Type AVE
–40 °C to 85 °C General Purpose SMT Capacitors
Aluminum Electrolytic Capacitors for Filtering and Bypass
Type AVE capacitors are a great value for filter and bypass
applications not requiring wide temperature performance or high
ripple current. Their vertical cylindrical cases facilitate automatic
mounting and reflow soldering and offer a significant savings over
tantalum capacitors.
Highlights
•
+85
°C,
Up to 2000 Hour Load Life
•
Low Impedance
•
Voltage Range: 4 Vdc to 100 Vdc
Specifications
Operating Temperature:
Rated Voltage:
Capacitance:
Capacitance Tolerance:
Leakage Current:
Dissipation Factor:
Low Temperature
Characteristics @ 120 Hz:
Ripple Curent Multipliers
:
Complies with the EU Direc-
tive 2002/95/EC requirement
restricting the use of Lead (Pb),
Mercury (Hg), Cadmium (Cd),
Hexavalent chromium (Cr(VI)),
PolyBrominated Biphenyls (PBB)
and PolyBrominated Diphenyl
Ethers (PBDE).
–40 °C to +85 °C
4, 6.3, 10, 16, 25, 35, 50, 63 & 100 Vdc
0.1
µF
to 1500
µF
±20% @ 120 Hz and +20 °C
0.01 CV or 3
µA
@ +20 °C, after two minutes (whichever is greater)
4V
0.42
6.3V
0.28
10 V
0.24
16 V
0.20
25 V
0.14
35 V
0.12
50 V
0.10
63 V
0.10
100 V
0.10
Rated Voltage (Vdc)
Impedance
Z(-25ºC)/Z(+20ºC)
Ratio
4
7
6.3
4
8
10
3
5
16
2
4
25
2
3
35
2
3
50
2
3
63
2
3
100
2
3
Z(-40ºC)/Z(+20ºC) 15
Frequency
Vdc (V)
≤ 16
25 - 35
50 - 63
100
50 Hz
0.80
0.80
0.80
0.70
120 Hz
1.00
1.00
1.00
1.00
1 kHz
1.15
1.25
1.35
1.35
10 kHz up
1.25
1.40
1.50
1.50
Multiplier
Life Test:
2000 h @ 85 °C
∆ Capacitance ±20% (4 WV: ±30%)
DF: ≤ 200% of limit (4 WV: ±30%)
DCL: ≤ 100% of limit
Shelf Test:
1000 h @ 85 °C
∆ Capacitance ±20% (4 WV: ±30%)
DF: ≤ 200% of limit (4 WV: ±30%)
Outline Drawing
Case
Code
A
B
C
D
X
E
F
G
∅
D
3
4
5
6.3
6.3
8
8
10
Dimensions in millimeters (mm)
L
5.3±0.2
5.3±0.2
5.3±0.2
5.3±0.2
7.7±0.3
6.5±0.3
10±0.5
10±0.5
A
3.3
4.3
5.3
6.6
6.6
8.4
8.4
10.4
B
3.3
4.3
5.3
6.6
6.6
8.4
8.4
10.4
C
W
P±0.2
0.8
1.0
1.5
2.0
2.0
2.3
3.1
4.7
1.5 .45 ~ 0.75
2.0 0.5 to 0.8
2.3 0.5 to 0.8
2.7 0.5 to 0.8
2.7 0.5 to 0.8
3.4 0.5 to 0.8
3.0 0.7 to 1.1
3.3 0.7 to 1.1
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8564 • Fax: (508)996-3830 • www.cde.com
Type AVE
–40 °C to 85 °C General Purpose SMT Capacitors
Aluminum Electrolytic Capacitors for Filtering and Bypass
Part Numbering System
AVE
106
M
Capacitance
Tolerance
M
= ±20%
16
Voltage
04
= 4 Vdc
06
= 6.3 Vdc
10
= 10 Vdc
16
= 16 Vdc
25
= 25 Vdc
35
= 35 Vdc
50
= 50 Vdc
63
= 63 Vdc
2A
= 100 Vdc
B
12T
–F
RoHS
Compliant
Type Capacitance
104
= 0.1 µF
105
= 1.0 µF
106
= 10.0 µF
107
= 100.0 µF
108
= 1000.0 µF
Case Packaging
Code
Information
Width (mm)
T
= Tape & Reel
B
= B
12
= Carrier Tape
Ratings
Max.
