06035F102KAU4A: DescriptionCeramic Capacitor, Multilayer, Ceramic, 50V, 10% +Tol, 10% -Tol, X8R, 15% TC, 0.001uF, Surface Mount, 0603, CHIP, ROHS COMPLIANT; CategoryPassive components capacitor; File Size118KB，3 Pages; ManufacturerAVX; Environmental Compliance

Download Datasheet Parametric View All

06035F102KAU4A Overview

Ceramic Capacitor, Multilayer, Ceramic, 50V, 10% +Tol, 10% -Tol, X8R, 15% TC, 0.001uF, Surface Mount, 0603, CHIP, ROHS COMPLIANT

06035F102KAU4A Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	AVX
package instruction	, 0603
Reach Compliance Code	compli
ECCN code	EAR99
capacitance	0.001 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
high	0.9 mm
JESD-609 code	e3
length	1.6 mm
Manufacturer's serial number	0603
Installation features	SURFACE MOUNT
multi-layer	Yes
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
Package form	SMT
method of packing	TR, PAPER, 13 INCH
positive tolerance	10%
Rated (DC) voltage (URdc)	50 V
Guideline	AEC-Q200
series	SIZE(X8R)
size code	0603
surface mount	YES
Temperature characteristic code	X8R
Temperature Coefficient	15% ppm/°C
Terminal surface	Tin (Sn) - with Nickel (Ni) barrie
Terminal shape	WRAPAROUND
width	0.81 mm

Preview

Download Datasheet

View All

X8R/X8L Dielectric

General Specifications

AVX has developed a range of multilayer ceramic capacitors designed for use in applications up to 150ºC.

These capacitors are manufactured with an X8R and an X8L dielectric material. X8R material has

capacitance variation of ±15% between -55ºC and +150ºC. The X8L material has capacitance variation of

±15% between -55ºC to 125ºC and +15/-40% from +125ºC to +150ºC.

The need for X8R and X8L performance has been driven by customer requirements for parts that operate

at elevated temperatures. They provide a highly reliable capacitor with low loss and stable capacitance

over temperature.

They are ideal for automotive under the hood sensors, and various industrial applications. Typical industrial

application would be drilling monitoring system. They can also be used as bulk capacitors for high

temperature camera modules.

Both X8R and X8L dielectric capacitors are automotive AEC-Q200 qualified. Optional termination systems, tin,

FLEXITERM

and conductive epoxy for hybrid applications are available. Providing this series with our

FLEXITERM

termination system provides further advantage to customers by way of enhanced resistance to

both, temperature cycling and mechanical damage.

PART NUMBER (see page 2 for complete part number explanation)

0805

Size

0603

0805

1206

Voltage

16V = Y

25V = 3

50V = 5

100V = 1

Dielectric

X8R = F

X8L = L

104

Packaging

2 = 7" Reel

4 = 13" Reel

Special

Code

A = Std.

Product

Capacitance Capacitance

Failure

Terminations

Tolerance

Code (In pF)

Rate

T = Plated Ni

J = ± 5%

4 = Automotive

2 Sig. Digits +

and Sn

K = ±10%

A = Not

Number of

Z = FLEXITERM

M = ± 20%

Applicable U = Conductive

Zeros

e.g. 10μF = 106

Epoxy for

Hybrid apps

NOTE: Contact factory for availability of Termination and Tolerance Options for Specific Part Numbers.

X8R

SIZE

331

471

681

102

152

222

332

472

682

103

153

223

333

473

683

104

154

224

334

474

684

105

WVDC

Cap

330

(pF)

470

680

1000

1500

2200

3300

4700

6800

Cap 0.01

(μF) 0.015

0.022

0.033

0.047

0.068

0.1

0.15

0.22

0.33

0.47

0.68

WVDC

X8L

0805

1206

50V

25V

50V

331

471

681

102

152

222

332

472

682

103

153

223

333

473

683

104

154

224

334

474

684

105

0603

25V

50V

25V

SIZE

WVDC

Cap

330

(pF)

470

680

1000

1500

2200

3300

4700

6800

Cap 0.01

(μF) 0.015

0.022

0.033

0.047

0.068

0.1

0.15

0.22

0.33

0.47

0.68

WVDC

0603

25V

50V

100V

25V

0805

50V

100V

16V

1206

25V

50V

100V

25V

50V

25V

50V

25V

50V

25V

50V

100V

25V

50V

100V

16V

25V

50V

100V

SIZE

Letter

Max.

Thickness

0.33

(0.013)

0603

0.56

(0.022)

0.71

(0.028)

PAPER

0805

0.90

(0.035)

0.94

(0.037)

1206

1.02

(0.040)

1.27

(0.050)

SIZE

1.40

(0.055)

0603

1.52

1.78

(0.060)

(0.070)

EMBOSSED

2.29

(0.090)

0805

2.54

(0.100)

2.79

(0.110)

1206

= AEC-Q200

Qualified
