CONTINUOUSLY VARIABLE ATTENUATORS
06 SERIES
VARIABLE ATTENUATORS
FREQUENCY FLAT MODELS
VA R I A B L E A T T E N U A T O R S
Freq
(GHz)
2.0-4.0
3.6-6.5
3.6-4.3
5.8-6.5
5.85-14.5
4.0-8.0
7.2-8.4
8.0-12.4
10.7-12.7
10.7-14.5
13.0-14.5
12.4-18.0
17.0-18.6
8.0-18.0
14.0-26.0
Atten
Range (dB)
10
10
20
20
20
10
20
10
20
20
30
10
20
20
20
Flatness
(+/- db)
1.5
0.8
0.5
0.5
0.5/B
2.0
1.0
1.0
0.8
1.5
0.5
1.0
1.0
1.8
1.0
Model
No.
AF064-10
AF065C-10
AF06C1-20
AF06C2-20
AF06CK-20
AF065-10
AF065X-20
AF066-10
AF066X-20
AF066K-20
AF067K-30
AF067-10
AF067J-20
AF066H-20
AF068-20
FREQUENCY FLAT MODELS
Freq
(GHz)
0.7-0.8
0.8-1.0
0.8-1.0
0.95-1.45
1.5-2.0
2.0-4.0
2.8-6.5
3.4-4.2
3.6-6.5
3.6-4.3
5.8-6.5
4.0-8.0
7.2-8.4
8.0-12.4
10.7-12.7
10.7-14.5
12.4-18.0
0.7-1.0
0.8-1.6
0.9-1.75
1.0-2.0
2.0-4.2
4.0-8.0
7.9-12.7
11.7-18.0
0.9-8.0
1.0-4.0
1.0-8.0
2.0-18.0
4.0-18.0
6.0-18.0
Atten
Range (dB)
10
15
20
15
20
20
20
20
30
30
30
20
30
20
30
30
20
10
15
15
20
20
30
30
30
20
20
30
10
20
60
Flatness
(+/- db)
0.75
1.5
1.5
1.7
1.5
1.5
1.5
1.0
1.2
0.7
0.7
1.0
0.7
1.0
1.0
1.5
1.0
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Model
No.
AF082L2-10
AF082L1-15
AF082L1-20
AF083L1-15
AF083L2-20
AF084-20
AF084F-20
AF085C3-20
AF085C-30
AF085C1-30
AF085C2-30
AF085-20
AF085X-30
AF086-20
AF086X-30
AF086K-30
AF087-20
AV082-10
AV083L-15
AV083-15B
AV083-20
AV084-20
AV085-30
AV086-30
AV087-30
AV083F-20
AV083E-20
AV083F-30
AV084H-10
AV085H-20
AV086H-60
08 SERIES
LEVEL ADJUST MODELS
2.0-4.2
3.7-4.2
7.9-12.7
11.7-18.0
14.0-26.5
26.5-40
2.0-8.0
4.0-12.4
4.0-18.0
6.0-18.0
10
20
30
30
20
20
10
20
10
30
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
AV064-10
AV065-20
AV066-30
AV067-30
AV068-20
AV069-20
AV064F-10
AV065G-20
AV065H-10
AV066H-30
MULTIBAND MODELS
LEVEL ADJUST MODELS
07 SERIES
VARIABLE ATTENUATORS
FREQUENCY FLAT MODELS
Freq
(GHz)
2.0-4.0
3.6-6.5
3.6-4.3
5.8-6.5
5.85-14.5
4.0-8.0
7.2-8.4
7.9-8.4
8.0-12.4
10.7-12.7
10.7-14.5
12.4-18.0
17.0-18.6
8.0-18.0
1.0-2.0
1.5-2.0
2.0-4.0
2.0-8.0
3.6-4.3
4.0-8.0
4.0-12.4
8.0-12.4
8.0-18.0
Atten
Range (dB)
10
20
20
20
20
10
20
20
10
20
20
10
20
20
10
15
20
20
30
30
30
40
40
Flatness
(+/- db)
1.5
0.8
0.5
0.5
0.5/B
2.0
1.0
0.5
1.0
0.8
1.5
1.0
1.0
1.5
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Model
No.
AF074-10
AF075C-20
AF07C1-20
AF07C2-20
AF07CK-20
AF075-10
AF075X-20
AF076X2-20
AF076-10
AF076X-20
AF076K-20
AF077-10
AF077J-20
AF076H-20
AV073-10
AV073-15
AV074-20
AV074F-20
AV07C1-30
AV075-30
AV075G-30
AV076-40
AV076H-40
MULTIBAND MODELS
GENERAL SPECIFICATIONS FOR ALL UNITS
•
•
•
•
•
RF CONN:
INS LOSS:
VSWR:
RF POWER*:
ATTEN RGE:
*Higher Power Models Available - Contact Factory
SMA female
0.5dB max
1.5 max
5 W avg, 3 Kw peak
Many other models to 60dB
ATTENUATOR DRIVE
OPTIONS
LEVEL ADJUST MODELS
Our Standard
is a Screw Driver Shaft with a Lock Nut
The Part Number begins with AV0 or AF0
For a
Knob Control Option
change the AV0
or the AF0 in the P/N to AV9 or AF9
Example: AF064-10 = AF964-10
For a
Turns Counting Dial Option
use AV8 or AF8
For a
Direct Reading Tape Drive Option
use
AF7 for Full Frequency Range Calibration or
AV7 for Single Frequency Calibration
(Specify Spot Frequency with Order)
For
28 Volt Motor Drive
add -28 to the Model Number
Attenuator Drive Options
Motor Drive
Knob Control
Turns Counting Dial
Direct Reading
(calibrated in dB)
49 Rider Ave, Patchogue, NY 11772 Phone:
631-289-0363
Fax:
631-289-0358
E-mail:
atmemail@juno.com
Web:
www.atmmicrowave.com
