BH15FB1WHFV Overview

Standard CMOS LDO Regulators

BH15FB1WHFV Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SOF
package instruction	PLASTIC, HVSOF-5
Contacts	5
Reach Compliance Code	compliant
ECCN code	EAR99
Adjustability	FIXED
Maximum absolute input voltage	6.5 V
Maximum input voltage	5.5 V
Minimum input voltage	2.5 V
JESD-30 code	R-PDSO-F5
JESD-609 code	e3/e2
length	1.6 mm
Maximum grid adjustment rate	0.02%
Maximum load regulation	0.03%
Number of functions	1
Output times	1
Number of terminals	5
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Maximum output current 1	0.15 A
Maximum output voltage 1	1.525 V
Minimum output voltage 1	1.475 V
Nominal output voltage 1	1.5 V
Package body material	PLASTIC/EPOXY
encapsulated code	HVSOF
Encapsulate equivalent code	FL6,.047,20
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Regulator type	FIXED POSITIVE SINGLE OUTPUT STANDARD REGULATOR
Maximum seat height	0.6 mm
surface mount	YES
technology	CMOS
Terminal surface	TIN/TIN COPPER
Terminal form	FLAT
Terminal pitch	0.5 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Maximum voltage tolerance	1.7%
width	1.2 mm
Base Number Matches	1

Preview

Download Datasheet

View All

CMOS LDO Regulator Series for Portable Equipments

Standard CMOS LDO Regulators

FB1WG series, BH

LB1WG series, BH

FB1WHFV series,

LB1WHFV series

Large Current 300mA

CMOS LDO Regulators

MA3WHFV Series

No.10020ECT02

Description

The BH

FB1W, BH

LB1W and BH

MA3W series are low dropout CMOS regulators with 150 mA and 300 mA

output that have

1% high accuracy output voltage.

The BH

FB1W series combines 40µA low current consumption and a 70 dB high ripple rejection ratio by utilizing output

level CMOS technology. The components can be easily mounted into the small standard SSOP5 and the ultra-small

HVSOF5/HVSOF6 packages.

Features

1) High accuracy output voltage:

2) High ripple rejection ratio: 70 dB (BH

FB1WHFV/WG, BH

LB1WHFV/WG)

3) Low dropout voltage: 60 mV (when current is 100 mA) (BH

MA3WHFV)

4) Stable with ceramic output capacitors

5) Low Bias current : 40µA (I

= 50 mA) (BH

FB1WHFV/WG)

6) Output voltage ON/OFF control

7) Built-in over-current protection and thermal shutdown circuits

8) Ultra-small power package: HVSOF5 (BH

FB1WHFV, BH

LB1WHFV)

9) Ultra-small power package: HVSOF6 (BH

MA3WHFV)

Applications

Battery-driven portable devices and etc.

Line up

150mA BH

FB1W and BH

LB1W Series

Part Number

FB1WG

FB1WHFV

LB1WG

LB1WHFV

MA3WHFV series

1.5

1.8

2.5

2.8

2.9

3.0

3.1

3.3

Package

HVSOF6

FB1W

Symbol

, BH

LB1W

Symbol

Part Number: B H

M A3 W

1.5

1.8

1.85

2.5

2.8

2.9

3.0

3.1

3.3

Package

SSOP5

HVSOF5

SSOP5

HVSOF5

300mA BH

Part Number

MA3WHFV

Part Number: B H

Details

Output Voltage Designation

Output Voltage (V)

1.5V (Typ.)

2.9V (Typ.)

1.8V (Typ.)

3.0V (Typ.)

1.85V (Typ.)

3.1V (Typ.)

2.5V (Typ.)

3.3V (Typ.)

2.8V (Typ.)

Package: G : SSOP5 HFV : HVSOF5

Details

Output Voltage Designation

Output Voltage (V)

1.5V (Typ.)

2.9V (Typ.)

1.8V (Typ.)

3.0V (Typ.)

2.5V (Typ.)

3.1V (Typ.)

2.8V (Typ.)

3.3V (Typ.)

Package: HFV : HVSOF6

www.rohm.com

1/8

2010.07 -

Rev. C
