AN/521P
H
ØD ØT
Ød
t
Category
• Rod Wiper, Snap Fit
Metric Specifications
Operating Conditions
Maximum Speed:
Temperature Range:
Surface Finish
Dynamic Sealing Face:
Static Sealing Face
:
Other Faces:
4.0 m/sec
-40°C ~ 110°C
0.1 ~ 0.4 µmRa
1.6 µmRa max
3.2 µmRa max
TRANSEALS TRANSEALS TRANSEALS TRANSEALS TRANSEALS TRANSEALS TRAN-
TRANSEALS TRANSEALS TRANSEALS TRANSEALS TRAN-
Construction
• Orange Polyurethane 361 with knifed
wiping lip
Housing
• Open rectangular groove in one
piece gland
Duty
• Medium
Imperial Specifications
Operating Conditions
Maximum Speed:
Temperature Range:
Surface Finish
Dynamic Sealing Face:
Static Sealing Face:
Other Faces:
12.0 ft/sec
-40°F ~ 230°F
4 ~ 16 µinCLA
63 µinCLA max
125 µinCLA max
Features
• Heel pressure release ribs
• External lip for improved dirt exclusion
• Crush lip for positive location
Comments
• An evolution of the classic AN/B rod
wiper, with improved performance
• Interchangeable with corresponding
AN6231 & MS28776 wipers
Manufacturer
• Hallite
Size Range
• US Imperial
Imperial Sizes
Part No.
Tolerances
AN0625-521P
AN0750-521P
AN0875-521P
AN1000-521P
AN1125-521P
AN1250-521P
Ød
ØD
+0.004
-0
0.885
1.010
1.147
1.272
1.397
1.522
H
+0.003
-0
0.107
0.107
0.107
0.107
0.107
0.107
ØT
+0.005
-0
0.772
0.897
1.023
1.148
1.273
1.398
t
Part No.
AN1375-521P
AN1500-521P
AN1750-521P
AN2000-521P
AN2500-521P
AN3000-521P
AN3500-521P
AN4000-521P
Imperial Sizes (cont’d)
Ød
1.375
1.500
1.750
2.000
2.500
3.000
3.500
4.000
ØD
1.677
1.802
2.052
2.302
2.802
3.364
3.864
4.427
H
0.107
0.107
0.107
0.107
0.107
0.122
0.122
0.138
ØT
1.542
1.668
1.918
2.178
2.678
3.209
3.709
4.240
t
0.187
0.187
0.187
0.187
0.187
0.211
0.211
0.238
0.625
0.750
0.875
1.000
1.125
1.250
0.187
0.187
0.187
0.187
0.187
0.187
11 July 2003
