Features
■
■
■
■
JA version available to 100K ohms
10 pin with 8 resistors in bussed type for
pull up/down circuit
Lead free version available (see How to
Order “Termination” options)
RoHS compliant*
■
■
■
■
■
Convex termination style
Resistance tolerance ±5 %
E24 Series from 10 ohms to 43K ohms
Suitable for all types of soldering processes
Paper tape on plastic reel for automatic
placement
*R
Model CAY17 - Bussed Resistor Array
Characteristics
Number of Resistors....8 (bussed circuit)
Power Rating per Resistor @ 70 °C
...................................................31 mW
Package Power Rating @ 70 °C
.................................................250 mW
Operating Temperature Range
..................................-55 °C to +125 °C
Derated to 0 Load @ ..................+125 °C
Max. Working Voltage ......................25 V
Max. Overload Voltage.....................50 V
Resistance Tolerance .....................±5 %
Resistance Range/E24 Series
JA version ........10 ohms to 100K ohms
JB version ..........10 ohms to 43K ohms
T.C.R..................................±250 ppm/°C
Construction
Rated Load (%)
Product Dimensions
0.55
±
0.1
(.022
±
.004)
0.2
±
0.15
(.008
±
.006)
0.3
±
0.2
(.012
±
.008)
1 0 3
1.6
±
0.2
(.063
±
.008)
DIMENSIONS:
0.64
(.025)
3.2
±
0.2
(.126
±
.008)
0.34
±
0.15
(.013
±
.006)
0.5
±
0.1
(.020
±
.004)
MM
(INCHES)
Derating Curve
100
70
°C
125
°C
80
60
40
20
0
-55
40 60 80
Ambient Temp. (˚C)
100 120 140 160
Bussed Circuits - Option A
10
9
R
R
1
2
R
3
8
R
R
4
7
R
R
5
6
R
Protective Glass Overcoat
Thick Film
Resistive Element
Termination
High Purity Alumina
Substrate
Packaging Dimensions
1.0
MAX.
(.039)
1.5 + 0.1 - 0
(.059 + .004 - 0)
4.0
±
0.1
(.158
±
.004)
How To Order
CA Y 17 - 103 J A __
Chip Arrays
Type
• Y = Convex
Model
• 17 = 1206 Package Size
Resistance Code
• 103 = 10K ohms
(JA range: 10 ohms to 100K ohms;
JB range: 10 ohms to 43K ohms)
Resistance Tolerance
• J = ±5 %
Resistors
• A = Common from terminal 5 to 10
• B = Common from terminal 1 to 6
Terminations
• LF = Tin-plated (lead free)
• Blank = Solder-plated
21.0
±
0.8
(.827
±
.031)
1.4
MAX.
(.055)
3.6
±
0.2
(.142
±
.008)
3.5
±
0.05
(.138
±
.002)
8.0
±
0.2
(.315
±
.008)
2.0
±
0.2
(.079
±
.008)
4.0
±
0.1
(.157
±
.004)
2.0
±
0.5
(.079
±
.020)
13.0
±
0.2
(.511
±
.008)
60
(2.362)
9.0
±
0.3
(.354
±
.012)
11.4
±
1.0
(.449
±
.040)
180
(7.087)
For Standard Values Used in Capacitors,
Inductors, and Resistors,
click here.
*RoHS Directive 2002/95/EC Jan 27 2003 including Annex
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
Model CAY17 - Bussed Resistor Array
Soldering Profile for Lead Free Chip Resistors and Arrays
275
<1>
Maximum of 20 seconds between
260 °C peak
<1>
255 °C
+255 °C and +260 °C
225
220 °C
Temperature (°C)
190 °C
175
150 °C
60 - 90
seconds
Ramp Down
3 °C/second
125
60 - 120 seconds
10 seconds minimum
75
Ramp Up
3 °C/second maximum
25
0
50
100
150
Time (seconds)
200
250
300
REV. 04/06
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