Catalog
Cap
(µF)
22
33
47
68
100
22
33
47
68
100
220
220
330
330
470
1000
1500
10
22
33
47
68
100
100
220
220
330
470
1000
AVE226M04A12T-F
AVE336M04B12T-F
AVE476M04B12T-F
AVE686M04C12T-F
AVE107M04D16T-F
AVE226M06B12T-F
AVE336M06B12T-F
AVE476M06C12T-F
AVE686M06D16T-F
AVE107M06D16T-F
AVE227M06X16T-F
AVE227M06E16T-F
AVE337M06X16T-F
AVE337M06E16T-F
AVE477M06F24T-F
AVE108M06G24T-F
AVE158M06G24T-F
AVE106M10B12T-F
AVE226M10C12T-F
AVE336M10C12T-F
AVE476M10D16T-F
AVE686M10D16T-F
AVE107M10X16T-F
AVE107M10E16T-F
AVE227M10X16T-F
AVE227M10E16T-F
AVE337M10F24T-F
AVE477M10G24T-F
AVE108M10G24T-F
Part Number
Max. DCL
2 min.
(µA)
3
3
3
3
4
3
3
3
4.3
6.3
13.9
13.9
20.8
20.8
29.6
63.0
94.5
3
3
3.3
4.7
6.8
10
10
22
22
33
47
100
Max. DF
(%)
0.42
0.42
0.42
0.42
0.42
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.28
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
0.24
Max. E.S.R.
(Ω)
31.65
21.10
14.81
10.24
6.96
21.10
14.07
9.88
6.83
4.64
2.11
2.11
1.41
1.41
0.99
0.46
0.31
39.79
18.09
12.06
8.47
5.85
3.98
3.98
1.81
1.81
1.21
0.85
0.40
Ripple Current Case
(mA)
14
31
37
63
110
23
31
52
89
120
123
155
139
155
252
458
458
23
39
48
67
98
108
155
130
155
252
458
458
A
B
B
C
D
B
B
C
D
D
X
E
X
E
F
G
G
B
C
C
D
D
X
E
X
E
F
G
G
Size
DxL
(mm)
3x5.3
4x5.3
4x5.3
5x5.3
6.3x5.3
4x5.3
4x5.3
5x5.3
6.3x5.3
6.3x5.3
6.3x7.7
8x6.5
6.3x7.7
8x6.5
8x10
10x10
10x10
4x5.3
5x5.3
5x5.3
6.3x5.3
6.3x5.3
6.3x7.7
8x6.5
6.3x7.7
8x6.5
8x10
10x10
10x10
Qty.
Per Reel
(Each)
2000
2000
2000
1000
1000
2000
2000
1000
1000
1000
1000
1000
1000
1000
500
500
500
2000
1000
1000
1000
1000
1000
1000
1000
1000
500
500
500
@120Hz/20ºC @120Hz/20ºC @120Hz/85ºC Code
4 Vdc ( 5 Vdc Surge )
6.3 Vdc ( 8 Vdc Surge )
10 Vdc ( 13 Vdc Surge )
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8564 • Fax: (508)996-3830 • www.cde.com
Type AVE
–40 °C to 85 °C General Purpose SMT Capacitors
Aluminum Electrolytic Capacitors for Filtering and Bypass
Ratings
Max.
Catalog
Cap
(µF)
10
10
22
33
47
68
100
100
220
220
330
470
4.7
10
22
33
47
47
68
68
100
100
220
330
3.3
4.7
10
22
33
33
47
47
68
68
100
220
AVE106M16A12T-F
AVE106M16B12T-F
AVE226M16C12T-F
AVE336M16D16T-F
AVE476M16D16T-F
AVE686M16D16T-F
AVE107M16X16T-F
AVE107M16E16T-F
AVE227M16X16T-F
AVE227M16F24T-F
AVE337M16F24T-F
AVE477M16G24T-F
AVE475M25B12T-F
AVE106M25C12T-F
AVE226M25D16T-F
AVE336M25D16T-F
AVE476M25X16T-F
AVE476M25E16T-F
AVE686M25X16T-F
AVE686M25E16T-F
AVE107M25X16T-F
AVE107M25E16T-F
AVE227M25F24T-F
AVE337M25G24T-F
AVE335M35A12T-F
AVE475M35B12T-F
AVE106M35C12T-F
AVE226M35D16T-F
AVE336M35X16T-F
AVE336M35E16T-F
AVE476M35X16T-F
AVE476M35E16T-F
AVE686M35X16T-F
AVE686M35E16T-F
AVE107M35F24T-F
AVE227M35G24T-F
Part Number
Max. DCL
2 min.
