BR427-35

Description
0.05 A, SILICON, SIGNAL DIODE
CategoryDiscrete semiconductor    diode
File Size729KB,2 Pages
ManufacturerEDAL
Websitehttp://www.edal.com/
Download Datasheet Parametric Compare View All

BR427-35 Overview

0.05 A, SILICON, SIGNAL DIODE

BR427-35 Parametric

Parameter NameAttribute value
MakerEDAL
package instructionO-PALF-W2
Reach Compliance Codeunknow
ECCN codeEAR99
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)10 V
JESD-30 codeO-PALF-W2
Number of components1
Number of terminals2
Maximum output current0.05 A
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formLONG FORM
Certification statusNot Qualified
Maximum repetitive peak reverse voltage3500 V
Maximum reverse recovery time0.25 µs
surface mountNO
Terminal formWIRE
Terminal locationAXIAL
Sub-Miniature High Voltage Rectifiers
Compact tubular construction and flexible leads facilitate circuit mounting, provide excellent thermal conductivity
and eliminate sharp edges to reduce corona common to large, rectangular packages. Diodes are manufactured using
double junctions that are bonded and selected for uniform electrical characteristics. Series B427 and the BA223,
units all meet moisture resistance requirements of MIL Standard 202A, Method 106. Series B427 and BA223 are
available in voltage ratings of 1000 to 7000 volts PIV. The B427 is available in a current range of 50ma to 200ma
and the BA223 in a current range from 150ma to 1000ma. Both are available in standard and fast recovery series.
All series are available with special ratings on request. Other sizes and ratings are available.
Specifications B427, BA223
Standard series
PIV
Volts
1000
1500
2000
2500
3000
3500
4000
4500
5000
5500
6000
6500
7000
PART
NO.
B427-10
B427-15
B427-20
B427-25
B427-30
B427-35
B427-40
B427-45
B427-50
B427-55
B427-60
B427-65
B427-70
Io ma @
55o C
200
200
200
200
200
100
100
100
100
50
50
50
50
Vf
Io @ 25o C
5
5
5
5
5
7
7
7
7
10
10
10
10
PART
NO.
BA223-10
BA223-15
BA223-20
BA223-25
BA223-30
BA223-35
BA223-40
BA223-45
BA223-50
BA223-55
BA223-60
BA223-65
BA223-70
Io ma @
55o C
1000
1000
700
700
500
500
400
400
300
300
200
200
150
Vf
Io @ 25o C
5
5
5
5
5
7
7
7
7
10
10
10
10
Fast Recovery series
PIV
1000
1500
2000
2500
3000
3500
4000
4500
5000
5500
6000
6500
7000
PART
BR427-10
BR427-15
BR427-20
BR427-25
BR427-30
BR427-35
BR427-40
BR427-45
BR427-50
BR427-55
BR427-60
BR427-65
BR427-70
Io ma @
100
100
100
100
100
50
50
50
50
25
25
25
25
Vf
7
7
7
7
7
10
10
10
10
15
15
15
15
PART
BAR223-10
BAR223-15
BAR-223-20
BAR-223-25
BAR223-30
BAR223-35
BAR223-40
BAR223-45
BAR223-50
BAR223-55
BAR223-60
BAR223-65
BAR223-70
Io ma @
500
500
350
350
250
250
200
200
150
150
100
100
75
Vf
7
7
7
7
7
10
10
10
10
15
15
15
15
(203) 467-2591 TEL
(203) 469-5928 FAX
Email: Info@edal.com
Internet:http://www.edal.com
EDAL
industries, inc.
51 Commerce St. East Haven, CT 06512
