AQV227NSZ datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> AQV227NSZ

AQV227NSZ: DescriptionTRANSISTOR OUTPUT SOLID STATE RELAY, 1500 V ISOLATION-MAX; CategoryLED optoelectronic/LED; File Size40KB，3 Pages; ManufacturerETC1

Download Datasheet Parametric Compare View All

AQV227NSZ Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	AQV227NSZ	-	-	View	Buy Now

AQV227NSZ Overview

TRANSISTOR OUTPUT SOLID STATE RELAY, 1500 V ISOLATION-MAX

AQV227NSZ Parametric

Parameter Name	Attribute value
Maximum operating temperature	85 Cel
Minimum operating temperature	-40 Cel
Number of functions	1
Processing package description	0.248 X 0.173 INCH, 0.083 INCH HEIGHT, ROHS COMPLIANT, MINIATURE, SOP-6
state	ACTIVE
structure	SINGLE
Optoelectronic device type	TRANSISTOR OUTPUT
Maximum input control current	50 mA
Maximum insulation voltage	1500 V
On-state resistance	50 ohm
Maximum output current	50 A

Preview

Download Datasheet

View All

RF (Radio Frequency) Type

SOP Series

[1-Channel (Form A) Type]

—Low On resistance—

6.3±0.2

.248±.008

4.4±0.2

.173±.008

2.1±0.2

.083±.008

PhotoMOS

RELAYS

toMOS relay has only 30 pA even with the

rated load voltage of 80 V (AQV225NS).

4. Controls low-level analog signals

PhotoMOS relays feature extremely low

closed-circuit offset voltage to enable

control of low-level analog signals without

distortion.

5. Tape and reel

The device comes standard in a tape and

reel (1,000 pcs./reel) to facilitate automat-

ic insertion machines.

(DIP)

Volume

(SOP)

Approx. 25%

inch

Approx. 50%

Footprint

FEATURES

1. 1-channel (Form A) in super minia-

ture design

The device comes in a super-miniature

SO package measuring (W) 4.4

(L) 6.3

(H) 2.1 mm

(W).173

(L) .248

(H) .083

inch

—approx. 25% of the volume and

50% of the footprint size of DIP type Pho-

toMOS Relays.

2. Low capacitance between output

terminals ensure high response

speed:

The capacitance between output termi-

nals is small, typically 10 pF. This enables

for a fast operation speed of 200

3. Low-level off state leakage current:

The SSR has an off state leakage current

of several milliamperes, whereas the Pho-

TYPICAL APPLICATIONS

• Telephones

• Measuring instruments

• Computer

• Industrial robots

• High-speed inspection machines

TYPES

1. AC/DC type

Output rating*

Load voltage

80 V

200 V

400 V

Load current

120 mA

50 mA

40 mA

Part No.

Picked from the 1/2/3-pin side

1 Form A

AQV225NSX

AQV227NSX

AQV224NSX

Picked from the 4/5/6-pin side

1 Form A

AQV225NSZ

AQV227NSZ

AQV224NSZ

Packing quantity in tape and reel

1,000 pcs.

*Indicate the peak AC and DC values.

Notes: (1) Tape package is the standard packing style. Also available in tube. (Part No. sufﬁx "X" or "Z" is not needed when ordering; Tube: 75 pcs.;

Case: 1,500 pcs.)

(2) For space reasons, the top two letters of the product number "AQ" are omitted on the product seal. The package type indicator "X" and "Z"

are also omitted from the seal. (Ex. the label for product number AQV224NS is V224NS).

RATING

1. Absolute maximum ratings (Ambient temperature: 25

Item

LED forward current

Input

LED reverse voltage

Peak forward current

Power dissipation

Load voltage (peak AC)

Continuous load current

Output

Peak load current

Power dissipation

Total power dissipation

I/O isolation voltage

Temperature

limits

Operating

Storage

peak

out

iso

opr

stg

Type of

Symbol connec-

tion

80 V

0.12 A

0.15 A

0.25 A

0.36 A

AQV225NS

AQV227NS

50 mA

75 mW

200 V

0.05 A

0.06 A

0.08 A

0.15 A

450 mW

500 mW

1,500 V AC

–40

C to +85

–40

F to +185

–40

C to +100

–40

F to +212

Non-condensing at low

temperatures

400 V

0.04 A

0.05 A

0.06 A

0.12 A

A connection: Peak AC, DC

B, C connection: DC

A connection: 100 ms (1 shot),

= DC

AQV224NS

Remarks

f = 100 Hz, Duty factor = 0.1%

149
