CLD160
Large Active Area
Silicon Planar photodiode
0.365 (9.27)
0.355 (9.02)
0.186 (4.72)
0.164 (4.17)
®
Clairex
Technologies, Inc
.
July, 2001
1.000 (25.4) min
0.030 (0.76) nom
0.200 (5.08)
0.330 (8.38)
0.320 (8.13)
(short lead)
CATHODE (long lead)
ALL DIMENSIONS ARE IN INCHES (MILLIMETERS)
Case 12
features
•
100° acceptance angle
•
860nm peak response
•
hermetically sealed TO-5
package
•
usable for visible through near-IR
•
RoHS compliant
absolute maximum ratings
(T
A
= 25°C unless otherwise stated)
storage temperature....................................................................... -65°C to +150°C
operating temperature................................................................... -65°C to +150°C
lead soldering temperature
(1)
......................................................................... 260°C
reverse voltage ..................................................................................................30V
continuous power dissipation
(2)
...................................................................250mW
1.
2.
0.06” (1.5mm) from the header for 5 seconds maximum.
Derate linearly 1.60mW/°C free air temperature to T
A
= +150°C.
notes:
description
The CLD160 is a 0.122" x 0.122"
active area silicon photodiode
mounted in a flat window TO-5
package. Wide acceptance angle
permits use in IR air communications
ambient light detection, safety and
monitoring, security systems, etc. For
additional information, call Clairex.
electrical characteristics
(T
A
= 25°C unless otherwise noted)
symbol
I
SC
I
D
V
O
V
BR
C
J
t
r
, t
f
Θ
HP
parameter
Short-circuit current
(3)
Dark current
Open circuit voltage
(3)
min
-
-
-
25
-
-
-
typ
50
-
0.35
-
-
-
100
max
-
5.0
-
-
200
12
-
units
µA
nA
V
V
pF
µs
deg.
test conditions
V
BIAS
= 0V, E
e
=5mW/cm
2
V
R
= 15V, E
e
= 0
E
e
= 5mW/cm
2
I
R
= 100µA
V
BIAS
=0V, f = 1MHz
R
L
= 1kΩ
Reverse breakdown
Junction capacitance
Output rise and fall time
(4)
Total angle at half sensitivity points
notes:
3.
4.
Radiation source is a frosted tungsten lamp with color temperature of 2854K or equivalent.
Radiation source is an AlGaAs IRED operating at a peak emission wavelength of 880nm and E
e
= 20mW/cm
2
.
Clairex reserves the right to make changes at any time to improve design and to provide the best possible product.
Revised 3/15/06
Clairex Technologies, Inc.
Phone: 972-265-4900
1301 East Plano Parkway
Fax: 972-265-4949
Plano, Texas 75074-8524
www.clairex.com
