BA3574BFS

Description
Low-current audio headphone driver
CategoryAnalog mixed-signal IC    Consumption circuit
File Size175KB,11 Pages
ManufacturerROHM Semiconductor
Websitehttps://www.rohm.com/
Environmental Compliance
Download Datasheet Parametric View All

BA3574BFS Overview

Low-current audio headphone driver

BA3574BFS Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerROHM Semiconductor
Parts packaging codeSSOP
package instructionSSOP-20
Contacts20
Reach Compliance Codecompli
ECCN codeEAR99
channel separation44 dB
Commercial integrated circuit typesTONE CONTROL CIRCUIT
harmonic distortion0.1%
JESD-30 codeR-PDSO-G20
JESD-609 codee3/e2
length8.7 mm
Number of frequency bands1
Number of channels1
Number of functions1
Number of terminals20
Maximum operating temperature75 °C
Minimum operating temperature-25 °C
Package body materialPLASTIC/EPOXY
encapsulated codeSSOP
Encapsulate equivalent codeSOP20,.3,32
Package shapeRECTANGULAR
Package formSMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)260
power supply2.4 V
Certification statusNot Qualified
Maximum seat height1.9 mm
Maximum slew rate3 mA
Maximum supply voltage (Vsup)3.6 V
Minimum supply voltage (Vsup)1.7 V
surface mountYES
Temperature levelCOMMERCIAL EXTENDED
Terminal surfaceTIN/TIN COPPER
Terminal formGULL WING
Terminal pitch0.8 mm
Terminal locationDUAL
Maximum time at peak reflow temperature10
width5.4 mm
Audio ICs
Low-current audio headphone driver
BA3574BFS
The BA3574BFS is a headphone driver with a fixed-gain bass boost circuit and an AVC circuit that keeps the output
below a fixed level. It features low current dissipation, and low output noise, and is ideal for use in portable digital audio
equipment.
FApplications
Portable CD and MD players
FFeatures
1) Low current dissipation (when V
CC
= 2.4V, the quies-
cent current is 4.9mA).
2) Suitable for use in digital audio equipment (voltage
gain: G
V
= 11.8dB, output noise voltage: V
NO
=
*102dBm
typ.).
3) Bass boost circuit.
4) AVC (Auto Volume Control) circuit, for output limiting.
5) Standby switch.
6) Mute switch.
7) Ripple filter.
8) No output coupling capacitor required.
9) Beep circuit.
10) SSOP-A20 package.
