Edal
SERIES B412
Miniature High Voltage Silicon Rectifiers
Smaller in size than other high voltage rectifiers, compact tubular construction and flexible leads facilitate circuit
mounting and provide excellent thermal conductivity. These units are ideally suited for commercial and industrial
applications including high voltage power supplies, electrostatic applications, cathode ray tubes, oscilloscopes, TV,
display, X-ray and laser. Diodes used consist of double diffused junctions, bonded selected and pre-tested for
uniform electrical characteristics. Compact, rugged, tubular construction eliminates sharp edges to reduce corona
common to rectangular packages. Series B412 units meet moisture resistance requirements of MIL Standard 202A,
Method 106. A varied operating range is available from 5,000 volts to 50,000 volts PIV, 5mA to 25mA and available
in both standard and fast recovery series.
Electrical Ratings
Maximum Allowable One Cycle Surge Current
(60 Hz single phase non-recurrent at
rated PRV and no load)
4 amps
Maximum Reverse Current at PIV
25 o C
1 ua*
100 o C
40 ua*
*fast recovery series 2 ua and 100 ua. Maximum reverse
recovery time trr @ If =2 ma and Ir = 4 ma. Recovery
to 1.0 ma – 250 nanoseconds
Standard Series
EDAL P/N*
AVG. FWD CURRENT Io AT
55oC
PIV
VOLTS
MAX.
FWD
VOLTAGE
DROP AT
25oC & Io
VOLTS
12
12
18
18
35
35
35
50
50
70
L
IN.
Fast Recovery Series
EDAL P/N*
AVG. FWD CURRENT Io AT 55oC
PIV
VOLTS
MAX.
FWD
VOLTAGE
DROP AT
25oC & Io
VOLTS
15
15
30
30
60
60
60
90
90
120
L
IN.
5 ma
B412-5-5
B412-7-5
B412-10-5
B412-12-5
B412-15-5
B412-20-5
B412-25-5
B412-30-5
B412-40-5
B412-50-5
10 ma
B412-5-10
B412-7-10
B412-10-10
B412-12-10
B412-15-10
B412-20-10
B412-25-10
B412-30-10
B412-40-10
B412-50-10
25ma
B412-5-25
B412-7-25
B412-10-25
B412-12-25
B412-15-25
B412-20-25
B412-25-25
B412-30-25
B412-40-25
B412-50-25
5000
7000
10000
12000
15000
20000
25000
30000
40000
50000
1.0
1.0
1.0
1.0
2.0
2.0
2.0
3.0
3.0
5.0
5 ma
BR412-5-5
BR412-7-5
BR412-10-5
BR412-12-5
BR412-15-5
BR412-20-5
BR412-25-5
BR412-30-5
BR412-40-5
BR412-50-5
10 ma
BR412-5-10
BR412-7-10
BR412-10-10
BR412-12-10
BR412-15-10
BR412-20-10
BR412-25-10
BR412-30-10
BR412-40-10
BR412-50-10
25 ma
BR412-5-25
BR412-7-25
BR412-10-25
BR412-12-25
BR412-15-25
BR412-20-25
BR412-25-25
BR412-30-25
BR412-40-25
BR412-50-25
5000
7000
10000
12000
15000
20000
25000
30000
40000
50000
1.0
1.0
1.0
1.0
2.0
2.0
2.0
3.0
3.0
5.0
* Standard product lines are also available in 50 ma and 100 ma ratings. Other values are available upon request.
