BT5C5

Description
1 A, 200 V, SILICON, SIGNAL DIODE, DO-41
CategoryDiscrete semiconductor    diode
File Size1MB,2 Pages
ManufacturerEDAL
Websitehttp://www.edal.com/
Download Datasheet Parametric View All

BT5C5 Overview

1 A, 200 V, SILICON, SIGNAL DIODE, DO-41

BT5C5 Parametric

Parameter NameAttribute value
MakerEDAL
Parts packaging codeDO-41
package instructionPLASTIC PACKAGE-2
Contacts2
Reach Compliance Codeunknow
ECCN codeEAR99
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
JEDEC-95 codeDO-41
JESD-30 codeO-PALF-W2
Number of components1
Number of terminals2
Maximum output current1 A
Package body materialPLASTIC/EPOXY
Package shapeROUND
Package formLONG FORM
Certification statusNot Qualified
Maximum repetitive peak reverse voltage200 V
Maximum reverse recovery time0.05 µs
surface mountNO
Terminal formWIRE
Terminal locationAXIAL
EDAL
SERIES BR5/BS5/BT5
SILICON FAST RECOVERY 1.0 AMP DIODES
DIM
A
B
C
D
INCHES
MIN.
MAX.
0.028
0.034
0.08
0.107
0.160
0.205
1.0
MILLIMETER
MIN.
MAX.
0.71
0.86
2.03
2.74
4.10
5.20
25.4
Io
1 Amp
@
50
C
Is
60
AMPS
Vf
1.4 max.
v@
1.0 amp
@
25
C
Ir
10 uA max.
@
PIV
@
25
C
STYLE
DO – 41 Plastic
Trr – Recovery Time measured from .5 amp forward to 1 amp reverse to .25 amp
PIV
(VOLTS)
50
100
200
300
400
500
600
700
800
1000
P/N
BR5A5
BR5B5
BR5C5
BR5D5
BR5E5
BR5F5
BR5G5
BR5H5
BR5K5
BR5M5
Trr
NSec
P/N
BS5A5
BS5B5
BS5C5
BS5D5
BS5E5
BS5F5
BS5G5
BS5H5
BS5K5
BS5M5
Trr
NSec
P/N
BT5A5
BT5B5
BT5C5
BT5D5
BT5E5
BT5F5
BT5G5
BT5H5
BT5K5
BT5M5
Trr
NSec
400
400
400
400
400
500
500
500
500
500
150
150
150
150
150
250
250
250
250
250
50
50
50
50
50
100
100
100
100
100
(203) 467-2591 TEL
(203) 469-5928 FAX
Email: Info@edal.com
Internet:http://www.edal.com
EDAL
Industries, inc.
51 Commerce St. East Haven, CT 06512
