ZHCS400
SURFACE MOUNT SCHOTTKY BARRIER DIODE
Product Summary
•
•
•
•
Low V
F
High Current Capability
Miniature Surface Mount Package
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
•
Case: SOD323
Case Material: UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: Cathode Band
Terminals: Finish - Matte Tin annealed over Alloy 42 leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 0.004 grams (approximate)
Applications
•
•
•
DC – DC Converters
Mobile Telecomms
PCMCIA
SOD323
Top View
Ordering Information
Device
ZHCS400
Packaging
SOD-323
Shipping
3000/Tape & Reel
Marking Information
Anode
BD
Cathode
BD = Product Type Marking Code
ZHCS400
Document number: DS33215 Rev. 7 - 2
1 of 5
www.diodes.com
June 2011
© Diodes Incorporated
ZHCS400
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Continuous Reverse Voltage
Continuous Forward Current
Forward Voltage @I
F
= 400mA
Average Peak Forward Current; D.C. = 50%
Continuous Drain Current (Note x)
t
≤
100μs
t
≤
10ms
Symbol
V
R
I
F
V
F
I
FAV
I
FSM
Value
40
400
500
1000
6.75
3
Units
V
mA
mV
mA
A
A
Thermal Characteristics
Characteristic
Power Dissipation, T
A
= 25°C
Storage Temperature Range
Symbol
P
D
T
STG
Value
250
-55 to +150
Unit
mW
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Reverse Breakdown Voltage
Symbol
V
(BR)R
Min
40
-
-
-
-
-
-
-
-
-
-
Typ
60
270
300
370
425
550
640
810
440
15
20
Max
-
300
350
460
500
670
780
1050
-
40
-
Unit
V
Test Condition
I
R
= 200μA
I
F
= 50mA
I
F
= 100mA
I
F
= 250mA
I
F
= 400mA
I
F
= 750mA
I
F
= 1,000mA
I
F
= 1,500mA
I
F
= 500mA, TA = 100°C
V
R
= 30V
f = 1MHz, V
R
= 25V
Forward Voltage
V
F
mV
Reverse Current
Diode Capacitance
I
R
C
D
μA
pF
ZHCS400
Document number: DS33215 Rev. 7 - 2
2 of 5
www.diodes.com
June 2011
© Diodes Incorporated
