New Product
B350A, B360A
Vishay General Semiconductor
Surface Mount Schottky Barrier Rectifier
FEATURES
• Low profile package
• Ideal for automated placement
• Low forward voltage drop, low power losses
• High efficifieency
• High surge capability
• Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
• Compliant to RoHS Directive 2002/95/EC and in
accordance to WEEE 2002/96/EC
•
Halogen-free according to IEC 61249-2-21 definition
DO-214AC (SMA)
TYPICAL APPLICATIONS
PRIMARY CHARACTERISTICS
I
F(AV)
V
RRM
I
FSM
V
F
at I
F
= 3.0 A
T
J
max.
3.0 A
50 V, 60 V
50 A
0.55 V
150 °C
For use in low voltage, high frequency inverters,
freewheeling, DC/DC converters, and polarity protection
applications.
MECHANICAL DATA
Case:
DO-214AC (SMA)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-M3 - halogen-free, RoHS compliant, and
commercial grade
Terminals:
Matte tin plated leads, solderable
J-STD-002 and JESD 22-B102
M3 suffix meets JESD 201 class 1A whisker test
Polarity:
Color band denotes the cathode end
per
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Device marking code
Maximum repetitive peak reverse voltage
Maximum average forward rectified current (fig. 1)
Peak forward surge current 8.3 ms single half sine-wave
superimposed on rated load
Voltage rate of change (rated V
R
)
Operating junction and storage temperature range
V
RRM
I
F(AV)
I
FSM
dV/dt
T
J
, T
STG
SYMBOL
B350A
B35
50
3.0
50
10 000
- 55 to + 150
B360A
B36
60
V
A
A
V/μs
°C
UNIT
Document Number: 89414
Revision: 20-Apr-11
For technical questions within your region, please contact one of the following:
www.vishay.com
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
1
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
New Product
B350A, B360A
Vishay General Semiconductor
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Maximum instantaneous
forward voltage
Maximum reverse current
Typical junction capacitance
TEST CONDITIONS
I
F
= 3.0 A
T
A
= 25 °C
T
A
= 125 °C
T
A
= 25 °C
T
A
= 125 °C
SYMBOL
V
F (1)
TYP.
0.64
0.55
-
2.9
145
MAX.
0.72
V
0.62
200
10
-
μA
mA
pF
UNIT
Rated V
R
4.0 V, 1 MHz
I
R (2)
C
J
Notes
(1)
Pulse test: 300 μs pulse width, 1 % duty cycle
(2)
Pulse test: Pulse width
40 ms
THERMAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Typical thermal resistance
SYMBOL
R
JA
(1)
R
JL
(1)
B350A
72
°C/W
12
B360A
UNIT
Note
(1)
PCB mounted with 0.32" x 0.32" (8 mm x 8 mm) copper pad areas. T measured at lead terminal mount.
L
ORDERING INFORMATION
(Example)
PREFERRED P/N
B360A-M3/61T
B360A-M3/5AT
UNIT WEIGHT (g)
0.064
0.064
PREFERRED PACKAGE CODE
61T
5AT
BASE QUANTITY
1800
7500
DELIVERY MODE
7" diameter plastic tape and reel
13" diameter plastic tape and reel
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
3.0
Resistive or Inductive Load
2.5
D = 0.3
D = 0.5
D = 0.8
Average Forward Current (A)
2.5
Average Power Loss (W)
2.0
D = 0.2
1.5
D = 0.1
D = 1.0
1.0
T
0.5
D = t
p
/T
0
t
p
3.0
3.5
2.0
1.5
1.0
P.C.B. Mounted on
0.32" x 0.32" (8 mm x 8 mm)
Copper Pad Areas
0.5
0
80
90
100
110
120
130
140
150
0
0.5
1.0
1.5
2.0
Lead Temperature (°C)
Average Forward Current (A)
Fig. 1 - Forward Current Derating Curve
Fig. 2 - Forward Power Loss Characteristics
www.vishay.com
2
For technical questions within your region, please contact one of the following:
Document Number: 89414
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
Revision: 20-Apr-11
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
New Product
B350A, B360A
Vishay General Semiconductor
100
1000
T
J
= 25 °C
f = 1.0 MHz
V
sig
= 50 mV
p-p
Instantaneous Forward Current (A)
T
A
= 125 °C
10
T
A
= 150 °C
Junction Capacitance (pF)
100
1
T
A
= 25 °C
0.1
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0 1.1 1.2
10
0.1
1
10
100
Instantaneous Forward Voltage (V)
Reverse Voltage (V)
Fig. 3 - Typical Instantaneous Forward Characteristics
Fig. 5 - Typical Junction Capacitance
100 000
Instantaneous Reverse Current (μA)
10 000
T
A
= 150 °C
T
A
= 125 °C
1000
100
10
T
A
= 25 °C
1
0.1
10
20
30
40
50
60
70
80
90
100
Percent of Rated Peak Reverse Voltage (%)
Fig. 4 - Typical Reverse Characteristics
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
DO-214AC (SMA)
Cathode Band
Mounting Pad Layout
0.066 (1.68)
MIN.
0.074 (1.88)
MAX.
0.065 (1.65)
0.049 (1.25)
0.110 (2.79)
0.100 (2.54)
0.177 (4.50)
0.157 (3.99)
0.012 (0.305)
0.006 (0.152)
0.060 (1.52)
MIN.
0.208 (5.28)
REF.
0.090 (2.29)
0.078 (1.98)
0.060 (1.52)
0.030 (0.76)
0.008 (0.203)
0 (0)
0.208 (5.28)
0.194 (4.93)
Document Number: 89414
Revision: 20-Apr-11
For technical questions within your region, please contact one of the following:
www.vishay.com
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
3
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