(µA)
3.0
3.0
3.5
5.3
7.5
10.9
16.0
16.0
35.2
35.2
52.8
75.2
3.0
3.0
5.5
8.3
11.8
11.8
17.0
17.0
25.0
25.0
55.0
82.5
3.0
3.0
3.5
7.7
11.6
11.6
16.5
16.5
23.8
23.8
35.0
77.0
Max. DF
(%)
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.2
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.14
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
Max. E.S.R. Ripple Current Case
(Ω)
33.16
33.16
15.07
10.05
7.05
4.88
3.32
3.32
1.51
1.51
1.00
0.71
49.38
23.21
10.55
7.03
4.94
4.94
3.41
3.41
2.32
2.32
1.06
0.70
60.28
42.33
19.89
9.04
6.03
6.03
4.23
4.23
2.93
2.93
1.99
0.90
(mA)
14
26
44
63
75
103
108
155
124
252
252
458
19
32
55
67
98
155
109
155
124
155
252
458
8
20
34
59
85
155
98
155
109
155
252
458
A
B
C
D
D
D
X
E
X
F
F
G
B
C
D
D
X
E
X
E
X
E
F
G
A
B
C
D
X
E
X
E
X
E
F
G
Size
DxL
(mm)
3x5.3
4x5.3
5x5.3
6.3x5.3
6.3x5.3
6.3x5.3
6.3x7.7
8x6.5
6.3x7.7
8x10
8x10
10x10
4x5.3
5x5.3
6.3x5.3
6.3x5.3
6.3x7.7
8x6.5
6.3x7.7
8x6.5
6.3x7.7
8x6.5
8x10
10x10
3x5.3
4x5.3
5x5.3
6.3x5.3
6.3x7.7
8x6.5
6.3x7.7
8x6.5
6.3x7.7
8x6.5
8x10
10x10
Qty.
Per Reel
(Each)
2000
2000
1000
1000
1000
1000
1000
1000
1000
500
500
500
2000
1000
1000
1000
1000
1000
1000
1000
1000
1000
500
500
2000
2000
1000
1000
1000
1000
1000
1000
1000
1000
500
500
@120Hz/20ºC @120Hz/20ºC @120Hz/85ºC Code
16 Vdc ( 20 Vdc Surge )
25 Vdc ( 31 Vdc Surge )
35 Vdc ( 44 Vdc Surge )
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8564 • Fax: (508)996-3830 • www.cde.com
Type AVE
–40 °C to 85 °C General Purpose SMT Capacitors
Aluminum Electrolytic Capacitors for Filtering and Bypass
Ratings
Max.
Catalog
Cap
(µF)
.10
.22
.33
.47
1
2.2
3.3
4.7
10
22
22
33
33
47
47
68
100
220
10
22
33
47
68
100
10
22
33
AVE104M50B12T-F
AVE224M50B12T-F
AVE334M50B12T-F
AVE474M50B12T-F
AVE105M50B12T-F
AVE225M50B12T-F
AVE335M50B12T-F
AVE475M50C12T-F
AVE106M50D16T-F
AVE226M50X16T-F
AVE226M50E16T-F
AVE336M50X16T-F
AVE336M50E16T-F
AVE476M50X16T-F
AVE476M50F24T-F
AVE686M50F24T-F
AVE107M50F24T-F
AVE227M50G24T-F
AVE106M63E16T-F
AVE226M63F24T-F
AVE336M63F24T-F
AVE476M63G24T-F
AVE686M63G24T-F
AVE107M63G24T-F
AVE106M2AF24T-F
AVE226M2AG24T-F
AVE336M2AG24T-F
Part Number
Max. DCL
2 min.
(µA)
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
5.0
11.0
11.0
16.5
16.5
23.5
23.5
34.0
50.0
110.0
6.3
13.9
20.8
29.6
42.8
63.0
10
22
33
Max. DF
(%)
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
Max. E.S.R. Ripple Current Case Size
(Ω)
1657.83
753.56
502.37
352.73
165.78
75.36
50.24
35.27
16.58
7.54
7.54
5.02
5.02
3.53
3.53
2.44
1.66
0.75
16.58
7.54
5.02
3.53
2.44
1.66
16.58
7.54
5.02
(mA)
3
5
6
7
10
15
19
26
44
65
155
82
155
98
252
252
252
458
75
139
139
226
226
226
94
189
189
B
B
B
B
B
B
B
C
D
X
E
X
E
X
F
F
F
G
E
F
F
G
G
G
F
G
G
(mm)
4x5.3
4x5.3
4x5.3
4x5.3
4x5.3
4x5.3
4x5.3
5x5.3
6.3x5.3
6.3x7.7
8x6.5
6.3x7.7
8x6.5
6.3x7.7
8x10
8x10
8x10
10x10
8x6.5
8x10
8x10
10x10
10x10
10x10
8x10
10x10
10x10
Qty.
(Each)
2000
2000
2000
2000
2000
2000
2000
1000
1000
1000
1000
1000
1000
1000
500
500
500
500
1000
500
500
500
500
500
500
500
500
@120Hz/20ºC @120Hz/20ºC @120Hz/85ºC Code D x L Per Reel
50 Vdc ( 63 Vdc Surge )
63 Vdc ( 75 Vdc Surge )
100 Vdc ( 125 Vdc Surge )
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8564 • Fax: (508)996-3830 • www.cde.com
京公网安备 11010802033920号
EEWORLD
