BR35H160F-WCE2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > storage> storage> BR35H160F-WCE2

BR35H160F-WCE2: Description125â SPI BUS ICs BR35 Family; Categorystorage storage; File Size497KB，17 Pages; ManufacturerROHM Semiconductor; Websitehttps://www.rohm.com/; Environmental Compliance

Download Datasheet Parametric View All

BR35H160F-WCE2 Overview

125â SPI BUS ICs BR35 Family

BR35H160F-WCE2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	ROHM Semiconductor
Parts packaging code	SOIC
package instruction	LSOP, SOP8,.25
Contacts	8
Reach Compliance Code	compli
ECCN code	EAR99
Maximum clock frequency (fCLK)	5 MHz
Data retention time - minimum	20
Durability	300000 Write/Erase Cycles
JESD-30 code	R-PDSO-G8
length	5 mm
memory density	16384 bi
Memory IC Type	EEPROM
memory width	8
Number of functions	1
Number of terminals	8
word count	2048 words
character code	2000
Operating mode	SYNCHRONOUS
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
organize	2KX8
Package body material	PLASTIC/EPOXY
encapsulated code	LSOP
Encapsulate equivalent code	SOP8,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, LOW PROFILE
Parallel/Serial	SERIAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3/5 V
Certification status	Not Qualified
Maximum seat height	1.6 mm
Serial bus type	SPI
Maximum standby current	0.00001 A
Maximum slew rate	0.003 mA
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	2.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	4.4 mm
write protect	SOFTWARE

Preview

Download Datasheet

View All

Automotive Serial EEPROMs

125℃ SPI BUS ICs

BR35□□□□ Family

BR35H□□□-WC Series

●Description

BR35H□□□-WC Series is a SPI BUS interface method serial EEPROM.

No.11001ECT09

●Features

1) High speed clock operation up to 5MHz(Max.)

2) 2.5V to 5.5V single power source operation most suitable for battery use.

3) Page write mode useful for initial value at factory shipment.

4) Highly reliable connection by Au pad and Au wire.

5) For SPI bus interface (CPOL,CPHA)=(0,0),(1,1)

6) Auto erase and auto end function at data rewrite.

7) Low operating current

At write operation (5V): 0.6mA(Typ.)

At read operation (5V): 1.3mA(Typ.)

At standby operation (5V): 0.1μA(Typ.)

8) Address auto increment function at read operation.

9) Write mistake prevention function

Write prohibition at power on.

Write prohibition by command code (WRDI)

Write mistake prevention function at low voltage.

10) MSOP8 / TSSOP-B8 / SOP8 / SOP-J8 Package.

11) Data at shipment Memory array:FFh.

12) Data Retention : 20 years(Ta≦125℃)

13) Endurance : 300,000 cycles(Ta≦125℃)

●Page

Write

Number of pages

Product number

32Byte

BR35H160-WC

BR35H320-WC

BR35H640-WC

64Byte

BR35H128-WC

●BR35H□□□

Series

Capacity

16Kbit

32Kbit

64Kbit

128Kbit

Bit Format

2K×8

4K×8

8K×8

16Kx8

Product Name

BR35H160-WC

BR35H320-WC

BR35H640-WC

BR35H128-WC

Supply

Voltage

2.5½5.5V

MSOP8

●

TSSOP-B8

●

SOP8

●

SOP-J8

●

www.rohm.com

1/16

2011.03 - Rev.C
