Resistance
The following specifications shall be satisfied when the capacitors are restored to 20 C
after exposing them for 1,000 hours at 60 C, 90 - 95%RH without voltage applied. The rated
voltage shall be applied to the capacitors for a minimum of 30 minutes at 105 C.
Capacitance change:
≤
10% of initial measured value
Tan ( DF )
:
≤
150% of initial specified value except
Ø
10 5 case size
:
≤
200% of initial specified value for
Ø
10 5 case size
Leakage current
:
≤
initial specified value
Diagram of Dimensions
Radial Lead
PVC Sleeve
d
K A
D
'
D
F
A'
L
L
'
15
MIN.
4
MIN.
G
Unit: mm
C
F
: Standard position of lead terminals
: Actual position of lead terminals A & A'
: Middle point C between A & A'
Ø
D
6.3
8
10
12.5
16
Ø
D
'
max.
Ø
D
Ø
D
Ø
D
Ø
D
Ø
D
For optional lead configurations and
tape and ammo packaging, refer to
the beginning of the Miniature section.
0.5
0.5
0.5
0.5
0.5
L
'
max.
L 1.0
L 1.0
L 1.0
L 1.0
L 1.0
Ø
d
0.5
0.6
0.5 ( 5L); 0.6 (10.5L)
0.8
0.8
F 0.5
2.5
3.5
5.0
5.0
7.5
G max.
0.5
0.5
0.5
0.8
0.8
K max.
0.5
0.5
0.5
0.8
0.8
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
67
FA Series
Part Numbering System for FA Series
10
FA
220
M
A
Suffix A indicates
Ø
10 5 case size products and is also used to
identify one part from another when two capacitors have the same
capacitance value and rated voltage.
Capacitance Tolerance: M = 20% or
K = 10% (optional for
Ø
6.3,
Ø
8 and
Ø
10)
Capacitance Value: Expressed in Microfarads. An R indicates a
decimal point (e.g. 2R2 = 2.2 F ).
Series Name: Indicates Basic Capacitor Design.
DC Rated Voltage: Expressed in Volts (e.g. 10 = 10WVDC).
Note: Prefix code 6 indicates 6.3WVDC products.
When ordering, always specify complete catalog number for FA Series.
OS -CON
TM
-105 C
FA
Standard Voltage Ratings - Radial Lead
Rated
Voltage
(WVDC)
Capacitance
(µF )
Catalog
†
Part Number
†
Nominal
Case Size*
D L ( mm )
Maximum
Leakage
Current ( µA )
at 20 C
Dissipation
Factor (Tan )
20 C, 120Hz
Maximum ESR
( m
Ω
) at 20 C
100k-300kHz
Rated
Ripple Current
( mA rms) at
45 C, 100kHz
4 Volts
220
4FA220MA
10
5
17.6
0.07
55
2,400
6.3 Volts
150
150
330
2,200
47
68
100
100
220
47
68
68
100
150
470
1,000
33
47
68
100
15
22
22
33
47
6FA150M
6FA150MA
6FA330M
6FA2200M
10FA47M
10FA68M
10FA100M
10FA100MA
10FA220M
16FA47M
16FA68M
16FA68MA
16FA100M
16FA150M
16FA470M
16FA1000M
20FA33M
20FA47M
20FA68M
20FA100M
25FA15M
25FA22M
25FA22MA
25FA33M
25FA47M
8
10
10
16
6.3
6.3
8
10
10
6.3
8
10
8
10
12.5
16
6.3
8
8
10
6.3
8
10
10
10
10.5
5
10.5
25
9.8
9.8
10.5
5
10.5
9.8
10.5
5
10.5
10.5
22
25
9.8
10.5
10.5
10.5
9.8
10.5
5
10.5
10.5
18.9
18.9
41.5
277.0
4.7
13.6
20.0
20.0
44.0
15.0
21.8
21.7
32.0
48.0
150.0
320.0
13.2
18.8
27.2
40.0
3.7
5.5
11.0
8.2
11.7
0.07
0.07
0.07
0.13
0.06
0.07
0.07
0.07
0.07
0.06
0.06
0.07
0.06
0.06
0.08
0.09
0.06
0.06
0.06
0.06
0.04
0.06
0.07
0.06
0.06
30
60
25
15
60
50
30
60
27
60
40
65
30
28
20
15
70
40
36
30
70
40
70
35
35
2,780
2,100
3,500
9,750
2,020
2,040
2,680
2,100
3,370
1,830
2,600
1,850
2,740
3,260
6,080
9,750
1,710
2,450
2,600
3,210
1,650
2,330
1,600
2,900
2,980
10 Volts
16 Volts
20 Volts
25 Volts
†
M indicates 20% capacitance tolerance. Substitute code letter K in part number for 10% tolerance (available for
Ø
6.3,
Ø
8 and
Ø
10 only ).
*
The case sizes in table are with no sleeve, refer to diagram for case sizes with sleeve.
68
United Chemi-Con, Inc. 9801 W. Higgins Road, Rosemont, IL 60018 Tel 847-696-2000 Fax 847-696-9278 www.chemi-con.com
