SINGLE PHASE BRIDGE RECTIFIER
KBPC6005 THRU KBPC610
BR605 THRU BR610
FEATURES
•
•
•
•
•
•
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
6.0 Ampere
Low cost
This series in UL recognized under component
index, file number E127707
High forward surge current capacity
Ideal for printed circuit board
High isolation voltage from case to leads
High temperature soldering guaranteed:
260
O
C / 10 seconds, at 5 lbs. (2.3kg) tension.
0.445( 11.3)
0.405( 10.3)
BR-6
0.445( 11.3)
0.405( 10.3)
0.620( 15.7)
0.580( 14.7)
0.10( 2.5) x45
0.158( 4.0)
DIA
0.142( 3.6)
+
AC
°
AC
-
0.620( 15.7)
0.580( 14.7)
MECHANICAL DATA
•
•
•
•
•
•
0.270( 6.9)
0.230( 5.8)
Technology: Cell with vacuum soldered
Case: Molded plastic body
Terminal: Lead solderable per MIL-STD-202E
method 208C
Polarity: Polarity symbols marked on case
Mounting: Thru hole for #10 screw, 5 in-lbs torque max.
Weight: 0.13 ounce, 3.66 gram
0.85( 21.6)
MIN
0.75( 19.0) MIN
0.08( 2.0) MIN
0.042( 1.10) DIA
0.038( 0.97) TYP
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
•
•
•
Ratings at 25
O
C ambient temperature unless otherwise specified
Single Phase, half wave, 60Hz, resistive or inductive load
For capacitive load derate current by 20%
SYMBOLS
KBPC6005 KBPC601
BR605
BR61
KBPC602
BR62
KBPC604
BR64
KBPC606
BR66
KBPC608
BR68
KBPC610
BR610
UNIT
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Output Current, at
T
C
= 50℃ (Note 1)
T
A
= 25℃ (Note 2)
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
V
ISO
R
θJc
T
J
T
STG
50
35
50
100
70
100
200
140
200
400
280
400
6.0
3.0
125
64
1.0
5.0
1.0
2500
8.0
-55 to +150
-55 to +150
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
A
2
s
Volts
µA
mA
Volts
O
C/W
O
C
O
C
Peak Forward Surge Current
8.3mS single half sine wave superimposed on
rated load (JEDEC method)
Rating for Fusing (t<8.3mS)
Maximum Instantaneous Forward Voltage drop per
Bridge element at 3.0 A
T
A
= 25℃
Maximum DC Reverse Current at Rated
DC Blocking Voltage per element
T
A
= 100℃
Isolation Voltage from case to lug
Typical Thermal Resistance (Note 1 )
Operating Temperature Rang
Storage Temperature Rang
Notes:
1.
2.
Unit mounted on 6.0” x 5.5” x 0.11” thick (15×14×0.3cm) AL plate
Unit mounted on P.C. Board 0.375” (9.5mm) lead length with 0.47”×0.47” (12×12mm) copper pads.
